Image preview - the first page of the document
>> Download Electrical documenatation <<
Text preview - extract from the document
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code Construction Place impartiality quantity Pummyeong Unit
0202-001498 1.0 PBA E 1 SOLDER-WIRE FLUX G
0203-001869 KAP_MDC CABLE E 0.04 TAPE-KAPTONE M
0204-000124 PBA CLEANING E 0.017 ETHANOL KG
0204-001105 SOLDERING MACHINE E 0.001 FLUX KG
0401-000132 D8 V 1 DIODE-SWITCHING PC
0401-000132 D9 V 1 DIODE-SWITCHING PC
0401-000191 D502 V 1 DIODE-SWITCHING PC
0401-000191 D508 V 1 DIODE-SWITCHING PC
0402-001405 D512 V 1 DIODE-SCHOTTKY PC
0402-001405 D513 V 1 DIODE-SCHOTTKY PC
0403-001047 ZD500 V 1 DIODE-ZENER PC
0404-001020 D515 V 1 DIODE-SCHOTTKY PC
0404-001084 D13 V 1 DIODE-SCHOTTKY PC
0404-001084 D6 V 1 DIODE-SCHOTTKY PC
0404-001084 D509 V 1 DIODE-SCHOTTKY PC
0404-001084 D510 V 1 DIODE-SCHOTTKY PC
0404-001084 D518 V 1 DIODE-SCHOTTKY PC
0404-001084 D520 V 1 DIODE-SCHOTTKY PC
0404-001382 D511 V 1 DIODE-SCHOTTKY PC
0501-000465 Q26 V 1 TR-SMALL SIGNAL PC
0501-000465 Q27 V 1 TR-SMALL SIGNAL PC
0501-000465 Q510 V 1 TR-SMALL SIGNAL PC
0501-000465 Q520 V 1 TR-SMALL SIGNAL PC
0502-001226 U2 V 1 TR-POWER PC
0502-001226 U507 V 1 TR-POWER PC
0504-001157 Q516 V 1 TR-DIGITAL PC
0505-000279 Q11 V 1 FET-SILICON PC
0505-000279 Q12 V 1 FET-SILICON PC
0505-000279 Q17 V 1 FET-SILICON PC
0505-000279 Q19 V 1 FET-SILICON PC
0505-000279 Q23 V 1 FET-SILICON PC
0505-000279 Q25 V 1 FET-SILICON PC
0505-001049 Q513 V 1 FET-GAAS PC
0505-001049 Q535 V 1 FET-GAAS PC
0505-001049 Q536 V 1 FET-GAAS PC
0505-001173 Q509 V 1 FET-SILICON PC
0505-001173 Q531 V 1 FET-SILICON PC
0505-001852 Q13 V 1 FET-SILICON PC
0505-001852 Q16 V 1 FET-SILICON PC
0505-001852 Q18 V 1 FET-SILICON PC
0505-001852 Q22 V 1 FET-SILICON PC
0505-001852 Q24 V 1 FET-SILICON PC
0505-001861 Q1 V 1 FET-SILICON PC
0505-001883 Q2 V 1 FET-SILICON PC
0505-001883 Q21 V 1 FET-SILICON PC
0505-001883 Q6 V 1 FET-SILICON PC
0505-001883 Q8 V 1 FET-SILICON PC
0505-001883 Q504 V 1 FET-SILICON PC
0505-001883 Q505 V 1 FET-SILICON PC
0505-001883 Q508 V 1 FET-SILICON PC
0505-001883 Q512 V 1 FET-SILICON PC
0505-001883 Q514 V 1 FET-SILICON PC
0505-001883 Q515 V 1 FET-SILICON PC
0505-001883 Q518 V 1 FET-SILICON PC
0505-001883 Q519 V 1 FET-SILICON PC
0505-001883 Q523 V 1 FET-SILICON PC
0505-001883 Q524 V 1 FET-SILICON PC
0505-001883 Q526 V 1 FET-SILICON PC
6-1
6_Material List_eng.indd 1
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code Construction Place impartiality quantity Pummyeong Unit
0505-001883 Q530 V 1 FET-SILICON PC
0505-002183 Q5 V 1 FET-SILICON PC
0505-002183 U3 V 1 FET-SILICON PC
0505-002183 U4 V 1 FET-SILICON PC
