Image preview - the first page of the document
>> Download UE32ES5500K_SI_1369292597 documenatation <<
Text preview - extract from the document
For X10+ LED TV
ES5700 : DVB- T/ C/ S2 Model
UE32ES5500(5700)
UE40ES5500(5700)
UE46ES5500(5700)
UE32EH5300
UE40EH5300
UE46EH5300
UE26EH4500
UE22ES5400
. Specification
. Design
. Inner Feature
. Disassemble
. Troubleshooting
. 12Year New Smart TV
. Speci f i cat i on
Series Series UE**ES5500(5700) Series Series UE**ES5500(5700)
Ultra Clear Panel No(Anti Glare) Samsung 3D No
Display Screen Size 32" / 40" / 46" 3D Converter No
Resolution 1,920 x 1,080 Dual View No
Dynamic Contrast Ratio MEGA Samsung One Line No
Picture Engine Hyper Real Engine History No
Wide Color Enhancer Plus Wide Color Enhancer Plus Smart Phone Remote Support Yes
Video
Auto Motion Plus 120/240Hz No Extended PVR Yes
Clear Motion Rate 100 Time shift Yes
Micro Dimming No Allshare (Powerd by DLNA) Yes
Dolby Dolby Digital Plus/ Dolby Pulse Allshare Cloud Storage Yes
SRS SRS TheaterSound HD ConnectShareTM (USB2.0) Movie(HDD)
dts 2.0 + Digital Out Yes RUI Yes
Audio
Sound Output (RMS) 10W X2 RVU Yes
Speaker Type Down Firing + Full Range Wi-Fi Direct Yes
3D Sound No Wireless LAN Built-In No
Samsung SMART TV Yes Wireless LAN Adapter Support Yes
Family Story Yes BT HID Built-In No
Fitness Yes USB HID Support Yes
Kids Yes OSD Language 29 European Languages
Advertisement No User Interface ACE Espresso
Samsung SMART View No Feature Digital Noise Filter Yes
SMART TV
Smart Hub Yes Analog Signal Booster No
Functionality
Search All Yes MHL No
Your Video Yes WiDi No
Social TV Yes InstaPort S (HDMI Quick Switch) No
Samsung Apps Yes HDMI 1.4 3D Auto Setting No
SkypeTM on Samsung TV Yes Yes(FR,
HbbTV
Web browser Yes DE,ATCH,ES,NL,BE,LU)
Camera Bulit-In No Teletext (TTXT) Yes
Face Recognition No Anynet+ (HDMI-CEC) Yes
Hand Gesture Recognition No BD WisePlus No
SI Voice Recognition (Embedded) No Auto Channel Search Yes
Voice Recognition (Server) No Auto Power Off Yes
Camera App No Auto Volume Leveler Yes
Samsung TV Apps supported No Caption (Subtitle) Yes
Clock & On/Off Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
Chanel List USB-clone Yes
V-Chip N/A
. Speci f i cat i on
Series Series UE**ES5500
DTV Tuner DVB-T/C, DVB-T2/C(UK,Nordic)
Analog Tuner Yes
System CI/CI+ CI+ 1.2
MHP(1.1.3) Italy Only
MHP/ MHEG (version) / ACAP
MHEG 5 (UK, Nordic Only)
HDMI 3
USB 2
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (common Use for Component Y)
Ethrnet (LAN) 1
Headphone 1
Digital Audio Out (Optical) 1
Audio Out (Mini Jack) No
Input & Output
PC In (D-sub) No
PC Audio In (Mini Jack) No
DVI Audio In (Mini Jack) 1
RF In (Terrestrial/Cable input) 1
RF In (Satellite input) No
RS232C (AV CONTROL) No
CI Slot 1
Scart 1
Bezel Type D2
Slim Type Ultra slim
Front Color Black
