Image preview - the first page of the document
>> Download Samsung+UE32F6100AW+Chassis+U88A documenatation <<
Text preview - extract from the document
LED TV
Chassis : U88A
Model : UE32F6100AW
UE40F6100AW
UE46F6100AW
UE55F6100AW
SERVICE Manual
LED TV Contents
1. Precautions
2. Product specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UE**F6100AW
Contents
1. Precautions ...................................................................................................................1-1
1-1. Safety Precautions ..............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard .............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions ..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specifications.................................................................................................2-1
2-1. Product Specifications .........................................................................................................2-1
2-2. Detailed Specifications ........................................................................................................2-7
2-2-1. Model Comparison ...................................................................................................2-7
2-2-2. Feature & Specifications ...........................................................................................2-8
2-3. Accessories .......................................................................................................................2-12
2-4. Viewing the Functions ......................................................................................................2-13
2-4-1. Auto Motion Plus 120 Hz ........................................................................................2-13
2-4-2. Supported Formats .................................................................................................2-14
2-4-3. 3D Display ..............................................................................................................2-17
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
3-1-1. LED TV .....................................................................................................................3-1
3-1-2. ASSY BOARD P-RF-MODULE...............................................................................3-10
4. Troubleshooting ...........................................................................................................4-1
4-1. Troubleshooting ...................................................................................................................4-1
4-1-1. Previous Check ........................................................................................................4-1
4-1-2. Simple flow chart of malfunction ...............................................................................4-3
4-2. How to Check Fault Symptom .............................................................................................4-4
4-2-1. NO Power .................................................................................................................4-4
4-2-2. No Video (Tuner_CVBS) ..........................................................................................4-7
4-2-3. No Vido (Tuner DTV) ..............................................................................................4-10
4-2-4. No Video (Video AV) ...............................................................................................4-13
4-2-5. No Video (COMPONENT) ......................................................................................4-16
4-2-6. No Sound (1.Speaker 2.Monitor_out 3.Optical) ..................................................4-19
4-3. Factory Mode Adjustments ................................................................................................4-22
4-3-1. Detail Factory Option ..............................................................................................4-22
4-3-2. Entering Factory Mode ...........................................................................................4-23
4-3-3. Factory Data ...........................................................................................................4-24
4-4. White Balance ...................................................................................................................4-37
4-4-1. Calibration ..............................................................................................................4-37
4-4-2. Service Adjustment .................................................................................................4-37
4-4-3. Adjustment ..............................................................................................................4-38
4-5. AV Control Tabe .................................................................................................................4-39
4-6. Software Upgrade..............................................................................................................4-45
4-6-1. How to Check the Software Version .......................................................................4-45
4-6-2. How to Upgade Software ........................................................................................4-46
4-7. The Dimension ..................................................................................................................4-48
4-7-1. UE32F6100AW .......................................................................................................4-48
4-7-2. UE40F6100AW .......................................................................................................4-49
4-7-3. UE46F6100AW .......................................................................................................4-50
4-7-4. UE55F6100AW .......................................................................................................4-51
5. Wiring Diagram .............................................................................................................5-1
5-1. Wiring Diagram ....................................................................................................................5-1
5-2. Connector ............................................................................................................................5-2
5-3. Connector Functions ...........................................................................................................5-5
5-4. Cables .................................................................................................................................5-6
5-5. The types of module ............................................................................................................5-7
1. Precautions
1. Precautions
1-1. Safety Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
WARNING
1-1-2. Servicing the LED TV
1. When servicing the LED TV, Disconnect the AC line cord from the AC outlet.
2. It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
1. Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the
chassis and other metal parts in the monitor.
2. Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
3. Leakage Current Hot Check:
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
DEVICE
CURRENT
UNDER
TESTER
TEST
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER EARTH
PLUG AS REQUIRED) GROUND
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
WARNING Publication UL1410, 59.7).
4. With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit's AC switch first
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identified by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, fire and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.
1-2
1. Precautions
1-2. Servicing Precautions
An electrolytic capacitor installed with the wrong polarity might explode.
WARNING
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
CAUTION
If unforeseen circumstances create conflict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
NOTE
1-2-1. General Servicing Precautions
1. Always unplug the unit's AC power cord from the AC power source and disconnect the DC Power Jack before
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
2. Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
3. After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that
the area around the serviced part has not been damaged.
4. Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input
terminals and earphone jacks).
5. Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
6. Always connect a test instrument's ground lead to the instrument chassis ground before connecting the positive lead;
always remove the instrument's ground lead last.