0505-002183 Q532 V 1 FET-SILICON PC
0505-002189 Q20 V 1 FET-SILICON PC
0505-002189 Q28 V 1 FET-SILICON PC
0505-002189 Q29 V 1 FET-SILICON PC
0505-002189 Q30 V 1 FET-SILICON PC
0505-002189 Q7 V 1 FET-SILICON PC
0505-002189 Q9 V 1 FET-SILICON PC
0505-002189 Q533 V 1 FET-SILICON PC
0505-002189 Q534 V 1 FET-SILICON PC
0601-002037 LED1 V 1 LED PC
0601-002037 LED2 V 1 LED PC
0601-002037 LED3 V 1 LED PC
0601-002037 LED4 V 1 LED PC
0601-002037 LED5 V 1 LED PC
0601-002037 LED6 V 1 LED PC
0601-002037 LED8 V 1 LED PC
0601-002391 LED7 V 1 LED PC
0801-002478 U523 V 1 IC-CMOS LOGIC PC
0801-002628 U501 V 1 IC-CMOS LOGIC PC
0801-002998 U505 V 1 IC-CMOS LOGIC PC
0801-002998 U506 V 1 IC-CMOS LOGIC PC
0903-001439 U9 V 1 IC-MICROCOMPUTER PC
0904-002225 U11 V 1 IC-BUS CONTROLLER PC
0904-002377 U509 V 1 IC-DRAM CONTROLLER PC
0904-002378 U513 V 1 IC-I/O CONTROLLER PC
1006-001427 U518 V 1 IC-BUS TRANSCEIVER PC
1009-001010 U1 V 1 IC-HALL EFFECT S/W PC
1103-001333 U504 V 1 IC-EEPROM PC
1107-001600 U511 V 1 IC-NOR FLASH PC
1201-001991 U515 V 1 IC-AUDIO AMP PC
1203-002364 U510 V 1 IC-RESET PC
1203-003344 U520 V 1 IC-POSI.FIXED REG. PC
1203-003765 U522 V 1 IC-PWM CONTROLLER PC
1203-004471 U508 V 1 IC-PWM CONTROLLER PC
1203-004685 U5 V 1 IC-PWM CONTROLLER PC
1203-004687 U521 V 1 IC-PWM CONTROLLER PC
1203-005009 U512 V 1 IC-PWM CONTROLLER PC
1205-002596 U500 V 1 IC-SWITCH PC
1205-002596 U502 V 1 IC-SWITCH PC
1205-002807 U516 V 1 IC-SWITCH PC
1205-003091 U503 V 1 IC-ETHERNET CONTROLLER PC
1205-003156 U10 V 1 IC-CLOCK GENERATOR PC
1205-003404 U519 V 1 IC-CODEC PC
1209-001718 U6 V 1 IC-SENSOR PC
1404-001089 TH500 V 1 THERMISTOR-PTC PC
1404-001152 R560 V 1 THERMISTOR-NTC PC
2007-000070 R30 V 1 R-CHIP PC
2007-000070 R31 V 1 R-CHIP PC
2007-000070 R65 V 1 R-CHIP PC
2007-000070 R644 V 1 R-CHIP PC
2007-000070 R662 V 1 R-CHIP PC
2007-000070 R663 V 1 R-CHIP PC
2007-000070 R692 V 1 R-CHIP PC
2007-000070 R722 V 1 R-CHIP PC
6-2
6_Material List_eng.indd 2
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code
2007-000070 R741 V 1 R-CHIP PC
2007-000070 R743 V 1 R-CHIP PC
2007-000070 R744 V 1 R-CHIP PC
2007-000070 R745 V 1 R-CHIP PC
2007-000070 R756 V 1 R-CHIP PC
2007-000082 R183 V 1 R-CHIP PC
2007-000082 R558 V 1 R-CHIP PC
2007-000141 R178 V 1 R-CHIP PC
2007-000141 R179 V 1 R-CHIP PC
2007-000141 R199 V 1 R-CHIP PC
2007-000141 R209 V 1 R-CHIP PC
2007-000141 R218 V 1 R-CHIP PC
2007-000141 R520 V 1 R-CHIP PC
2007-000141 R521 V 1 R-CHIP PC
2007-000141 R527 V 1 R-CHIP PC
2007-000141 R528 V 1 R-CHIP PC
2007-000141 R529 V 1 R-CHIP PC
2007-000141 R530 V 1 R-CHIP PC
2007-000141 R723 V 1 R-CHIP PC
2007-000141 R726 V 1 R-CHIP PC
2007-000141 R728 V 1 R-CHIP PC
