Image preview - the first page of the document
>> Download Product Specification documenatation <<
Text preview - extract from the document
- This Document can not be used without Samsung's authorization -
2. Introduction and Specification
1) Product Characteristic
2- 1
- This Document can not be used without Samsung's authorization -
2- 2
- This Document can not be used without Samsung's authorization -
2. Introduction and Specification
2) Specification
Processor and Core Logic Q1 Ultra
CPU Intel Ultra Mobile Platform 2007
Intel Processor A100 (600MHz)
Speed
Intel Processor A110 (800MHz)
Cache 512KB L2 cache
Chipset Intel 945GU +ICH7M U
BIOS 8 Mbit, Flash (upgradable)
Thermal Design Performance MAX. 5W
Memory
Memory / Max. Memory 512MB / Max.1GB
Memory type PC2-4200(533MHz) SODIMM
Memory Modules Memory Modules 256MB, 512MB, 1GB SODIMM
Sockets 1 SODIMM Socket
Display and Graphics
LCD 7" WSVGA TFT LCD (Glare)
LCD Vendor SAMSUNG AMLCD
LCD Viewable Area 153.6(H) x 90.0(V) (7.0diagonal )
LCD Resolution 262,144
Pixel Pitch 0.150(H) x 0.150(V) (TYP.)
Contrast Ratio Typ 350:1
Brightness Typ 280 (cd/m2)
Response time Typ 30ms
Graphics Controller Intel Graphic Media Accelerator 950
Video Memory DVMT Max 128 MB
Audio
Sound High Definition Audio
Controller HD Audio Codec, ALC262
Conversion Built-in high performance 20-bit ADC & 24-bit DAC
Speaker Power Rating 2 Speakers x 1 Watt with enclosure each
External Interfaces Microphone, Headphone/ Optical S/PDIF out port
Controls Touch Burron volume control, SRS enable / disable
Output Impedance 2.2K
2- 3
- This Document can not be used without Samsung's authorization -
Storage
Hard Disk Drive 8mmH 1.8" SFF HDD
Supports SMART UltraDMA-33/66/100 support,DMA Mode 2/4, PIO Mode 4
Average Access Time 15m sec.
Speed 4200rpm
Capacity 8mm 60GB
Network Tools
LAN 10/100 Ethernet UTP
Chipset Broadcom BCM4401
Features RJ45 Output
802.11b/g Wireless LAN Askey Atheros AR5BXB61 : 802.11 b/g
Type Mini card
Chipset Atheros
Antenna Integrated 2 Antenna
Bluetooth BCM92045NMD
Type USB daughter card with integrated PIFA antenna
Chipset Broadcom BCM2045
Standard version 2.0
DMB Module SDM-2000 : Factory Option
- Type USB I/F
- Antenna Int. Cable & Ext. Rod Antenna
I/O Interface
Multi Card Slots 2 in 1 card slot
Controller ALCOR AU6371
I/O Ports
USB Port 2 (USB2.0)
Video Port VGA port (15 pin)
Audio Jacks HeadPhone-out, Array MIC-in
Modem / LAN RJ45
DMB Antenna Port 1 (Option)
Docking (Option)
Power 1(8.4pie)
Input Devices
Key pad
Sepcial Feature
AV Station
OS VISTA Embedded
Funtion DVD Player / MP3 player / Picture slide show
Boot-up time 18 sec(Including HDD Navigation)
Control Button Key Button
2- 4
- This Document can not be used without Samsung's authorization -
Power and Power Management
Battery (Standard) AA-PB1UC4B (4cells, Smart Li-Ion Battery)
- Dimension 12.35x8.15x1.7Cm
- Weight 210g (max)
- Recharge Time 2 hours to 100% with Windows on & off
- Battery Life over 3 hour ( Battery mark 4.01)
- Details of Cell 4cells (2Parallel 2Serial)
- Voltage 7.4Vdc
- Battery Capacity 2000mAh/cell
- Battery Rating 7.4V / 4000mAh (29.6Wh)
Battery (Long life) AA-PL1UC6B (6cells, Smart Li-Ion Battery)
- Dimension 12.35x8.15x2.3Cm
- Weight 360g (max)
- Recharge Time 3.5 hours to 100% with Windows on & off
- Battery Life over 7hour ( Battery mark 4.01)
- Details of Cell 6cells (3Parallel 3Serial)
- Voltage 7.4Vdc
- Battery Capacity 2600mAh/cell
- Battery Rating 7.4V / 7800mAh (57.72Wh)
AC Adapter AD-6019S
Output Power 60Watts
Dimension 108 X 47 X 28mm
Weight (AC Adapter) 270g (typ)
Worldwide Compatibility Auto-sensing 100 - 240VAC
Line Frequency 50 / 60Hz
Adapter Rating - Input 100V - 240V, 1.8A
Adapter Rating - Output 19.0VDC/3.16A
Power Management Features ACPI 1.0b support, Standby(S3), Hibernate(S4)
System Dimensions
Dimensions (W X D X H) 227.5 x 123.9 x 22.9 ~ 23.5 mm
Weight (Full system w/ 3Cell) Int : 669 g
