Image preview - the first page of the document
NP-R410-FA02RU_SM_EN_20080508185811453_05_Disassembly_and_Ressembly


>> Download NP-R410-FA02RU_SM_EN_20080508185811453_05_Disassembly_and_Ressembly documenatation <<

Text preview - extract from the document
- This document cannot be used without Samsung's authorization -




3. Disassembly and Reassembly

3-1. Disassembly and Reassembly of R410
  Part
                        Figure                                     Description
 Name

                                               1. Must remove AC Adapter and Battery when
                                               disassembling system.

                                               2. Then, slide buttons in direction of red
                                               arrows No.1, then push battery in direction of
                                               No.2.




                                               3. Have Battery with pushing Battery upward.




  Main
 System
                                               4. Remove Bottom Screws.
                                                   - M2.6xL8 : 18 EA (RED)
                                                   - M2xL4 : 5 EA (GREEN)




                                               5. Separate HDD DOOR and remove HDD Door.




                                             3-1
- This document cannot be used without the authorization of Samsung -




3. Disassembly and Reassembly
  Part
                        Figure                                   Description
 Name

                                               6. Pull Insulator of HDD to 70