2007-000143 R141 V 1 R-CHIP PC
2007-000143 R18 V 1 R-CHIP PC
2007-000143 R202 V 1 R-CHIP PC
2007-000143 R203 V 1 R-CHIP PC
2007-000143 R206 V 1 R-CHIP PC
2007-000143 R21 V 1 R-CHIP PC
2007-000143 R22 V 1 R-CHIP PC
2007-000143 R518 V 1 R-CHIP PC
2007-000143 R519 V 1 R-CHIP PC
2007-000143 R531 V 1 R-CHIP PC
2007-000143 R588 V 1 R-CHIP PC
2007-000143 R656 V 1 R-CHIP PC
2007-000143 R670 V 1 R-CHIP PC
2007-000143 R732 V 1 R-CHIP PC
2007-000147 R247 V 1 R-CHIP PC
2007-000148 R19 V 1 R-CHIP PC
2007-000148 R204 V 1 R-CHIP PC
2007-000148 R205 V 1 R-CHIP PC
2007-000148 R524 V 1 R-CHIP PC
2007-000148 R772 V 1 R-CHIP PC
2007-000148 R776 V 1 R-CHIP PC
2007-000157 R250 V 1 R-CHIP PC
2007-000157 R760 V 1 R-CHIP PC
2007-000170 R256 V 1 R-CHIP PC
2007-000170 R678 V 1 R-CHIP PC
2007-000170 R780 V 1 R-CHIP PC
2007-000171 R10 V 1 R-CHIP PC
2007-000171 R11 V 1 R-CHIP PC
2007-000171 R17 V 1 R-CHIP PC
2007-000171 R2 V 1 R-CHIP PC
2007-000171 R201 V 1 R-CHIP PC
2007-000171 R210 V 1 R-CHIP PC
2007-000171 R24 V 1 R-CHIP PC
2007-000171 R244 V 1 R-CHIP PC
2007-000171 R3 V 1 R-CHIP PC
2007-000171 R8 V 1 R-CHIP PC
2007-000171 R9 V 1 R-CHIP PC
6-3
6_Material List_eng.indd 3
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code Construction Place impartiality quantity Pummyeong Unit
2007-000171 R92 V 1 R-CHIP PC
2007-000171 R542 V 1 R-CHIP PC
2007-000171 R586 V 1 R-CHIP PC
2007-000171 R616 V 1 R-CHIP PC
2007-000171 R621 V 1 R-CHIP PC
2007-000171 R648 V 1 R-CHIP PC
2007-000171 R659 V 1 R-CHIP PC
2007-000171 R674 V 1 R-CHIP PC
2007-000171 R675 V 1 R-CHIP PC
2007-000171 R766 V 1 R-CHIP PC
2007-000171 R774 V 1 R-CHIP PC
2007-000171 R779 V 1 R-CHIP PC
2007-000171 R796 V 1 R-CHIP PC
2007-000173 R541 V 1 R-CHIP PC
2007-000173 R543 V 1 R-CHIP PC
2007-000173 R544 V 1 R-CHIP PC
2007-000173 R545 V 1 R-CHIP PC
2007-000174 R215 V 1 R-CHIP PC
2007-000503 R546 V 1 R-CHIP PC
2007-000695 R189 V 1 R-CHIP PC
2007-000695 R249 V 1 R-CHIP PC
2007-000695 R52 V 1 R-CHIP PC
2007-000695 R61 V 1 R-CHIP PC
2007-000695 R537 V 1 R-CHIP PC
2007-000695 R605 V 1 R-CHIP PC
2007-000695 R759 V 1 R-CHIP PC
2007-000695 R763 V 1 R-CHIP PC
2007-000758 R618 V 1 R-CHIP PC
2007-000882 R43 V 1 R-CHIP PC
2007-000882 R60 V 1 R-CHIP PC
2007-000882 R554 V 1 R-CHIP PC
2007-000882 R784 V 1 R-CHIP PC
2007-000969 R36 V 1 R-CHIP PC
2007-000969 R735 V 1 R-CHIP PC
2007-001139 R549 V 1 R-CHIP PC
2007-001139 R734 V 1 R-CHIP PC
2007-001292 R241 V 1 R-CHIP PC
2007-001313 R135 V 1 R-CHIP PC
2007-001313 R255 V 1 R-CHIP PC
2007-001313 R567 V 1 R-CHIP PC
2007-001313 R568 V 1 R-CHIP PC
2007-002425 R83 V 1 R-CHIP PC
2007-002425 R84 V 1 R-CHIP PC
2007-002425 R97 V 1 R-CHIP PC
2007-002425 R562 V 1 R-CHIP PC
