Text preview - extract from the document

- This Document can not be used without Samsung's authorization -




8. Exploded view(2)



   1. Housing Front
                Assemble spec                              Checking list


                                               Check Silk print
    1.   FPC Touch-sensor
                                               No gap between FPC Touch-
    2.   FPC LED
                                              sensor and Top
    3.   MIC
                                               No gap between FPC LED and Top
    4.   BUTTON-UDF
                                               Care about the assemble MIC
    5.   SUB B'D LEFT
                                              Cable.




   2. Housing Front (FPC Assy)




                                           8- 1
- This Document can not be used without Samsung's authorization -




   2. Housing Front (MIC Assy)




   3. Key Pad Spec




                                           8- 2
- This Document can not be used without Samsung's authorization -




   3. FPC Keypad + Bracket Keypad assemble




   3. Bracket Keypad Housing Front assemble




                                           8- 3
- This Document can not be used without Samsung's authorization -




   4. Housing Front + Bluetooth Assemble




   5. Finger print Assemble




                                           8- 4
- This Document can not be used without Samsung's authorization -




   6. Finger print Assemble




   7. Housing Front + Sub Board Right Assemble 1




                                           8- 5
- This Document can not be used without Samsung's authorization -




   8. Housing Front + Sub Board Right Assemble 2




   9. LCD Module Assemble 1




                                           8- 6
- This Document can not be used without Samsung's authorization -




   10. LCD Module Assemble 2




   11. LCD Module Assemble 3




                                           8- 7
- This Document can not be used without Samsung's authorization -




   12. LCD Module Assemble 4




   13. Housing Front + LCD Module Assemble




                                           8- 8
- This Document can not be used without Samsung's authorization -




   14. Housing Front + Camera module Assemble




   15. Cable Assemble




                                           8- 9
- This Document can not be used without Samsung's authorization -




   16. Right FFC Assemble




   17. Shield LCD Assemble




                                          8- 10
- This Document can not be used without Samsung's authorization -




   18. RTC Battery Assemble




   19. Main Board Assemble 1




                                          8- 11
- This Document can not be used without Samsung's authorization -




   20. Main Board Assemble 2




   21. Main Board Assemble 3




                                          8- 12
- This Document can not be used without Samsung's authorization -




   22. Main Board Assemble 4




   22. Main Board Assemble 5




                                          8- 13
- This Document can not be used without Samsung's authorization -




   23. HDD & Mic Assemble




   24. Housing Back Assemble




                                          8- 14
- This Document can not be used without Samsung's authorization -




   25. Battery Assemble 1




   26. Battery Assemble 2




                                          8- 15
- This Document can not be used without Samsung's authorization -




   27. Battery Assemble 3




                                          8- 16
