Image preview - the first page of the document
>> Download exploded_view_and_part_list_142 documenatation <<
Text preview - extract from the document
Exploded View & Part List
4. Exploded View & Part List
4-1 PS42V6SX/XEE
You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
Loc.No. Code No. Description Specification Q'ty SA/SNA Remark
FT532 2901-001357 FILTER-EMI AC LINE 250V,6A,UL/SA/VDE,0.1 1 S.A
M0013 BN96-02743A ASSY COVER P-REAR 42V6,PCM T0.5 1 S.A
T0074 T0268 T0448
M0013 BN96-02744A ASSY COVER P-REAR BOTTOM 42V6,HIPS HB,BK 1 S.A
M0013 M0112 BN63-02216A COVER-FRONT 42V6,HIPS,HB,XEC,BLK(BK500), 1 S.N.A
M0145 BN96-02784A ASSY BOARD P-FUNCTION TWISTER,CT5000-385 1 S.A
M0146 BN96-02050D ASSY BOARD P-POWER & IR Twister,CT5000-3 1 S.A
T0003 BN96-02737A ASSY COVER P-FRONT 42V6,XEC,HIPS HB,BLK( 1 S.A
T0023 BN64-00419A KNOB-POWER 42V6,PC,VIOLET 1 S.N.A
T0152 T0023 BN64-00421A KNOB POWER 42V6,DECO,ABS,HB,BLK(BK500),C 1 S.N.A
T0079
FT532
T0044 BN96-01887A ASSY PDP MODULE P M1,PS42S5S,D,V4,1002◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