Design Middle Color Black
Light Effect (Deco) No
Stand Type Square
Swivel (Left/Right) No
Eco Mark EU Ecolabel
Eco Eco Label Yes
Eco Sensor Yes
Power Supply (V) AC220-240V 50/60Hz
Power Power Consumption (Max.) 32"(60W) / 40"(87W) / 46"(92")
Power Consumption (Stand-by) Under 0.3W
32" (36.6 x 4.7 x 21.1)
Package Size (W x D x H) 40" (44.3 x 5.0 x 25.4)
46" (50.0 x 5.5 x 29.1)
32" (29.1 x 7.1 x 19.3)
Set Size (W x D x H)
Dimension 40" (36.5 x 7.2 x 23.8)
with Stand (inchs)
46" (41.8 x 9.0 x 26.9)
32" (29.1 x 1.8 x 17.7)
Set Size (W x D x H)
40" (36.5 x 1.8 x 21.8)
without Stand (inchs)
46" (41.8 x 1.8 x 24.8)
Package Weight (lbs) 32"(17.6) / 40"(30.9) / 46"(39.9)
Weight Set Weight with Stand (lbs) 32"(14.8) / 40"(27.6) / 46"(33.7)
Set Weight without Stand (lbs) 32"(13.7) / 40"(22.8) / 46"(29.1)
. Speci f i cat i on
Series Series UE**ES5700
DTV Tuner DVB-T/C/S2
Analog Tuner Yes
System
CI/CI+ CI+ 1.2
MHP/ MHEG (version) / ACAP N/A
HDMI 3
USB 2
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (common Use for Component Y)
Ethrnet (LAN) 1
Headphone 1
Digital Audio Out (Optical) 1
Audio Out (Mini Jack) No
Input & Output
PC In (D-sub) No
PC Audio In (Mini Jack) No
DVI Audio In (Mini Jack) 1
RF In (Terrestrial/Cable input) 1
RF In (Satellite input) No
RS232C (AV CONTROL) No
CI Slot 1
Scart 1
Bezel Type D2
Slim Type Ultra slim
Front Color Black
Design Middle Color Black
Light Effect (Deco) No
Stand Type Square
Swivel (Left/Right) No
Eco Mark EU Ecolabel
Eco Eco Label Yes
Eco Sensor Yes
Power Supply (V) AC220-240V 50/60Hz
Power Power Consumption (Max.) 32"(60W) / 40"(87W) / 46"(92")
Power Consumption (Stand-by) Under 0.3W
32" (36.6 x 4.7 x 21.1)
Package Size (W x D x H) 40" (44.3 x 5.0 x 25.4)
46" (50.0 x 5.5 x 29.1)
32" (29.1 x 7.1 x 19.3)
Set Size (W x D x H)
Dimension 40" (36.5 x 7.2 x 23.8)
with Stand (inchs)
46" (41.8 x 9.0 x 26.9)
32" (29.1 x 1.8 x 17.7)
Set Size (W x D x H)
40" (36.5 x 1.8 x 21.8)
without Stand (inchs)
46" (41.8 x 1.8 x 24.8)
Package Weight (lbs) 32"(17.6) / 40"(30.9) / 46"(39.9)
Weight Set Weight with Stand (lbs) 32"(14.8) / 40"(27.6) / 46"(33.7)
Set Weight without Stand (lbs) 32"(13.7) / 40"(22.8) / 46"(29.1)
. Speci f i cat i on
Series Series UE**EH5300 Series Series UE**EH5300
Ultra Clear Panel No(Anti Glare) Samsung 3D No
Display Screen Size 32" / 40" / 46" 3D Converter No
Resolution 1,920 x 1,080 Dual View No
Dynamic Contrast Ratio MEGA Samsung One Line No
Picture Engine Hyper Real Engine History No
Wide Color Enhancer Plus Wide Color Enhancer Plus Smart Phone Remote Support Yes
Video
Auto Motion Plus 120/240Hz No Extended PVR No
Clear Motion Rate 100 Time shift Yes
Micro Dimming No Allshare (Powerd by DLNA) Yes
Dolby Dolby Digital Plus/ Dolby Pulse Allshare Cloud Storage Yes
SRS SRS TheaterSound HD ConnectShareTM (USB2.0) Movie(HDD)
dts 2.0 + Digital Out Yes RUI Yes
