Image preview - the first page of the document
samsung r510


>> Download samsung r510 documenatation <<

Text preview - extract from the document
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                3-1. Disassembly and Reassembly R510
                                                                                           [Caution] Attention to red sentence.

                     Part                     Picture                                        Description

                                                                         1. Before disassembling, the AC adaptor and Battery
                                      2                     2               must be separated.
                                                                         2. AS mark No.1/2 put KNOB-Battery to end of each
                                                                            side, then pull the battery upward like outward




                                          1             1




                                                                         3. After removing the Battery




                    Main
                   System                                                4. ODD and DOOR-HDD, DOOR-Memory Screw
                                                                            Remove.
                                                                            M2 X L4, Black (4EA)

                                                                           - Yellow ( ): ODD Screw
                                                                           - Skyblue ( ): HDD Door Screw
                                                                           - Red ( ): Minicard Door Screw




                                                                         5. HDD DOOR Remove,
                                                                            MEMORY DOOR Remove
                                                                            ODD Remove




                                                                  3-1




3_Disassembly and Reassembly_eng1 1
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                    Part                     Picture                                          Description

                                                                          6. Separate HDD by pulling in the arrow direction.


                                                                          * Cautions
                                                                            Avoid lifting HDD excessively, because Connector
                                                                            can be damaged.




                                                                          7. ODD Remove
                                                       1




                                                                2



                                                       1

                    Main
                   System
                                                                          8. Bottom Screw Remove

                                                                            - Yellow( ): M2 X L4, Black (4EA)
                                                                            - Skyblue( ): M2.6 X L8, Black (17EA)
                                                                            - Red( ): M2 X L6, (2EA)




                                                                          9. Push two keyboard hooks fixing a keyboard in the
                                                                             arrow direction

                                                                          * Caution
                                                                            When using a tool, be careful not to scratch the
                                                                            surface of Top and not to be hurt




                                                                    3-2




3_Disassembly and Reassembly_eng2 2
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                     Part                    Picture                                          Description

                                                                         10. When seperating the keyboard hook, use a tweeze,
                                                                             wood cutter or "-"screwdriver.

                                                                         * Caution
                                                                           Keyboard is connected to FPC, thus lift a little bit
                                                                           until FPC appear.




                                                                         11. Lift up the cover of connector connected FPC
                                                                             of keyboard, and then pull out FPC, separate the
                                                                             keyboard.


                                                                         * Caution
                                                                           Avoid pulling the keyboard excessively at this time as
                                                                           the keyboard connector can become detached.




                    Main
                   System
                                                                         12. Separate 3 CABLE from TOP ASSY
                                                                             (TOUCH_PAD / SPEAKER / MIC Cable)




                                                                         13. Separate two cables for disassembling Top.
                                                                             (Audio / MIC.)




                                                                  3-3




3_Disassembly and Reassembly_eng3 3
            -          -
            - This Document can not be used without Samsung's authorization -



            3. Disassembly and Reassembly

                Part                     Picture                                       Description

                                                                     14.   FPC Connector  TouchPad
                                                                         FPC .




                                                                     15. And Then Remove TOP ASSY by lift up




               Main
              System
                                                                     16. Wireless LAN Card Bluetooth Main Board
                                                                         .




                                                                     17. Remove cables connected to Wireless LAN Card,
                                                                         remove screw and LAN Card.




                                                              3-4




C(MWEWWIQFP]ERH6IEWWIQFP]CIRK
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                     Part                    Picture                                       Description

                                                                         18.   Bluetooth Connector
                                                                              Bluetooth Cable , Screw
                                                                             Bluetooth Module .

                                                                            M2 X L4, Black (1EA)




                                                                         19. LCD Ass'y Main System
                                                                                2 Cable .




                    Main
                   System
                                                                         20.    Camera Cable LCD Cable
                                                                              .




