Image preview - the first page of the document
>> Download NP-R70A001_SER_SM_EN_20070602092538656_07_Wiring_Diagram documenatation <<
Text preview - extract from the document
- This Document can not be used without Samsung's authorization -
7. System Wire Diagram
1) Top
Left speaker
Right speaker
Speaker Cable
Touchpad FFC
MIC Assy
7- 1
- This Document can not be used without Samsung's authorization -
7. System Wire Diagram
2) Bottom
MDC cable
connector to MDC
(J3)
Camera
Connector (J2)
LCD connector
(J1)
MDC cable
connector to
RJ11 (J4)
Speaker
Touchpad FFC Keyboard connector
connector (J7)
connector (J6) (J9)
Internal MIC
connector (J8)
Bluetooth
connector (J10)
MDC modem
card
MDC modem cable
Bluetooth cable
LCD cable
Camera cable
7- 2
- This Document can not be used without Samsung's authorization -
7. System Wire Diagram
3) LCD
Camera cable
connector on
camera board
LCD connector
on LCD panel
Inverter connector
Inverter board
Camera cable
Antenna cable Main
LCD Cable
Antenna cable Aux
Antenna cable MIMO
7- 3