Audio
Sound Output (RMS) 10W X2 RVU Yes
Speaker Type Down Firing + Full Range Wi-Fi Direct Yes
3D Sound No Wireless LAN Built-In No
Samsung SMART TV Yes Wireless LAN Adapter Support Yes
Family Story Yes BT HID Built-In No
Fitness Yes USB HID Support Yes
Kids Yes OSD Language 29 European Languages
Advertisement No User Interface ACE Espresso
Samsung SMART View No Feature Digital Noise Filter Yes
SMART TV
Smart Hub Yes Analog Signal Booster No
Functionality
Search All Yes MHL No
Your Video Yes WiDi No
Social TV Yes InstaPort S (HDMI Quick Switch) No
Samsung Apps Yes HDMI 1.4 3D Auto Setting No
SkypeTM on Samsung TV Yes Yes(FR,
HbbTV
Web browser Yes DE,ATCH,ES,NL,BE,LU)
Camera Bulit-In No Teletext (TTXT) Yes
Face Recognition No Anynet+ (HDMI-CEC) Yes
Hand Gesture Recognition No BD WisePlus No
SI Voice Recognition (Embedded) No Auto Channel Search Yes
Voice Recognition (Server) No Auto Power Off Yes
Camera App No Auto Volume Leveler Yes
Samsung TV Apps supported No Caption (Subtitle) Yes
Clock & On/Off Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
Chanel List USB-Clone Yes
V-Chip N/A
. Speci f i cat i on
Series Series UE**EH5300
DTV Tuner DVB-T/C, DVB-T2/C(UK,Nordic)
Analog Tuner Yes
System CI/CI+ CI+ 1.2
MHP(1.1.3) Italy Only
MHP/ MHEG (version) / ACAP
MHEG 5 (UK, Nordic Only)
HDMI 3
USB 2
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (common Use for Component Y)
Ethrnet (LAN) 1
Headphone 1
Digital Audio Out (Optical) 1
Audio Out (Mini Jack) No
Input & Output
PC In (D-sub) No
PC Audio In (Mini Jack) No
DVI Audio In (Mini Jack) 1
RF In (Terrestrial/Cable input) 1
RF In (Satellite input) No
RS232C (AV CONTROL) No
CI Slot 1
Scart 1
Bezel Type D2
Slim Type Normal
Front Color Black
Design Middle Color Black
Light Effect (Deco) No
Stand Type Square
Swivel (Left/Right) No
Eco Mark EU Ecolabel
Eco Eco Label Yes
Eco Sensor Yes
Power Supply (V) AC220-240V 50/60Hz
Power Power Consumption (Max.) 32"(60W) / 40"(87W) / 46"(92")
Power Consumption (Stand-by) Under 0.3W
32" (35.5 x 6.4 x 20.9)
Package Size (W x D x H) 40" (43.5 x 6.5 x 25.2)
46" (48.7 x 6.5 x 28.5)
32" (29.1 x 7.6 x 19.6)
Set Size (W x D x H)
Dimension 40" (36.5 x 9.8 x 23.9)
with Stand (inchs)
46" (41.7 x 9.8 x 26.8)
32" (29.1 x 3.7 x 17.5)
Set Size (W x D x H)
40" (36.5 x 3.7 x 20.1)
without Stand (inchs)
46" (41.7 x 3.7 x 24.6)
Package Weight (lbs) 32"(17.6) / 40"(29.5) / 46"(35.9)
Weight Set Weight with Stand (lbs) 32"(14.3) / 40"(24.0) / 46"(31.3)
Set Weight without Stand (lbs) 32"(12.8) / 40"(19.6) / 46"(26.9)
. Speci f i cat i on
Series Series UE26EH4500 Series Series UE26EH4500
Ultra Clear Panel No(Anti Glare) Samsung 3D No
Display Screen Size 26" 3D Converter No
Resolution 1,366 x 768 Dual View No
Dynamic Contrast Ratio MEGA Samsung One Line No
Picture Engine Hyper Real Engine History No