2007-002425 R606 V 1 R-CHIP PC
2007-002899 R175 V 1 R-CHIP PC
2007-002899 R180 V 1 R-CHIP PC
2007-002899 R184 V 1 R-CHIP PC
2007-002899 R185 V 1 R-CHIP PC
2007-002899 R789 V 1 R-CHIP PC
2007-002899 R790 V 1 R-CHIP PC
2007-002899 R791 V 1 R-CHIP PC
2007-002899 R792 V 1 R-CHIP PC
2007-002899 R602 V 1 R-CHIP PC
2007-002899 R633 V 1 R-CHIP PC
2007-002899 R634 V 1 R-CHIP PC
2007-002899 R636 V 1 R-CHIP PC
6-4
C1EXIVMEP0MWXCIRKMRHH
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code
2007-002899 R748 V 1 R-CHIP PC
2007-002899 R749 V 1 R-CHIP PC
2007-002899 R750 V 1 R-CHIP PC
2007-002899 R765 V 1 R-CHIP PC
2007-002900 R793 V 1 R-CHIP PC
2007-002900 R631 V 1 R-CHIP PC
2007-002900 R668 V 1 R-CHIP PC
2007-002900 R671 V 1 R-CHIP PC
2007-002910 R26 V 1 R-CHIP PC
2007-002910 R41 V 1 R-CHIP PC
2007-002910 R700 V 1 R-CHIP PC
2007-002910 R737 V 1 R-CHIP PC
2007-002918 R68 V 1 R-CHIP PC
2007-002918 R797 V 1 R-CHIP PC
2007-002970 R100 V 1 R-CHIP PC
2007-002970 R101 V 1 R-CHIP PC
2007-002970 R102 V 1 R-CHIP PC
2007-002970 R103 V 1 R-CHIP PC
2007-002970 R104 V 1 R-CHIP PC
2007-002970 R105 V 1 R-CHIP PC
2007-002970 R106 V 1 R-CHIP PC
2007-002970 R107 V 1 R-CHIP PC
2007-002970 R108 V 1 R-CHIP PC
2007-002970 R109 V 1 R-CHIP PC
2007-002970 R110 V 1 R-CHIP PC
2007-002970 R111 V 1 R-CHIP PC
2007-002970 R112 V 1 R-CHIP PC
2007-002970 R113 V 1 R-CHIP PC
2007-002970 R114 V 1 R-CHIP PC
2007-002970 R115 V 1 R-CHIP PC
2007-002970 R116 V 1 R-CHIP PC
2007-002970 R117 V 1 R-CHIP PC
2007-002970 R118 V 1 R-CHIP PC
2007-002970 R119 V 1 R-CHIP PC
2007-002970 R120 V 1 R-CHIP PC
2007-002970 R121 V 1 R-CHIP PC
2007-002970 R122 V 1 R-CHIP PC
2007-002970 R123 V 1 R-CHIP PC
2007-002970 R124 V 1 R-CHIP PC
2007-002970 R125 V 1 R-CHIP PC
2007-002970 R126 V 1 R-CHIP PC
2007-002970 R127 V 1 R-CHIP PC
2007-002970 R128 V 1 R-CHIP PC
2007-002970 R129 V 1 R-CHIP PC
2007-002970 R130 V 1 R-CHIP PC
2007-002970 R131 V 1 R-CHIP PC
2007-002970 R132 V 1 R-CHIP PC
2007-002970 R133 V 1 R-CHIP PC
2007-002970 R134 V 1 R-CHIP PC
2007-002970 R152 V 1 R-CHIP PC
2007-002970 R153 V 1 R-CHIP PC
2007-002970 R154 V 1 R-CHIP PC
2007-002970 R155 V 1 R-CHIP PC
2007-002970 R156 V 1 R-CHIP PC
2007-002970 R157 V 1 R-CHIP PC
2007-002970 R158 V 1 R-CHIP PC
2007-002970 R159 V 1 R-CHIP PC
2007-002970 R160 V 1 R-CHIP PC
6-5
6_Material List_eng.indd 5
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code Construction Place impartiality quantity Pummyeong Unit
2007-002970 R161 V 1 R-CHIP PC
2007-002970 R162 V 1 R-CHIP PC
2007-002970 R163 V 1 R-CHIP PC
2007-002970 R164 V 1 R-CHIP PC
2007-002970 R165 V 1 R-CHIP PC
2007-002970 R166 V 1 R-CHIP PC
2007-002970 R167 V 1 R-CHIP PC
2007-002970 R168 V 1 R-CHIP PC