                                                                         21. To separate LCD ASSY Remove 1 ,2 Screw




                                                                  3-5




3_Disassembly and Reassembly_eng5 5
            -          -
            - This Document can not be used without Samsung's authorization -



            3. Disassembly and Reassembly

                Part                     Picture                                         Description

                                                                     22. ASSY LCD and Bottom sys.




                                                                     23. Remove Dummy Card in the direction of arrow.




               Main
              System
                                                                     24. Lift up Main board following direction.




                                                                     25. BOTTOM




                                                              3-6




C(MWEWWIQFP]ERH6IEWWIQFP]CIRK
            -          -
            - This Document can not be used without Samsung's authorization -



            3. Disassembly and Reassembly

                Part                     Picture                                         Description

                                                                     26. Remove screws for separating FAN and Heat
                                                                         sink.


                                                                        - Yellow ( ): Screw (6EA)
                                                                        - Red ( ): M2 X L4, Black (2EA)




                                                                     27. Remove FAN CONNECTOR




               Main
              System




                                                                     28. separating FAN and Heat sink.




                                                                     29. Turn the screwdriver in the direction of anti-
                                                                         clockwise and open CPU socket.




                                                              3-7




C(MWEWWIQFP]ERH6IEWWIQFP]CIRK
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                     Part                    Picture                                         Description

                                                                         30. Hold up CPU.




                                                                         31. Remove rubber-LCD-Cap & Screw on the LCD
                                                                             front.



                                                                         * Caution
                                                                         When using a tool, be careful not to scratch
                                                                         the surface of Top and not to be hurt.




                                                                         32.   6  Screw .
                                                                             M2 X L6 (6EA)




                                                                  3-8




3_Disassembly and Reassembly_eng8 8
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                     Part                    Picture                                         Description

                                                                         33. Separate LCD Front by twisting inside to outside
                                                                             like picture.


                                                                         * Caution
                                                                         When removing LCD Front, avoid twisting
                                                                         too strongly. If not, it can be bant.




                                                                         34. Remove 4 screw in the Hinge




                     LCD
                                                                         35. Hinge L, R
                    Ass'y




                                                                         36. LCD Panel Ass'y   INVERTER BD
                                                                               Screw .
                                                                             M2 X L5 (1EA)




                                                                  3-9




3_Disassembly and Reassembly_eng9 9
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                    Part                     Picture                                        Description

                                                                         37. Separate Hinge and LCD-Panel like picture




                                                                         38. Screw 2 , Bracket .




                     LCD
                    Ass'y




                                                                         39.   CAMERA MODULE CABLE
                                                                             .




                                                                  3-10




3_Disassembly and Reassembly_eng10 10
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                    Part                     Picture                                   Description

                                                                         40.   Wireless LAN Antenna Cable .




                     LCD
                    Ass'y                                                41. LCD Panel Ass'Y Cable
                                                                             LCD-Back




                                                                         42. LCD Panel Ass'Y




                                                                  3-11




3_Disassembly and Reassembly_eng11 11
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                     Part                    Picture                                    Description

                                                                           43.   6 Screw , Bracket
                                                                               -LCD _L, R .
                                                                               M2 * L5 (6 EA)




                                                                           44.    LCD CABLE INVERTER BD
                                                                               .




                     LCD
                     Ass'y                                                 45. 1, 2   Tape ,
                                                                                 LCD Cable
                                                         1




                                                                2




                                                                           46. LCD CABLE INVERTER cable
                                                                               LCD Panel




                                                                    3-12




3_Disassembly and Reassembly_eng12 12
                -          -
                - This Document can not be used without Samsung's authorization -



                3. Disassembly and Reassembly

                    Part                     Picture                                        Description

                                                                         LCD panel




                                                                         47. Remove Speaker & Mic.




                     LCD
                    Ass'y




                                                                         48. Taking care of removing Touchpad FPC, remove
                                                                             Shield of Touchpad. After that, remove Touchpad
                                                                             FPC.


                                                                         * Caution
                                                                           Touchpad module is fixed using by tape on Top.




                                                                  3-13