Wide Color Enhancer Plus Wide Color Enhancer Plus Smart Phone Remote Support Yes
Video
Auto Motion Plus 120/240Hz No Extended PVR No
Clear Motion Rate 100 Time shift Yes
Micro Dimming No Allshare (Powerd by DLNA) Yes
Dolby Dolby Digital Plus/ Dolby Pulse Allshare Cloud Storage Yes
SRS SRS TheaterSound HD ConnectShareTM (USB2.0) Movie
dts 2.0 + Digital Out Yes RUI Yes
Audio
Sound Output (RMS) 5W X2 RVU Yes
Speaker Type Down Firing + Full Range Wi-Fi Direct Yes
3D Sound No Wireless LAN Built-In Yes
Samsung SMART TV Yes Wireless LAN Adapter Support No
Family Story Yes BT HID Built-In No
Fitness Yes USB HID Support Yes
Kids Yes OSD Language 29 European Languages
Advertisement No User Interface ACE Espresso
Samsung SMART View No Feature Digital Noise Filter Yes
SMART TV
Smart Hub Yes Analog Signal Booster Yes
Functionality
Search All Yes MHL No
Your Video Yes WiDi No
Social TV Yes InstaPort S (HDMI Quick Switch) No
Samsung Apps Yes HDMI 1.4 3D Auto Setting No
SkypeTM on Samsung TV Yes Yes(FR,
HbbTV
Web browser Yes DE,ATCH,ES,NL,BE,LU)
Camera Bulit-In No Teletext (TTXT) Yes
Face Recognition No Anynet+ (HDMI-CEC) Yes
Hand Gesture Recognition No BD WisePlus No
SI Voice Recognition (Embedded) No Auto Channel Search Yes
Voice Recognition (Server) No Auto Power Off Yes
Camera App No Auto Volume Leveler Yes
Samsung TV Apps supported No Caption (Subtitle) Yes
Clock & On/Off Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
Chanel List USB-Clone Yes
V-Chip N/A
. Speci f i cat i on
Series Series UE26EH4500
DTV Tuner DVB-T/C
Analog Tuner Yes
System CI/CI+ CI+ 1.2
MHP(1.1.3) Italy Only
MHP/ MHEG (version) / ACAP
MHEG 5 (UK, Nordic Only)
HDMI 2
USB 2
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (common Use for Component Y)
Ethrnet (LAN) 1
Headphone 1
Digital Audio Out (Optical) 1
Audio Out (Mini Jack) No
Input & Output
PC In (D-sub) No
PC Audio In (Mini Jack) No
DVI Audio In (Mini Jack) 1
RF In (Terrestrial/Cable input) 1
RF In (Satellite input) No
RS232C (AV CONTROL) No
CI Slot 1
Scart 1
Bezel Type D3
Slim Type Normal
Front Color Black
Design Middle Color Black
Light Effect (Deco) No
Stand Type Square
Swivel (Left/Right) No
Eco Mark EU Ecolabel
Eco Eco Label Yes
Eco Sensor Yes
Power Supply (V) AC220-240V 50/60Hz
Power Power Consumption (Max.) 26"(40W)
Power Consumption (Stand-by) Under 0.3W
Package Size (W x D x H) 26" (30.8 x 6.5 x 18.2)
Set Size (W x D x H)
26" (24.9 x 7.1 x 17.5)
Dimension with Stand (inchs)
Set Size (W x D x H)
26" (20.6 x 6.8 x 14.7)
without Stand (inchs)
Package Weight (lbs) 26"(12.3)
Weight Set Weight with Stand (lbs) 26"(10.4)
Set Weight without Stand (lbs) 26"(9.3)
. Speci f i cat i on
Series Series UE22ES5400 Series Series UE22ES5400
Ultra Clear Panel No(Anti Glare) Samsung 3D No
Display Screen Size 22" 3D Converter No
