Image preview - the first page of the document
>> Download Product Specification documenatation <<
Text preview - extract from the document
Product Specification
2. Product Specification
2-1 Product Specification
Features
Block Specification Major IC Remark
RF Tuner TDHG6-K02A ALPS
PDP Module Samsung SDI W2A 42"HD/50"HD SAMSUNG SDI
Power Input Voltage: AC 100~240V, 50/60Hz
Scaler
Video MST69981 MSTAR
Video Decoder
Sound AMP NTP3000 Neo Fidelity
Sound
Audio CODEC SGTV5810
Cabinet C6 Design
Specification
Model PS-42C67HD PS-50C67HD
Screen Size 42 Inches (16:9) 50 Inches (16:9)
Dimensions (WxHxD) 1155 x 440 x 878 mm (With Stand) 1355 x 460 x 984 mm (With Stand)
Weight 42.8 kg (With Stand) 53.9 kg (With Stand)
Voltage AC 100~240V, 50/60Hz
Colour System PAL, SECAM, NTSC4.43, NTSC 3.58
Sound System BG, DK, I, M
PC Resolution 1024 x 768 @ 85Hz 1365 x 768 @ 60Hz
ANTENNA input AIR IN (75 unbalanced)
SCART1, SCART2
COMPONENT IN (480i/P, 576i/P, 720P, 1080i)
VIDEO input
PC IN (MINI D-SUB 15P)
HDMI1
SCART1, SCART2
Component
AUDIO input
PC
DVI
Audio Output AUDIO (L/R)
Speaker Output 10W + 10W
Samsung Electronics 2-1
Product Specification
2-2 Specifications Analysis
: application, X: non-application
Model PS-42C67HD (Lily2-42HD) PS-50C67HD (Lily2-50HD) PS-42C96HD (Lily-42HD) PS-50C96HD (Lily-50HD)
Design
Display Type PDP TV PDP TV PDP TV PDP TV
Built-In Tuner O O O O
PC Resolution 1024 x 768 @ 85Hz 1365 x 768 @ 60Hz 1024 x 768 @ 85Hz 1365 x 768 @ 60Hz
PDP Module W2A W2A W2A W2A
Basic Screen Size 42 inches 50 inches 42 inches 50 inches
Aspect Ratio 16 : 9 16 : 9 16 : 9 16 : 9
1155 x 440 x 878 mm 1355 x 460 x 984 mm 1055 x 759 x 316 mm 1231 x 848.5 x 316 mm
Dimensions (WxHxD)
(With Stand) (With Stand) (With Stand) (With Stand)
Weight 42.8 kg (With stand) 53.9 kg (With stand) 33.2 kg (With stand) 44 kg (With stand)
Brightness 1,500 Cd/m2 1,300 Cd/m2 1,500 Cd/m2 1,300 Cd/m2
Picture Contrast Ratio 10000:1 10000:1 10000:1 10000:1
Image Enhacer FBE2X FBE2X FBE2X FBE2X
Equalizer O O O O
Auto Volume O O O O
Audio Surround Sound SRS TruSurround SRS TruSurround SRS TruSurround SRS TruSurround
Speaker Output 10 W + 10 W 10 W + 10 W 10 W + 10 W 10 W + 10 W
Speaker 2CH 2CH 2CH 2.2CH (2Way)
PIP O O O O
Double Screen O O O O
Caption X X X X
Still Image O O O O
Features
My Color Control O O O O
Color Weakness X X X X
Energy Saving O O O O
Screen Burn Protection O O O O
Antenna 1 Input 1 Input 1 Input 1 Input
CVBS X X 1AV(Side) 1AV(Side)
S-Video X X O O
Component(Y/PB/PR) 1 Input 1 Input 1 Input 1 Input
Connections PC(D-SUB) 1 Input 1 Input 1 Input 1 Input
HDMI 1 Input 1 Input 2 Input 2 Input
Scart 2 Input 2 Input 2 Input 2 Input
Optical O O O O
Coaxial X X X X
For the power supply and power consumption, refer to the label attached to the product.
2-2 Samsung Electronics
Product Specification
2-3 Accessories
Accessories Item Item code Remark
Remote Control BN59-00611A
Batteries 4301-000103
Power Cord 3903-000145
Supplied Accessories
Owner's Instructions BN68-01330C
Samsung Service center
Warranty Card -
Registration Card AA68-03575H
Safety Guide Manual AA68-03242K
Ferrite Core for
3301-001110
Earphone/Power Cord
Ferrite Core for
3301-001305
S-VIDEO/Power Cord
HDMI Cable
BN39-00641A
3000mm
HDMI/DVI cable
BN39-00643A
3000mm
Accessories that can be purchased
Component Cables (RCA)
BN39-00279A
1500mm
additionally
Electronics Store/
Scart Cable None
Internal shopping mall
PC Cable 1830mm
BN39-00115A PC Audio Cable
2000mm BN39-00061B
Samsung Electronics 2-3
MEMO
2-4 Samsung Electronics