Materials PC+ABS
2- 5
- This Document can not be used without Samsung's authorization -
2. Introduction and Specification
Section Q1 Ultra Q1
Feature
CPU Intel CPU 800 , 600 MHz Intel celeron M ULV 900 MHz(Dothan)
Chipse 945 GU 915GMS / ICH6M
Memory DDR II 533MHz (MAX 1G) DDRII 400MHz (MAX. 1GB)
Graphic Intel 945GMS GMA950(Internal) Intel 915GMS GMA900(Internal)
LCD 7" WSVGA with TSP 7" WVGA with TSP
Wireless 802.11 b/g, DMB, Bluetooth 802.11 b/g, DMB, Bluetooth
Lan 10/100 Mavell 88e8036, 10/100
HDD 1.8" SFF HDD(60G) 1.8" SFF HDD(40G)
ODD External ODD External ODD
2 USB, 1PC card, VGA, LAN, HP Jack, 2 USB, 1PC card, VGA, LAN, HP Jack,
Port
Array MIC, DC-in Array MIC, DC-in
4 Cell ,6 Cell 3 Cell(38.5 W, 3.5 hrs)/
Battery
Power Pack 8 Cell(77 W, 9 hrs) Power Pack 8 Cell(77 W, 9 hrs)
Dimension 227.5 x 123.9 x 22.9 ~ 23.5 mm 227.5 x 139.5 x 24.5 ~ 26.5 mm
Weight 699 g (Without Bluetooth, DMB) 779 g (Without Bluetooth, DMB)
2- 6
- This Document can not be used without Samsung's authorization -
4) Option material list
HDD
BA59-01906A 60GB (1.8") HDD;60G,MK6008GAH,S63,H16,D16385,H8.0mm
HDD FPC
BA41-00748A AFC FPC_MACAO_HDD_AFC
BA41-00752A CMI FPC_MACAO_HDD_CMI
T-Con FPC
BA41-00769A AFC FPC_MACAO_TCON_AFC
BA41-00751A CMI FPC_MACAO_TCON_CMI
2- 7
- This Document can not be used without Samsung's authorization -
MEMORY
1105-001611 1G(SEC) IC-DRAM MODULE ; M470T2953,DDR2,1GByte
1105-001784 1G(NANYA) IC-DRAM MODULE ; NT1GT64U8HB0BN-37B,DDR2,1GByte
Blue Tooth
BA59-01916A SEC MODULE-BLUETOOTH ; Bluetooth Version 2.0,BTO2P0B2SA
BA59-01691A Foxconn MODULE-BLUETOOTH ; Bluetooth V2.0,T60H928.01
DMB
BA59-01869A MBRIDGE DMB Module SDM-2000
2- 8
- This Document can not be used without Samsung's authorization -
LED FPC
BA41-00770A AFC FPC_MACAO_LED
BA41-00750A CMI FPC_MACAO_LED
HALL Mouse
BA32-00017A HALL_MOUSE2.1,MACAO
Key Pad FPC
BA41-00788A SMAC MACAO,0.1,FPC(2 Layer),12PIN,T0.2mm,-,Key pad FPC Left
BA41-00787A SMAC MACAO,0.1,FPC(2 Layer),12PIN,T0.2mm,-,Key pad FPC-Right
BA41-00747A AFC MACAO,0.1,FPC(2 Layer),12PIN,T0.2mm,Key pad FPC
BA41-00746A AFC MACAO,0.1,FPC(2 Layer),12PIN,T0.2mm,Key pad FPC
2- 9
- This Document can not be used without Samsung's authorization -
Sub R / L / Finger FFC
BA41-00735A Sub-L FFC
BA41-00737A SUB_R FFC
BA41-00736A F/P FFC
WLAN
BA59-01843A 802.11 b/g WLL3140-D99(MOW-ROHS, WMAC+RF, 11C
BA59-01842A 802.11 b/g WLL3140-D99(ROSH), WMAC+RF, 13C
Camera FPC
BA41-00771A AFC CAMERA_FPC
BA41-00773A CMI CAMERA_FPC
2- 10
- This Document can not be used without Samsung's authorization -
Toucj Sensor FPC
BA41-00772A AFC FPC_MACAO_TOUCHSENSOR
BA41-00749A CMI FPC_MACAO_TOUCHSENSOR
2- 11
- This Document can not be used without Samsung's authorization -
5) Separate sales material list
Power Bank Charge
AA-PL0UC8B / X Power Bank Charge & Extend Battery
ODD_12.7 mm
AA-EB2U12B / X 12.7 mm DVD Combo
AA-ES2U12B / X 12.7 mm DVD Super Multi
Car Cradle
AA-EX1UCAR/ X
2- 12
- This Document can not be used without Samsung's authorization -
WLAN
AA-PL1UC4B / X 6 Cell
GPS Receiver
AA-EX1UNAV / X GPS Receiver
Data Cable
AA-EX0TSYN / X 12.7 mm DVD Combo
CAR Adapter
AA-PC0NCAR / X Car Adapter
2- 13
- This Document can not be used without Samsung's authorization -
USB Key Board
AA-ST0TKBD / X USB Key Board
Pouch
AA-EX1UPOU / X Pouch
Q1 Ultra S/W Map
AA-EX1UMAP / X Q1Ultra S/W Map
2- 14
- This Document can not be used without Samsung's authorization -
6) Function of product
2- 15
- This Document can not be used without Samsung's authorization -
2- 16
- This Document can not be used without Samsung's authorization -
2- 17
- This Document can not be used without Samsung's authorization -
2- 18
- -
- This Document can not be used without Samsung's authorization -
2- 19
- -
- This Document can not be used without Samsung's authorization -
2- 20
- -
- This Document can not be used without Samsung's authorization -
2- 21