Resolution 1,920 x 1,080 Dual View No
Dynamic Contrast Ratio MEGA Samsung One Line No
Picture Engine Hyper Real Engine History No
Wide Color Enhancer Plus Wide Color Enhancer Plus Smart Phone Remote Support Yes
Video
Auto Motion Plus 120/240Hz No Extended PVR No
Clear Motion Rate 100 Time shift Yes
Micro Dimming No Allshare (Powerd by DLNA) Yes
Dolby Dolby Digital Plus/ Dolby Pulse Allshare Cloud Storage Yes
SRS SRS TheaterSound HD ConnectShareTM (USB2.0) Movie
dts 2.0 + Digital Out Yes RUI Yes
Audio
Sound Output (RMS) 3W X2 RVU Yes
Speaker Type Down Firing + Full Range Wi-Fi Direct Yes
3D Sound No Wireless LAN Built-In Yes
Samsung SMART TV Yes Wireless LAN Adapter Support No
Family Story Yes BT HID Built-In No
Fitness Yes USB HID Support Yes
Kids Yes OSD Language 29 European Languages
Advertisement No User Interface ACE Espresso
Samsung SMART View No Feature Digital Noise Filter Yes
SMART TV
Smart Hub Yes Analog Signal Booster Yes
Functionality
Search All Yes MHL No
Your Video Yes WiDi No
Social TV Yes InstaPort S (HDMI Quick Switch) No
Samsung Apps Yes HDMI 1.4 3D Auto Setting No
SkypeTM on Samsung TV Yes Yes(FR,
HbbTV
Web browser Yes DE,ATCH,ES,NL,BE,LU)
Camera Bulit-In No Teletext (TTXT) Yes
Face Recognition No Anynet+ (HDMI-CEC) Yes
Hand Gesture Recognition No BD WisePlus No
SI Voice Recognition (Embedded) No Auto Channel Search Yes
Voice Recognition (Server) No Auto Power Off Yes
Camera App No Auto Volume Leveler Yes
Samsung TV Apps supported No Caption (Subtitle) Yes
Clock & On/Off Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
Chanel List USB-Clone Yes
V-Chip N/A
. Speci f i cat i on
Series Series UE22ES5400
DTV Tuner DVB-T/C
Analog Tuner Yes
System CI/CI+ CI+ 1.2
MHP(1.1.3) Italy Only
MHP/ MHEG (version) / ACAP
MHEG 5 (UK, Nordic Only)
HDMI 1
USB 2
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (common Use for Component Y)
Ethrnet (LAN) 1
Headphone 1
Digital Audio Out (Optical) 1
Audio Out (Mini Jack) No
Input & Output
PC In (D-sub) 1
PC Audio In (Mini Jack) 1 (common Use for DVI Audio In)
DVI Audio In (Mini Jack) 1
RF In (Terrestrial/Cable input) 1
RF In (Satellite input) No
RS232C (AV CONTROL) No
CI Slot 1
Scart 1
Bezel Type D3
Slim Type Normal
Front Color Black
Design Middle Color Black
Light Effect (Deco) No
Stand Type Square
Swivel (Left/Right) No
Eco Mark EU Ecolabel
Eco Eco Label Yes
Eco Sensor Yes
Power Supply (V) AC220-240V 50/60Hz
Power Power Consumption (Max.) 26"(30W)
Power Consumption (Stand-by) Under 0.3W
Package Size (W x D x H) 22" (23.0 x 4.4 x 18.2)
Set Size (W x D x H)
22" (20.6 x 6.8 x 14.7)
Dimension with Stand (inchs)
Set Size (W x D x H)
22" (20.6 x 2.0 x 12.7)
without Stand (inchs)
Package Weight (lbs) 22"(9.7)
Weight Set Weight with Stand (lbs) 22"(7.9)
Set Weight without Stand (lbs) 22"(7.5)
. Speci f i cat i on Model
