Image preview - the first page of the document
06_Disassembly & Reassembly


>> Download 06_Disassembly & Reassembly documenatation <<

Text preview - extract from the document
1. Make sure to separate the AC adapter and
battery before disassembling the system.

2. Slide the knob all the way to the end in the
direction of the arrows (1) and push the battery
in the direction of the arrows (2).




4. Remove the screws from the bottom.




5. Remove the HDD compartment cover.

6. Remove the memory compartment cover.

7.Remove the minicard compartment cover.
8. When removing the HDD compartment cover,
you will find the HDD. Separate the HDD cable
and lift up the HDD at an angle of 70