1-3
1. Precautions
1-3. Static Electricity Precautions
Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
2. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent
accumulation of an electrostatic charge.
3. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESDs.
4. Use only a grounded-tip soldering iron to solder or desolder ESDs.
5. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can generate
electrical charges sufficient to damage ESDs.
6. Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
7. Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
CAUTION
8. Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or
lifting your foot from a carpeted floor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-4. Installation Precautions
1. For safety reasons, more than a people are required for carrying the product.
2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock.
3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature
may cause fire.
4. Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed
to moisture. Otherwise, it may cause a fire or electric shock.
5. Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause fire or electric
shock.
6. Keep the antenna far away from any high-voltage cables and install it firmly. Contact with the highvoltage cable or the
antenna falling over may cause fire or electric shock.
7. When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.
A rise in temperature within the product may cause fire.
1-5
2. Product specifications
2. Product Specifications
2-1. Product Specifications
Item UE**F6100AW
General Information Product LED
Cabinet Basic Code FP
Series 6
Series Name LED F6100
Country EU
Platform(TV) Novatek | NT13
Display Inch 32" / 40" / 46" / 55"
Resolution 1,920 x 1,080
Ultra Clear Panel No
Lvds Format JEIDA
HV Flip ON
Video Picture Engine 3D HyperReal Engine
Clear Motion Rate 480
Dynamic Contrast Ratio Mega Contrast
Micro Dimming Micro Dimming
Precision Black (Local Dimming) No
Wide Color Enhancer (Plus) Yes
Auto Motion Plus 120/240Hz 120Hz
Film Mode Yes
Brightness 300nits
Contrast Ratio 5000:1
Picture 3D-Effect, Film Mode, HDMI Black Level
Detail Resolution 60Hz
Response Time 8ms
Viewing Angle (H/V) 178/178
Natural Mode Support Yes
Audio Dolby Dolby Digital Plus / Dolby Pulse
SRS / DNSe+ SRS Theater Sound HD
dts 2.0+ Digital Out / DTS Premium Audio DTS Premium Audio
3D Sound Yes
Sound Customizer No
Speaker Type Down Firing + Full Range
Sound Output (RMS) 10W x 2
Woofer No
Sound Amp IC TI | TAS5745
2-1
2. Product specifications
Item UE**F6100AW
Audio Speaker Rated Power 10W x 2
Woofer Speaker Rated Power No
Analog 2Ch
Digital Optical
SMART TV Functionality Smart Hub No
Smart Guide No
Family Story No
Movie & TV Shows No
Fitness No
Apps No
Kids No
Social No
Music, Photos & Clip No
Samsung SMART View No
Your Video 2.0 No
Social TV No
Samsung Sports Experience (SSE) No
Samsung Apps No
Smart Scene No
SkypeTM on Samsung TV No
Web Browser No
AllShare Control No
Recommendation Bar No
VESA Standard Screw Size M8
Smart Interaction Camera Built-in No
Face Recognition No
Hand Gesture Recognition No
Voice Recognition (Embedded) No
Voice Recognition (Server) No
NLU (Natural Language Understanding) No
Camera App No
Samsung TV Apps supported No
Feature Samsung 3D Yes
3D Converter Yes
Dual View N/A
History Yes
Smart Phone Remote support No
Smart Evolution Support No
Extended PVR Yes
2-2
2. Product specifications
Item UE**F6100AW
Feature Time Shift Yes
Allshare Play No
ConnectShareTM (USB2.0) Movie
AllShare Cast No
RUI NO
RVU N/A
WiFi Direct No
Wireless LAN Built-in No
Wireless LAN Adaptor Support No
BT HID Built-in Yes
USB HID Support Yes
Network Speaker Support N/A
OSD Language 26 Europeanl Languages
Samsung IR Blaster Support No
User Interface Golden Bridge
