Image preview - the first page of the document



>> Download 02_specifications documenatation <<

Text preview - extract from the document

                                                                                                    2. Product specifications

2. Product specifications
2-1. Product information
2-1-1. Model Comparison
                   Model                                                       UE7000L*




   Front view                All




                             All




   Detail view




                             All




   Front Color               All                                                U-T-CL-M

                           Without Stnand            908.6                         29.7                        524.9
                     40"
                            With Stand               908.6                        241.3                         600

  Dimensions               Without Stnand           1041.1                         29.7                        599.4
   WxDxH             46"
     (mm)                   With Stand              1041.1                        276.5                        607.5

                           Without Stnand           1232.6                         29.7                        707.2
                     55"
                             With Stand             1232.6                        309.3                        789.7

                           Without Stnand                                          10.0
                     40"
                            With Stand                                             12.0

                           Without Stnand                                          12.4
     Weight
                     46"
      (lbs)                 With Stand                                             14.3

                           Without Stnand                                          16.2
                     55"
                            With Stand                                             18.6

   Panel Type                All                                        TFT LCD PANEL 240 Hz

 Internal Memory             All                                                128 Mbtye

      DDR                    All                                                768 Mbtye

    Feature                  All            3D, MOIP, SMART HUB, Allshare, Internet TV, Built-in Wi-Fi, Full Browser, Bluetooth


                                                                                                                            2-1
2. Product specifications

2-1-2. Feature & Specifications
                Model                                                 UE40D7000L*

                                                         Feature

  Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V, 3-USB2.0(Media Play), D-SUB , LAN
  Brightness : Mega Contrast
  PIP(in HDMI 1, 2, 3, 4, Component 1, PC Mode and Sub picture is available only in TV mode(DTV/ATV))
  Dolby Digital+, SRS theater HD

                                                     Specifications

                Item                                                    Description
 LCD Panel                         40 inch HD 240 Hz
 Scanning Frequency                Horizontal : 67.5 KHz (typ)
                                   Vertical : 60 Hz (typ)
 Display Colors                    16.7M color
 Maximum resolution                Horizontal : 1920 Pixels
                                   Vertical : 1080 Pixels
 Input Signal                      Analog 0.7 Vp-p
