Image preview - the first page of the document
>> Download Product Specification documenatation <<
Text preview - extract from the document
2. Product specifications
2. Features and Specifications
2-1. Features and Specifications
Model SP-A400B
Features
Supporting Data and AV level qualities at the same time as implementing a maximum 2,000 ANSI
lumen brightness and HD images
Crossover product
Adapting standard specifications and presenting film-like images with excellent color rendering
New premium whale design
Adapting HDMI and a user-friendly Interface
(1*HDMI, D-Sub, 1*Component, Composite, S-VHS, RS-232C)
Supporting various modes (Including Monitor mode)
Manual Lens Focus, Zoom control
Low noise - less than 30dB / Meeting the highest standards
Major Specifications
Items Specifications
Panel Diagonal Size 0.65"
Deflection Frequency Panel
Resolution WXGA (1280 x 768)
(Width X Height)
Panel Manufacturer Texas Instrument
Optimal Resolution 1280 x 768 @ 60Hz
Lamp Type 200W UHP (Theater mode : 172W)
Guaranteed Lamp Lifetime 3,000 Hours (Theater mode : 3,250 hr)
Lamp Manufacturer Philips
Screen Color 18.9 M Colors (1024 x 768 x 3 x 8bit)
Max. Resolution 1280 x 1024
Brightness Max 2,000 ANSI lumen
Contrast Ratio 2,500:1
Lens Specifications Manual focus and manual zoom
Diagonal Screen Size 40" ~ 250" (diagonal)
Projection Distance 0.3 ~ 9.8 m
Keystone Vertical direction
Input Video Signal Video, S-Video, Component, Analog PC, HDMI
Hor. Freq. : 30 ~ 80KHz
Input Frequency
Ver. Freq. : 56 ~ 85Hz
Voltage 110/220Vac +/-10%, 50/60Hz +/-3Hz
Rated Power Consumption Less then 280W
Noise Level Theater mode: 28 dB, High luminance mode: 32 dB
Dimensions 343.1mm(W) x 162.4mm(H) x 347.2mm(D)
Weight 4.5kg
Operating temperature: 0~ 40
Operating humidity: 10% ~ 80%
Ambience
Storage temperature: -20~ 45
Storage humidity: 5% ~ 95%
Note: The design and specifications of the product are subject to change without prior notice.
