Image preview - the first page of the document



>> Download 01_Cover documenatation <<

Text preview - extract from the document

                                            SENS
                                            Q40
                                            RIMINI
                                            N -Q40




SERVICE                                                      Manual

If there are the contents not included in this book, please refer to K-zone service manual




                  SENS Q40                                      FEATURES



                                                   1. High performance Note pc

                                                   -. Intel Napa Platform with

                                                       Mobile Centrino Technology

                                                   -. High-Performance Single Core

                                                   2. Comvenient Management

                                                   -. 12.1" WXGA Super Bright Glare LCD

                                                   -. Port Replicator(X-Dock) support

                                                   -. AVS, SRS Sound, Bluetooth

                                                       4-in-1 Multi Card Slot, DMB
-          -
- This Document can not be used without Samsung's authorization -


                                         Table of Contents


1. Precaution
   1) General after sales Service Precautions
   2) Safely Precautions
   3) Ground
   4) Static Electricity Precautions


2. Introduction and Specification
    1) Introducion
    2) Specification
    3) Model Comparison
    4) Wireless LAN Specification
    5) Option list
    6) Separate sales list


3. Function
    1) Construction of system
    2) Key board
    3) Multi card slot
    4) PC card slot
    5) SPDIF Port
    6) DMB
    7) WLAN
    8) Description of Main board


4. Disassembly and Assembly
    1) Q40 Disassembly and Assembly


5. Troubleshooting
    1) General
    2) Debugging Flow Chart
    3) System Diagnosis
    4) H/W Troubleshooting
    5) Device settings Related S/W Diagnosis
    6) Thermal control
    7) Battery Use time


6. Exploded view(1)
    1) LCD Back Assy
    2) LCD Back Assy List
    3) LCD Main
    4) LCD Main List
    5) Housing Top Assy
    6) Housing Top Assy(List)
    7) System Main
    8) System Main(List)


7. Schematic
    1) SYSTEM
-          -
- This Document can not be used without Samsung's authorization -




8. System Block Diagram
    1) Block diagram

9. Exploded view(2)
    1) Q40 Top
    2) Q401 Bottom
    3) LCD

10. Part list
    1) SYSTEM

11. References
    1) Safety Notice
    2) Model Numbering Rule
    3) Glossary
    4) Hard Ware Upgrade