UE5N(UE**ES5500)
Slim LED
UE5M(UE**EH5300)
Direct LED
UD5R(UE**D5500)
LED
Spec. Comparison
Design
Diplay Type LED TV 2D LED TV 2D LED TV 2D
Built-in Tuner O O O
Resolution 1920 x 1080 1920 x 1080 1920 x 1080
LCD Panel TFT LCD Panel 60Hz TFT LCD Panel 60Hz TFT LCD Panel 60Hz
Picture ratio 16:9 16:9 16:9
Under 60 W Under 60 W Under 68 W
32" 32" 32"
(under 0.3 W, Standby) (under 0.3 W, Standby) (under 0.3 W, Standby)
Under 87 W Under 87 W Under 103 W
Power Consumption 40" 40" 40"
(under 0.3 W, Standby) (under 0.3 W, Standby) (under 0.3 W, Standby)
Under 92 W Under 92 W Under 134 W
46" 46" 46"
(under 0.3 W, Standby) (under 0.3 W, Standby) (under 0.3 W, Standby)
32" 319 cd/m2 32" 320 cd/m2 32" 286 cd/m2
Brightness 40" 328 cd/m2 40" 286 cd/m2 40" 318 cd/m2
46" 324 cd/m2 46" 313 cd/m2 46" 383 cd/m2
29.1*1.8*17.7 (inches) 29.1*3.7*17.5 (inches) 30.2*1.2*18.4 (inches)
without stand without stand without stand
32" 32" 32"
29.1*7.1*19.3 (inches) 29.1*7.6*19.6 (inches) 30.2*9.4*20.9 (inches)
with stand with stand with stand
36.5*1.8*21.8 (inches) 36.5*3.7*20.1 (inches) 37.6*1.2*22.6 (inches)
Dimensions without stand without stand without stand
40" 40" 40"
(W*D*H) 36.5*7.2*23.8 (inches) 36.5*9.8*23.9 (inches) 37.6*10.0*25.1 (inches)
with stand with stand with stand
41.8*1.8*24.8 (inches) 41.7*3.7*23.6 (inches) 43.0*1.2*25.6 (inches)
without stand without stand without stand
46" 46" 46"
41.8*9.0*26.9 (inches) 41.7*9.8*26.8 (inches) 43.0*10.8*28.1 (inches)
with stand with stand with stand
13.7 (lbs) without stand 12.8 (lbs) without stand 22.8 (lbs) without stand
32" 32" 32"
14.8 (lbs) with stand 14.3 (lbs) with stand 27.6 (lbs) with stand
22.8 (lbs) without stand 19.6 (lbs) without stand 24.4 (lbs) without stand
Weight 40" 40" 40"
27.6 (lbs) with stand 24.0 (lbs) with stand 31.7 (lbs) with stand
29.1 (lbs) without stand 26.9 (lbs) without stand 30.3 (lbs) without stand
46" 46" 46"
33.7 (lbs) with stand 31.3 (lbs) with stand 38.1 (lbs) with stand
Contrast Ratio Mega Contrast Mega Contrast Mega Contrast
Picture Enhancer HyperReal Engine (X10+) HyperReal Engine (X10+) HyperReal Engine (X6)
Equalizer 5 Band 5 Band 5 Band
Auto Volume Control O O O
Surround Sound Dolby Digital plus / Dolby Pulse Dolby Digital plus / Dolby Pulse Dolby Digital plus
Function Jog Function Jog Function Touch Function
Speaker Output 10W * 10W 10W * 10W 10W * 10W
PIP O (originally, inclueded function) O (originally, inclueded function) O
Antena DTV 1 (Cable/Air) DTV 1 (Cable/Air) DTV 1 (Cable/Air)
. Speci f i cat i on
Spec. Comparison Model
UE4K(UE26EH4500) UD5P(UE27D5000)
Direct LED LED
Design
Diplay Type LED TV 2D LED TV 2D
Built-in Tuner O O
Resolution 1366 x 768 1920 x 1080
LCD Panel TFT LCD Panel 60Hz TFT LCD Panel 60Hz
Picture ratio 16:9 16:9
Under 40 W Under 65 W
Power Consumption 26"
(under 0.3 W, Standby)
