Image preview - the first page of the document
>> Download samsung r50 documenatation <<
Text preview - extract from the document
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(1) Slide both of the latches
outwards and pull the battery
in the direction of the arrow.
BATTERY
(1) Loosen the screw and pull
the ODD in the direction of
the arrow.
ODD
(1) Loosen the 2 screws from
the HDD compartment cover
and pull the cover in the
direction of the arrow to lift
the cover up.
HDD
SENS R50 23
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(2) Pull the left and right
hooks of the connector
forward to lift the HDD.
HDD
(1) Insert a screw driver into
the groove at the back and lift
it up in the direction of the
arrow. (Apply this step to both
the left and right sides.)
Main
System
24 SENS R50
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(2) Loosen the 15 screws at
the bottom of the computer.
(3) Release the 2 hooks
below the keyboard using a
screwdriver.
Main
System
(4) Lift the keyboard up and
slightly pull the keyboard
forward. Turn the keyboard
over.
SENS R50 25
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(4) Lift the keyboard up and
slightly pull the keyboard
forward. Turn the keyboard
over.
(5) Separate all cables.
Main
System
(6) Remove the cover and
pull out the aerial cable.
26 SENS R50
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(6) Remove the cover and
pull out the aerial cable.
(7) Loosen the 2 screws and
pull the LCD out.
Main (8) Loosen the screw and lift
System the back end of the main
board forward slowly.
SENS R50 27
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(9) Loosen the five screws.
Main
System (10) Lift the bottom end of
the main board slightly to
separate the board
completely.
(1) Separate the USB board
by pulling the USB board in
the direction of the arrow
USB SUB from the disassembled main
BOARD board.
(1) Push the hooks in the
directions of the two arrows.
(2) Pull the Mini PCI in the
MINI PCI direction of the arrow.
CARD
28 SENS R50
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(1) Slide both of the latches
outwards and pull the battery
in the direction of the arrow.
(2) Loosen the 4 screws.
LCD
ASSY
(3) Remove the cover and
pull out the aerial cable.
SENS R50 29
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(4) Loosen the 2 screws and
pull out the LCD.
(5) Separate the 5 rubber
parts.
LCD
(6) Loosen the screws that
ASSY
were under the rubber parts.
(7) Lift the LCD panel up
slowly from the bottom end
with your hand.
30 SENS R50
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(8) Loosen the 4 screws.
(9) Lift the LCD up holding
the edge of the LCD with your
hand.
LCD
ASSY
SENS R50 31
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(10) Loosen the 8 screws on
both sides holding the edge
of the LCD.
LCD
ASSY
(11) Separate the bracket
and turn the LCD over.
32 SENS R50
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(12) Pull the end of the cable
on the lower part in the
direction of the arrow to
separate the cable from the
inverter board.
(13) Separate the LCD cable
from the inverter board by
pulling each of them in the
LCD direction of the respective
ASSY arrows.
(14) Pull the LCD cable in the
direction of the arrow to
separate it from the LCD.
SENS R50 33
.
This Document can not be used without Samsung's authorization.
4. DISASSEMBLE & ASSEMBLE
Part Pictures Descriptions
(1) Loosen the screw on the
memory compartment cover
and remove the cover.
(2) Pull the hooks outward.
MEMORY
(3) Separate the memory
card by holding one side of
the card.
34 SENS R50
