Image preview - the first page of the document
>> Download Wiring Diagram documenatation <<
Text preview - extract from the document
6-1
6. Wiring Diagram
Wooper
C N 1301_W
IP Board
C NM801 C N 201
C N 1401
Main
Board
C N 1302
C N 401
6. Wiring Diagram
6-1. Wiring Diagram
T-CON
32"/37"
Function & IR Speaker Speaker
Wooper
IP Board C N 1301_W
C NM801 C N 201
C N 1401
Main
C N 1302
C N 401
Board
T-CON
40"/46"/55" Speaker Speaker
6. Wiring Diagram
Function & IR
6-2
6. Wiring Diagram
6-2. Connector
CN1201(to Panel) CN2(POWER)
1 NC 42 Tx1_AN 1 B12V 10 GND
2 NC 43 GND 2 A5V 11 GND
3 NC 44 GND 3 B12V 12 B5V
4 NC 45 GND 4 GND 13 B13V
5 NC 46 NC TOP_PWM_
5 B5V 14
DIMMING
6 NC 47 PANEL_VCC_PW
6 B5V 15 B13V
7 GND 48 PANEL_VCC_PW
7 B5V 16 SW_INVERTER
8 SDA_PANEL2 49 PANEL_VCC_PW
8 GND 17 B13V
9 PANEL_WP 50 PANEL_VCC_PW
9 GND 18 DET_5V
10 NC 51 PANEL_VCC_PW
11 NC 52 GND CN3004(to Component)
12 SCL 53 TX2_AN 1 GND 5 NC
13 GND 54 TX2_AP 2 COMP_Y 6 NC
14 TX3_EP 55 TX2_BN 3 IDENT_COMP_1 7 COMP_PR
15 TX3_EN 56 TX2_BP 4 COMP_PB
16 TX3_DP 57 TX2_CN
CN3013(to HDMI1)
17 TX3_DN 58 TX2_CP
1 HDMI1_RX2+_HDMI 11 GND
18 GND 59 GND
2 GND 12 HDMI1_RXCLK-_HDMI
19 TX3_CLKN 60 TX2_CLKN
3 HDMI1_RX2-_HDMI 13 HDMI_CEC
20 TX3_CLKP 61 TX2_CLKP
4 HDMI1_RX1+_HDMI 14 GND
21 GND 62 GND
5 GND 15 HDMI1_SCL_DDC
22 TX3_CP 63 TX2_DN
6 HDMI1_RX1-_HDMI 16 HDMI1_SDA_DDC
23 TX3_CN 64 TX2_DP
7 HDMI1_RX0+_HDMI 17 GND
24 TX3_BP 65 TX2_EN
8 GND 18 HDMI1_5V
25 TX3_BN 66 TX2_EP
9 HDMI1_RX0-_HDMI 19 HDMI1_HPD
26 TX3_AP 67 GND
10 HDMI1_RXCLK+_HDMI
27 TX3_AN 68 TX4_AN
28 GND 69 TX4_AP
CN3016(to HDMI2)
1 HDMI2_RX2+_HDMI 11 GND
29 TX1_EP 70 TX4_BN
2 GND 12 HDMI2_RXCLK-_HDMI
30 TX1_EN 71 TX4_BP
3 HDMI2_RX2-_HDMI 13 HDMI_CEC
31 TX1_DP 72 TX4_CN
4 HDMI2_RX1+_HDMI 14 GND
32 TX1_DN 73 TX3_CP
5 GND 15 HDMI2_SCL_DDC
33 GND 74 GND
6 HDMI2_RX1-_HDMI 16 HDMI2_SDA_DDC
34 TX1_CLKP 75 TX4_CLKN
7 HDMI2_RX0+_HDMI 17 GND
35 TX1_CLKN 76 TX4_CLKP
8 GND 18 HDMI2_5V
36 GND 77 GND