Digital Noise Filter Yes
Analog Noise Filter N/A
MHL No
Sound Share Yes
WiDi N/A
InstaPort S (HDMI quick switch) No
HDMI 1.4 3D Auto Setting Yes
HDMI 1.4 A/Return Ch. Support Yes
EPG Yes
Teletext (TTX) Yes
Triple Protector N/A
Miracast Yes
Anynet+ (HDMI-CEC) Yes
BD Wise Plus Yes
Auto Channel Search Yes
Auto Power Off Yes
Auto Volume Leveler Yes
Caption (Subtitle) Yes
2 Tuner No
Clock&On/Off Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
2-3
2. Product specifications
Item UE**F6100AW
Feature V-Chip Yes
Embeded POP Yes
Channel Auto Store, Signal Level, Fine Tune
Plug&Play Yes
Child Lock Yes
Soccer Mode Yes
Kids Lock N/A
Media Play(USB & DLNA) Yes
Bluetooth Yes
ACS N/A
IP Video Closed Caption No
Additional Feature Self Diagnosis Yes
Software Upgrade Yes
HD Connection Guide Yes
Contact Samsung Yes
S/W MCU Name NT13
OS Linux
System DTV Tuner TC/T2C/TCS2/T2CS2
Analog Tuner Yes
CI/ CI+ CI+ (1.3)
DVB-T/C/S2 (UK and Nordic : T2/C/S2),
Broadcast System
PAL, SECAM, NT4.4
ATV Sound System BK, DK, NICAM, MPEG1
DVB-T/C/S2 (UK and Nordic : T2/C/S2),
DTV Video System
PAL, SECAM, NT4.4
DTV Sound System Dolby
Tuner Vendor & Model TC - SEM | DTOS40EIH035A
T2C - SEM | DNTS403EH105A
TCS2 - SEM | DNSS243IH105A
T2CS2 - SEM | DNTS243EH105A
Input & Output HDMI 2
Resolution 1920 x 1080
DVI Port Port1 Type
PC Max Resolution 1920 x 1080 | 60 Hz
USB 1
Port 1 Type Host
Port 2 Type No
Port 3 Type No
OS Linux
2-4
2. Product specifications
Item UE**F6100AW
Input & Output Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (Common Use for Component Y)
Ethernet (LAN) No
Headphone 1
Digital Audio Out (Optical) 1
Audio Out (Mini Jack / LR) No
PC In (D-sub) No
PC Audio In (Mini Jack) No
DVI Audio In (Mini Jack) 1
RF In (Terrestrial/Cable Input) 1
RF In (Satelite Input) 1
RS232C (AV CONTROL) No
SCART 1
CI Slot 1
Coaxial No
EX-Link No
Monitor Output No
DVI
Resolution 1920 x 1080i 60
DVI Port Port1 Type
PC Max Resolution 1920 x 1080 | 60 Hz
Design Design ToC
Bezel Type NNB
Slim Type Slim 1
Front Color Black
Light Effect (Deco) No
Stand Type Quad
Swivel (Left/Right) Yes
Emission ToC
Front Resin PC+G/F
Design Stand Packing Type Bundle
ECO Energy Efficiency Class TBD
Eco Mark EU Ecolabel
Eco Label Yes
Eco Sensor Yes
Security Kensington Lock Yes
Accessory 3D Active Glasses (Included) 2 (SSG-5100GB)
IR Blaster (Included) No
2-5
2. Product specifications
Item UE**F6100AW
Accessory Wireless LAN Adaptor (Included) No
Network Speaker (Included) No
MOIP Camera (Included) No
Wireless Keyboard (Included) No
Remote Controller Model TM1240
Battery (for Remote Control) Yes
Mini Wall Mount Support Yes
Ultra Slim Wall Mount Support No
VESA Wall Mount Support Yes
Slim Gender Cable No
ANT-Cable No
Power Cable Yes
User Manual Yes
E-Manual Yes
Floor Stand Support No
2-6
2. Product specifications
2-2. Detailed Specifications
2-2-1. Model Comparison
Model UE**F6100AW
W
Front View H
D
* W : Width H : High D : Depth
Detail View
Front Color Black
Set with Stand 743.8 x 508.7 x 191.7 mm
32"
Set without Stand 743.8 x 441.7 x 49.5 mm
Set with Stand 934 x 617.4 x 235 mm
40"
Dimensions Set without Stand 934 x 548.6 x 49.6 mm
(W x H x D) Set with Stand 1065.4 x 697.3 x 235 mm
46"
Set without Stand 1065.4 x 622.5 x 49.6 mm
Set with Stand 1256 x 798.6 x 235 mm
55"
Set without Stand 1256 x 729.3 x 19.2 mm
Set with Stand 5.8 kg
32"
Set without Stand 5.1 kg
Set with Stand 10.4 kg
40"
Set without Stand 8.7 kg
Weight
Set with Stand 13.1 kg
46"
Set without Stand 11.5 kg
Set with Stand 18.3 kg
55"
Set without Stand 16.9 kg
Panel Type Black
Internal Memory 4G
DDR 1G
Feature 3D / USB HID / DLNA / Full Browsing / Miracast
2-7
2. Product specifications
2-2-2. Feature & Specifications
Model UE32F6100AW
Feature
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