27"
(under 0.3 W, Standby)
Brightness 26" 257 cd/m2 27" 288 cd/m2
24.9*3.8*15.5 (inches) 23.7*1.4*15.5 (inches)
Dimensions without stand without stand
26" 27"
(W*D*H) 24.9*7.1*17.5 (inches) 23.7*6.9*17.8 (inches)
with stand with stand
9.3 (lbs) without stand 16.7 (lbs) without stand
Weight 26" 27"
10.4 (lbs) with stand 12.9 (lbs) with stand
Contrast Ratio Mega Contrast Mega Contrast
Picture Enhancer HyperReal Engine (X10+) HyperReal Engine (X5)
Equalizer 5 Band 5 Band
Auto Volume Control O O
Surround Sound Dolby Digital plus / Dolby Pulse Dolby Digital plus
Function Jog Function Touch Function
Speaker Output 5W * 5W 5W * 5W
PIP O (originally, inclueded function) O (originally, inclueded function)
Antena DTV 1 (Cable/Air) DTV 1 (Cable/Air)
. Speci f i cat i on
UE5M(UE22ES5400) UD5P(UE22D5000)
Spec. Comparison Model
Slim LED_small LED
Design
Diplay Type LED TV 2D LED TV 2D
Built-in Tuner O O
Resolution 1920 x 1080 1920 x 1080
LCD Panel TFT LCD Panel 60Hz TFT LCD Panel 60Hz
Picture ratio 16:9 16:9
Under 30 W Under 36 W
Power Consumption 22"
(under 0.3 W, Standby)
22"
(under 0.3 W, Standby)
Brightness 22" 270 cd/m2 22" 257 cd/m2
20.6*2.0*12.7 (inches) 20.2*2.0*12.4 (inches)
Dimensions without stand without stand
22" 22"
(W*D*H) 20.6*6.8*14.7 (inches) 20.2*6.3*14.3 (inches)
with stand with stand
7.9 (lbs) without stand 7.7 (lbs) without stand
Weight 22" 22"
7.5 (lbs) with stand 7.3 (lbs) with stand
Contrast Ratio Mega Contrast Mega Contrast
Picture Enhancer HyperReal Engine (X10+) HyperReal Engine (X5)
Equalizer 5 Band 5 Band
Auto Volume Control O O
Surround Sound Dolby Digital plus / Dolby Pulse Dolby Digital plus
Function Jog Function Touch Function
Speaker Output 3W * 3W 3W * 3W
PIP O (originally, inclueded function) O (originally, inclueded function)
Antena DTV 1 (Cable/Air) DTV 1 (Cable/Air)
. Desi gn
TV Controller
. Desi gn
Initial Setup
. Desi gn
Initial Setup
. Desi gn
Initial Setup
. Desi gn
Reset (Self Diagnosis)
When you want to initialize the TV setting, use the 'reset' menu
* Initial PIN number : '0-0-0-0`
(If you want change the PIN number, use the Change PIN function located 'System-Security'
menu.)
* After you execute 'Reset' function, All the settings will return to factory default.
. Desi gn
Connection (for more information, refer to Connecting the TV in the E-Manual)
According to Model, connection differ!!
. Desi gn
Connecting to a COMMON INTERFACE slot
. Desi gn
Changing the Input Source
. Desi gn
Network Connection
. Desi gn
Network Connection
. Desi gn
Display Resolution
. Desi gn
Remote Control(TM1250)
. Desi gn
Remote Control(TM1250)
I t al y ( M Onl y)
HP
. Desi gn
E5500/5700
Front
- Speakers
- IR Sensor
- Power Indicator
- Jog Function
. Desi gn
Rear -
UE32ES5500(5700)
. Desi gn
Rear ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