2007-002970 R176 V 1 R-CHIP PC
2007-002970 R177 V 1 R-CHIP PC
2007-002970 R80 V 1 R-CHIP PC
2007-002970 R98 V 1 R-CHIP PC
2007-002970 R99 V 1 R-CHIP PC
2007-002970 R584 V 1 R-CHIP PC
2007-002970 R599 V 1 R-CHIP PC
2007-002970 R607 V 1 R-CHIP PC
2007-002970 R608 V 1 R-CHIP PC
2007-002970 R610 V 1 R-CHIP PC
2007-007046 R35 V 1 R-CHIP PC
2007-007046 R547 V 1 R-CHIP PC
2007-007100 R198 V 1 R-CHIP PC
2007-007107 R242 V 1 R-CHIP PC
2007-007107 R248 V 1 R-CHIP PC
2007-007107 R32 V 1 R-CHIP PC
2007-007107 R33 V 1 R-CHIP PC
2007-007107 R42 V 1 R-CHIP PC
2007-007107 R45 V 1 R-CHIP PC
2007-007107 R508 V 1 R-CHIP PC
2007-007107 R509 V 1 R-CHIP PC
2007-007107 R576 V 1 R-CHIP PC
2007-007107 R581 V 1 R-CHIP PC
2007-007107 R617 V 1 R-CHIP PC
2007-007107 R622 V 1 R-CHIP PC
2007-007107 R658 V 1 R-CHIP PC
2007-007107 R669 V 1 R-CHIP PC
2007-007107 R727 V 1 R-CHIP PC
2007-007107 R736 V 1 R-CHIP PC
2007-007108 R47 V 1 R-CHIP PC
2007-007131 R245 V 1 R-CHIP PC
2007-007131 R764 V 1 R-CHIP PC
2007-007142 R140 V 1 R-CHIP PC
2007-007142 R142 V 1 R-CHIP PC
2007-007142 R145 V 1 R-CHIP PC
2007-007142 R188 V 1 R-CHIP PC
2007-007142 R191 V 1 R-CHIP PC
2007-007142 R192 V 1 R-CHIP PC
2007-007142 R194 V 1 R-CHIP PC
2007-007142 R200 V 1 R-CHIP PC
2007-007142 R207 V 1 R-CHIP PC
2007-007142 R208 V 1 R-CHIP PC
2007-007142 R216 V 1 R-CHIP PC
2007-007142 R221 V 1 R-CHIP PC
2007-007142 R222 V 1 R-CHIP PC
2007-007142 R223 V 1 R-CHIP PC
2007-007142 R224 V 1 R-CHIP PC
2007-007142 R226 V 1 R-CHIP PC
2007-007142 R227 V 1 R-CHIP PC
2007-007142 R228 V 1 R-CHIP PC
6-6
6_Material List_eng.indd 6
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code
2007-007142 R229 V 1 R-CHIP PC
2007-007142 R230 V 1 R-CHIP PC
2007-007142 R231 V 1 R-CHIP PC
2007-007142 R232 V 1 R-CHIP PC
2007-007142 R233 V 1 R-CHIP PC
2007-007142 R234 V 1 R-CHIP PC
2007-007142 R235 V 1 R-CHIP PC
2007-007142 R236 V 1 R-CHIP PC
2007-007142 R237 V 1 R-CHIP PC
2007-007142 R240 V 1 R-CHIP PC
2007-007142 R46 V 1 R-CHIP PC
2007-007142 R48 V 1 R-CHIP PC
2007-007142 R53 V 1 R-CHIP PC
2007-007142 R55 V 1 R-CHIP PC
2007-007142 R56 V 1 R-CHIP PC
2007-007142 R57 V 1 R-CHIP PC
2007-007142 R58 V 1 R-CHIP PC
2007-007142 R63 V 1 R-CHIP PC
2007-007142 R64 V 1 R-CHIP PC
2007-007142 R70 V 1 R-CHIP PC
2007-007142 R73 V 1 R-CHIP PC
2007-007142 R74 V 1 R-CHIP PC
2007-007142 R75 V 1 R-CHIP PC
2007-007142 R76 V 1 R-CHIP PC
2007-007142 R534 V 1 R-CHIP PC
2007-007142 R565 V 1 R-CHIP PC
2007-007142 R580 V 1 R-CHIP PC
2007-007142 R582 V 1 R-CHIP PC
2007-007142 R594 V 1 R-CHIP PC
2007-007142 R595 V 1 R-CHIP PC
2007-007142 R596 V 1 R-CHIP PC
2007-007142 R609 V 1 R-CHIP PC
2007-007142 R613 V 1 R-CHIP PC
2007-007142 R614 V 1 R-CHIP PC
