Image preview - the first page of the document
>> Download Product Specification documenatation <<Text preview - extract from the document 2. Product specifications
2. Product specifications
2-1. Model Comparison
Model UD6000SF UD6050TF UD6300SF
Front view All
All
Detail view
All
Front Color All Rose Black Rose Black Charcol Gray
Without Stnand 30.24 1.18 18.71
32"
With Stand 30.24 9.45 21.00
Without Stnand 37.74 1.18 22.86 37.74 1.18 22.67 37.74 1.18 22.86
40"
Dimensions With Stand 37.61 10.04 25.12 37.74 10.04 25.52 37.61 10.04 25.12
WxDxH
(inches) Without Stnand 42.94 1.18 22.86 43.08 1.18 25.69 42.94 1.18 22.86
46"
With Stand 42.94 10.83 28.11 43.08 10.83 28.18 42.94 10.83 28.11
Without Stnand 50.58 1.18 30.14 50.58 1.18 29.89 50.58 1.18 30.14
55"
With Stand 50.58 12.01 32.39 50.58 12.01 32.41 50.58 12.01 32.39
Without Stnand 15.87
32"
With Stand 21.83
Without Stnand 24.47 24.03 24.47
40"
Weight With Stand 31.75 31.97 31.75
(lbs) Without Stnand 30.86 30.64 30.86
46"
With Stand 38.80 38.36 38.80
Without Stnand 39.02 39.24 39.02
55"
With Stand 48.28 48.50 48.28
Panel Type All Super-Clear Super-Clear Super-Clear
Flash All 2G 2G 2G
DDR All 512 MB 512 MB 512 MB
3D / Internet@TV DLNA /
Feature All 3D / Internet@TV / DLNA 3D / Internet@TV / DLNA
Full browsing
2-1
2. Product specifications
2-2. Feature & Specifications
Model UN32D6000SF
Feature
Digital-TV, RF, 4-HDMI, 1-Component, 2-A/V, 3-USB2.0(Media Play), D-SUB , LAN
Contrast Ratio : Mega Contrast
Dynamic contrast , Super-PVA
PIP(in HDMI 1, 2, 3, 4, Component 1, PC Mode and Sub picture is available only in TV mode(DTV/ATV))
Dolby Digital+, SRS theater, DVIX HD
Specifications
Item Description
LCD Panel 32 inch FHD 120Hz
Scanning Frequency Horizontal : 120 kHz ~ 139.2 kHz (Automatic)
Vertical : 94 Hz ~ 122 Hz (Automatic)
Display Colors 1.07B
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p