9 HDMI2_RX0-_HDMI 19 HDMI2_HPD
37 TX1_CP 78 TX4_DN
10 HDMI2_RXCLK+_HDMI
38 TX1_CN 79 TX4_DP
39 TX1_BP 80 TX4_EN
40 TX1_BN 81 TX4_EP
41 TX1_AP 82 GND
6-3
6. Wiring Diagram
CN3015(to HDMI3) CN7502(USB1)
1 HDMI3_RX2+_HDMI 11 GND 1 USB0_5V_PW 3 USB0_DP
2 GND 12 HDMI3_RXCLK-_HDMI 2 USB0_DM 4 GND
3 HDMI3_RX2-_HDMI 13 HDMI_CEC
CN7501(USB2)
4 HDMI3_RX1+_HDMI 14 GND
1 USB1_5V_PW 3 USB1_DP
5 GND 15 HDMI3_SCL_DDC
2 USB1_DM 4 GND
6 HDMI3_RX1-_HDMI 16 HDMI3_SDA_DDC
CN4001(FUCTION)
7 HDMI3_RX0+_HDMI 17 GND
1 IR 6 KEY_INPUT1
8 GND 18 HDMI3_5V
2 GND 7 KEY_INPUT2
9 HDMI3_RX0-_HDMI 19 HDMI3_HPD
3 3.3V 8 LED_STB
10 HDMI3_RXCLK+_HDMI
4 MSCL_A5V 9 LED_CNTR
CN3010(to HDMI4) 5 MSDA_A5V 10 3.3V
1 HDMI4_RX2+_HDMI 11 GND
CN3002(Scart)-AV Jack
2 GND 12 HDMI4_RXCLK-_HDMI
1 GND 13 NC
3 HDMI4_RX2-_HDMI 13 HDMI_CEC
2 GND 14 SC1_G
4 HDMI4_RX1+_HDMI 14 GND
3 GND 15 GND
5 GND 15 HDMI4_SCL_DDC
4 GND 16 NC
6 HDMI4_RX1-_HDMI 16 HDMI4_SDA_DDC
5 SC1_AV_CVBS_IN 17 IDENT_SC1_AV
7 HDMI4_RX0+_HDMI 17 GND
6 GND 18 SC1_B
8 GND 18 HDMI4_5V
7 SC1_CVBS_OUT 19 GND
9 HDMI4_RX0-_HDMI 19 HDMI4_HPD
8 GND 20 SC1_AV_SL_IN
10 HDMI4_RXCLK+_HDMI
9 SC1_FB 21 SC1_AV_SR_IN
CN3011(to PC) 10 GND 22 GND
1 PC_RED 9 5V
11 SC1_R 23 SC1_SL_OUT
2 PC_GREEN 10 PC_IDENT
12 GND 24 SC1_SR_OUT
3 PC_BLUE 11 GND
4 GND 12 SDA
5 GND 13 PC_HS
6 GND 14 PC_VS
7 GND 15 SCL
8 GND
CN1301(Speaker Out)
1 R-_OUT 3 L-_OUT
2 R+_OUT 4 L+_OUT
OP3001(Optical Jack)
1 VIN 3 GND
2 VCC
CN3005(COMP)
1 GND 5 NC
2 AV2_CVBS 6 NC
3 INDENT_AV2 7 COMP_AV2_SL_IN
4 COMP_AV2_SR_IN
6-4
6. Wiring Diagram
6-3. Connector Functions
Connector Function
CN201 CN802
Supply main power and dimming signal from IP board to Main Board.
CN1401 CN505
The LVDS signal transfered from Main Board to Panel .
6-4. Cables
For common
Use Main IP (18P) Main - TCON
32" BN39-01267E (250mm) 32" BN96-12723J
40" BN39-01267N (225mm) 40" BN96-12723L
Code
46" BN39-01267N (225mm) 46" BN96-12723M
55" BN39-01267E (250mm) 55" BN96-12723N
6-5