2007-007142 R624 V 1 R-CHIP PC
2007-007142 R628 V 1 R-CHIP PC
2007-007142 R630 V 1 R-CHIP PC
2007-007142 R642 V 1 R-CHIP PC
2007-007142 R655 V 1 R-CHIP PC
2007-007142 R661 V 1 R-CHIP PC
2007-007142 R677 V 1 R-CHIP PC
2007-007142 R706 V 1 R-CHIP PC
2007-007142 R710 V 1 R-CHIP PC
2007-007142 R711 V 1 R-CHIP PC
2007-007142 R712 V 1 R-CHIP PC
2007-007142 R713 V 1 R-CHIP PC
2007-007142 R714 V 1 R-CHIP PC
2007-007142 R717 V 1 R-CHIP PC
2007-007226 R146 V 1 R-CHIP PC
2007-007226 R54 V 1 R-CHIP PC
2007-007226 R510 V 1 R-CHIP PC
2007-007226 R511 V 1 R-CHIP PC
2007-007226 R512 V 1 R-CHIP PC
2007-007226 R513 V 1 R-CHIP PC
2007-007226 R514 V 1 R-CHIP PC
2007-007226 R515 V 1 R-CHIP PC
2007-007226 R516 V 1 R-CHIP PC
2007-007226 R517 V 1 R-CHIP PC
6-7
C1EXIVMEP0MWXCIRKMRHH
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code Construction Place impartiality quantity Pummyeong Unit
2007-007226 R665 V 1 R-CHIP PC
2007-007226 R785 V 1 R-CHIP PC
2007-007226 R786 V 1 R-CHIP PC
2007-007226 R787 V 1 R-CHIP PC
2007-007226 R788 V 1 R-CHIP PC
2007-007239 R254 V 1 R-CHIP PC
2007-007274 R253 V 1 R-CHIP PC
2007-007274 R533 V 1 R-CHIP PC
2007-007302 R81 V 1 R-CHIP PC
2007-007302 R587 V 1 R-CHIP PC
2007-007302 R589 V 1 R-CHIP PC
2007-007302 R689 V 1 R-CHIP PC
2007-007306 R44 V 1 R-CHIP PC
2007-007306 R85 V 1 R-CHIP PC
2007-007306 R535 V 1 R-CHIP PC
2007-007306 R539 V 1 R-CHIP PC
2007-007306 R555 V 1 R-CHIP PC
2007-007306 R570 V 1 R-CHIP PC
2007-007306 R573 V 1 R-CHIP PC
2007-007306 R592 V 1 R-CHIP PC
2007-007306 R627 V 1 R-CHIP PC
2007-007306 R691 V 1 R-CHIP PC
2007-007307 R13 V 1 R-CHIP PC
2007-007307 R14 V 1 R-CHIP PC
2007-007307 R15 V 1 R-CHIP PC
2007-007307 R86 V 1 R-CHIP PC
2007-007307 R87 V 1 R-CHIP PC
2007-007307 R89 V 1 R-CHIP PC
2007-007312 R1 V 1 R-CHIP PC
2007-007312 R182 V 1 R-CHIP PC
2007-007312 R243 V 1 R-CHIP PC
2007-007312 R39 V 1 R-CHIP PC
2007-007312 R66 V 1 R-CHIP PC
2007-007312 R71 V 1 R-CHIP PC
2007-007312 R551 V 1 R-CHIP PC
2007-007312 R553 V 1 R-CHIP PC
2007-007312 R559 V 1 R-CHIP PC
2007-007312 R583 V 1 R-CHIP PC
2007-007312 R585 V 1 R-CHIP PC
2007-007312 R649 V 1 R-CHIP PC
2007-007312 R724 V 1 R-CHIP PC
2007-007312 R733 V 1 R-CHIP PC
2007-007312 R752 V 1 R-CHIP PC
2007-007312 R754 V 1 R-CHIP PC
2007-007318 R137 V 1 R-CHIP PC
2007-007318 R147 V 1 R-CHIP PC
2007-007318 R149 V 1 R-CHIP PC
2007-007318 R151 V 1 R-CHIP PC
2007-007318 R169 V 1 R-CHIP PC
2007-007318 R196 V 1 R-CHIP PC
2007-007318 R38 V 1 R-CHIP PC
2007-007318 R79 V 1 R-CHIP PC
2007-007318 R505 V 1 R-CHIP PC
2007-007318 R600 V 1 R-CHIP PC
2007-007318 R601 V 1 R-CHIP PC
2007-007318 R629 V 1 R-CHIP PC
2007-007318 R637 V 1 R-CHIP PC
