Image preview - the first page of the document



>> Download Disassembly documenatation <<

Text preview - extract from the document

- This document cannot be used without Samsung's authorization -




3. Disassembly and Reassembly

3-1. Disassembly and Reassembly of R700
  Part
                        Figure                                     Description
 Name

                                               1. Must remove AC Adapter and Battery when
                                               disassembling system.
                                               2. After push knobs to end forward to red
                                               arrows and red mark No.1, Push Battery like red
                                               mark No.2.




                                               3. Have Battery with pushing Battery upward.




  Main
 System


                                               4. Remove Bottom Screws.
                                                   - M2.6xL8 : 18 EA (RED)
                                                   - M2xL4 : 3 EA (GREEN)




                                               5. Separate HDD DOOR

                                               6. Separate MEMORY / MINICARD DOOR.




                                             3-1
- This document cannot be used without the authorization of Samsung -




3. Disassembly and Reassembly

  Part
                        Figure                                    Description
 Name
                                               7. You can see HDD, removing Door-HDD,
                                               And, Pick Insulator and pull it toward to 70
