Image preview - the first page of the document



>> Download NP-R70A001_SER_SM_EN_20070602092538656_01_Cover documenatation <<

Text preview - extract from the document

                                           R70
                                           OSLO
                                           NT-R70xxxx/xxx
                                           NP-R70xxxx/xxx




SERVICE                                                    Manual


                   R70                                          Features


                                                  1. Essential functions

                                                     - 15.4" Wide display,

                                                         Internal Camera, HDMI

                                                  2. New Technology

                                                     - Intel Santarosa, MS Vista

                                                        nVIDIA Geforce 8000 series




If there are the Contents not included in this book, please refer to K-zone Service Manual
- This Document can not be used without Samsung's authorization -




- Contents -

1. Precations
  1)    General After-Sales Service Precautions -------------------------- 1-1
  2)    Safety Precautions ---------------------------------------------------------- 1-2
  3)    Ground -------------------------------------------------------------------------- 1-3
  4)    Static Electricity Precautions ------------------------------------------- 1-3

2. Introduction and Specification
   1)   Introduction ------------------------------------------------------------------- 2-1
   2)   Specification ------------------------------------------------------------------ 2-2
   3)   Specification comparison between R55 and R70. ------------- 2-8
   4)   Option list --------------------------------------------------------------------- 2-9
   5)   New Added Function ------------------------------------------------------- 2-12
   6)   System Setup (BIOS Setup) --------------------------------------------- 2-17
   7)   Mainboard part Description ----------------------------------------------- 2-25

3. Disassembly and Reassembly
   1) Disassembly and Reassembly R70 ---------------------------------- 3-1

4. Troubleshooting
   1)   General ------------------------------------------------------------------------- 4-1
   2)   Debugging Flow Chart ----------------------------------------------------- 4-2
   3)   System Diagnosis ----------------------------------------------------------- 4-5
   4)   Hardware Troubleshooting ----------------------------------------------- 4-9
   5)   Driver and Application SW List----------------------------------------- 4-17
   6)   CPU Fan Control ------------------------------------------------------------ 4-18
   7)   Battery Use Time ----------------------------------------------------------- 4-19
   8)   etc --------------------------------------------------------------------------------- 4-24

5. Exploded view
   1) Exoloed view of R70 ------------------------------------------------------- 5-1

6. Material List
   1) Material List--------------------------------------------------------------------- 6-1

7. System Wire Diagram
   1) System Wire Diagram ------------------------------------------------------ 7-1

8. Block Diagram and Schematic
   1) Block Diagram ---------------------------------------------------------------- 8-2
   2) Schematic ---------------------------------------------------------------------- 8-1
