Image preview - the first page of the document



>> Download Disassembly & Reassembly documenatation <<

Text preview - extract from the document

                                                                                       3. Disassembly and Reassemble

3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
    WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling these components.

3-1. Disassembly and Reassembly
   Cautions: 1. Disconnect the LED TV from the power source before disassembly.
             2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.

                 Description                                    Picture Description                         Screws
 1. Place TV face down on cushioned table.
    Remove screws from the Stand.
    Remove stand.




                                                                                                           6003-000133




 2. Remove the screws of rear-cover.                                       40"




                                                                                                           6003-000133




                                                                                                           6003-001003

                                                                       40"/46"/55"




                                                                                                           6003-001003




                                                                                                                    3-1
3. Disassembly and Reassemble


                  Description                               Picture Description    Screws
      Pull out a AC Power Cord.




3. Lift up the rear-cover.




4. Remove the cables and screws from
   SMPS, Main board and Woofer and
   Bracket stand link.



                                                                                  6001-002283




5. Remove the panel bracket screws from the
   panel.




 Reassembly procedures are in the reverse order of disassembly procedures.


3-2