2007-007318 R647 V 1 R-CHIP PC
6-8
6_Material List_eng.indd 8
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code
2007-007318 R664 V 1 R-CHIP PC
2007-007318 R667 V 1 R-CHIP PC
2007-007318 R695 V 1 R-CHIP PC
2007-007318 R705 V 1 R-CHIP PC
2007-007318 R709 V 1 R-CHIP PC
2007-007318 R729 V 1 R-CHIP PC
2007-007318 R751 V 1 R-CHIP PC
2007-007318 R755 V 1 R-CHIP PC
2007-007334 R181 V 1 R-CHIP PC
2007-007334 R25 V 1 R-CHIP PC
2007-007334 R69 V 1 R-CHIP PC
2007-007334 R522 V 1 R-CHIP PC
2007-007489 R40 V 1 R-CHIP PC
2007-007489 R523 V 1 R-CHIP PC
2007-007489 R640 V 1 R-CHIP PC
2007-007549 R16 V 1 R-CHIP PC
2007-007549 R673 V 1 R-CHIP PC
2007-007642 R197 V 1 R-CHIP PC
2007-007642 R557 V 1 R-CHIP PC
2007-007642 R619 V 1 R-CHIP PC
2007-007642 R620 V 1 R-CHIP PC
2007-007642 R623 V 1 R-CHIP PC
2007-007642 R704 V 1 R-CHIP PC
2007-007697 R561 V 1 R-CHIP PC
2007-007766 R170 V 1 R-CHIP PC
2007-007766 R62 V 1 R-CHIP PC
2007-007766 R77 V 1 R-CHIP PC
2007-007766 R720 V 1 R-CHIP PC
2007-007766 R721 V 1 R-CHIP PC
2007-007792 R78 V 1 R-CHIP PC
2007-007796 R632 V 1 R-CHIP PC
2007-007796 R635 V 1 R-CHIP PC
2007-007946 R20 V 1 R-CHIP PC
2007-007946 R538 V 1 R-CHIP PC
2007-007946 R563 V 1 R-CHIP PC
2007-007946 R672 V 1 R-CHIP PC
2007-008007 R591 V 1 R-CHIP PC
2007-008015 R4 V 1 R-CHIP PC
2007-008015 R5 V 1 R-CHIP PC
2007-008015 R6 V 1 R-CHIP PC
2007-008015 R7 V 1 R-CHIP PC
2007-008015 R88 V 1 R-CHIP PC
2007-008015 R90 V 1 R-CHIP PC
2007-008015 R91 V 1 R-CHIP PC
2007-008032 R49 V 1 R-CHIP PC
2007-008032 R746 V 1 R-CHIP PC
2007-008223 R798 V 1 R-CHIP PC
2007-008223 R638 V 1 R-CHIP PC
2007-008223 R753 V 1 R-CHIP PC
2007-008293 R12 V 1 R-CHIP PC
2007-008293 R212 V 1 R-CHIP PC
2007-008293 R213 V 1 R-CHIP PC
2007-008293 R767 V 1 R-CHIP PC
2007-008293 R768 V 1 R-CHIP PC
2007-008293 R769 V 1 R-CHIP PC
2007-008293 R770 V 1 R-CHIP PC
2007-008293 R771 V 1 R-CHIP PC
2007-008293 R773 V 1 R-CHIP PC
6-9
6_Material List_eng.indd 9
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code Construction Place impartiality quantity Pummyeong Unit
2007-008293 R777 V 1 R-CHIP PC
2007-008293 R781 V 1 R-CHIP PC
2007-008294 R136 V 1 R-CHIP PC
2007-008294 R211 V 1 R-CHIP PC
2007-008294 R219 V 1 R-CHIP PC
2007-008294 R59 V 1 R-CHIP PC
2007-008294 R757 V 1 R-CHIP PC
2007-008302 R95 V 1 R-CHIP PC
2007-008302 R96 V 1 R-CHIP PC
2007-008303 R172 V 1 R-CHIP PC
2007-008303 R186 V 1 R-CHIP PC
2007-008304 R34 V 1 R-CHIP PC
2007-008304 R50 V 1 R-CHIP PC
2007-008304 R795 V 1 R-CHIP PC
2007-008304 R597 V 1 R-CHIP PC
2007-008304 R794 V 1 R-CHIP PC
2007-008314 R171 V 1 R-CHIP PC
2007-008314 R187 V 1 R-CHIP PC
2007-008314 R569 V 1 R-CHIP PC
2007-008314 R571 V 1 R-CHIP PC
2007-008314 R572 V 1 R-CHIP PC
2007-008314 R574 V 1 R-CHIP PC
2007-008314 R612 V 1 R-CHIP PC
2007-008330 R214 V 1 R-CHIP PC
2007-008330 R239 V 1 R-CHIP PC
2007-008330 R651 V 1 R-CHIP PC
2007-008330 R652 V 1 R-CHIP PC
2007-008330 R679 V 1 R-CHIP PC
2007-008330 R680 V 1 R-CHIP PC
2007-008330 R681 V 1 R-CHIP PC
2007-008330 R682 V 1 R-CHIP PC
2007-008330 R683 V 1 R-CHIP PC
2007-008330 R684 V 1 R-CHIP PC
2007-008330 R685 V 1 R-CHIP PC
2007-008330 R686 V 1 R-CHIP PC
2007-008330 R687 V 1 R-CHIP PC
2007-008330 R688 V 1 R-CHIP PC
2007-008330 R702 V 1 R-CHIP PC
2007-008359 R150 V 1 R-CHIP PC
2007-008359 R548 V 1 R-CHIP PC
2007-008400 R590 V 1 R-CHIP PC
2007-008429 R148 V 1 R-CHIP PC
2007-008429 R556 V 1 R-CHIP PC
2007-008429 R639 V 1 R-CHIP PC
2007-008429 R641 V 1 R-CHIP PC
2007-008429 R730 V 1 R-CHIP PC
2007-008676 R550 V 1 R-CHIP PC
2007-008708 R138 V 1 R-CHIP PC
2007-008708 R139 V 1 R-CHIP PC
2007-008708 R525 V 1 R-CHIP PC
2007-008708 R526 V 1 R-CHIP PC
2203-000233 C10 V 1 C-CER,CHIP PC
2203-000233 C183 V 1 C-CER,CHIP PC
2203-000233 C26 V 1 C-CER,CHIP PC
2203-000233 C66 V 1 C-CER,CHIP PC
2203-000233 C9 V 1 C-CER,CHIP PC
2203-000233 C525 V 1 C-CER,CHIP PC
2203-000233 C555 V 1 C-CER,CHIP PC
6-10
6_Material List_eng.indd 10
- -
- This Document can not be used without Samsung's authorization -
6. Material List
Part Code
2203-000233 C556 V 1 C-CER,CHIP PC
2203-000233 C617 V 1 C-CER,CHIP PC
2203-000233 C620 V 1 C-CER,CHIP PC
2203-000233 C627 V 1 C-CER,CHIP PC
2203-000233 C628 V 1 C-CER,CHIP PC
2203-000278 C27 V 1 C-CER,CHIP PC
2203-000278 C526 V 1 C-CER,CHIP PC
2203-000278 C608 V 1 C-CER,CHIP PC
2203-000330 C127 V 1 C-CER,CHIP PC
2203-000330 C128 V 1 C-CER,CHIP PC
2203-000330 C129 V 1 C-CER,CHIP PC
2203-000386 C16 V 1 C-CER,CHIP PC
2203-000386 C17 V 1 C-CER,CHIP PC
2203-000405 C682 V 1 C-CER,CHIP PC
2203-000425 C28 V 1 C-CER,CHIP PC
2203-000425 C315 V 1 C-CER,CHIP PC
2203-000425 C316 V 1 C-CER,CHIP PC
2203-000425 C351 V 1 C-CER,CHIP PC
2203-000425 C352 V 1 C-CER,CHIP PC
2203-000425 C370 V 1 C-CER,CHIP PC
2203-000425 C371 V 1 C-CER,CHIP PC
2203-000425 C527 V 1 C-CER,CHIP PC
2203-000438 C224 V 1 C-CER,CHIP PC
2203-000438 C236 V 1 C-CER,CHIP PC
2203-000438 C237 V 1 C-CER,CHIP PC
2203-000438 C249 V 1 C-CER,CHIP PC
2203-000438 C250 V 1 C-CER,CHIP PC
2203-000438 C253 V 1 C-CER,CHIP PC
2203-000438 C274 V 1 C-CER,CHIP PC
2203-000438 C286 V 1 C-CER,CHIP PC
2203-000438 C287 V 1 C-CER,CHIP PC
2203-000438 C296 V 1 C-CER,CHIP PC
2203-000438 C357 V 1 C-CER,CHIP PC
2203-000438 C359 V 1 C-CER,CHIP PC
2203-000438 C62 V 1 C-CER,CHIP PC
2203-000438 C79 V 1 C-CER,CHIP PC
2203-000438 C93 V 1 C-CER,CHIP PC
2203-000◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
