Image preview - the first page of the document
>> Download PCB_Diagram-2 documenatation <<
Text preview - extract from the document
62
No. Parts Number Part Name Function and Rule
1 CN01 Door plunger switch, cooktop warming center, oven lamp and relay of convection fan connector This is connector which is connected with Door plunger switch and Door lock switch. (COM-NO, COM-NC)
(This Document can not be used without Samsung's authorization)
2 CN02 Oven sensor Connector This is connector which is connected with oven sensor.
3 CN04, CN05 Relay connector This connector is to get all operating of relay on sub PCB to be connected.
4 CN07 Keypad Connector This is consisted of 15 pin and take a role of getting a cable on keypad to connect with touch PCB.
5 CN08, CN09 This is to supply power with primary on Low voltage transformer, and AC120V with main PCB through
A Terminal for connecting with SMPS Power Supply
harness. It won t be problem even though CN08 and CN09 has been changed when you insert housing.
6 CN10 This is connector which take a role of supplying secondary voltage of Low voltage transformer with main
A Terminal for connecting with a small-sized RELAY Power Supply
PCB.
7 ZNR1 Varistor This is the element to protect main PCB, getting varistor to work if over voltage is supplied with varistor.
8 IC02 DC 12V IC This is to supply DC12V with main PCB by voltage regulator.
9 IC03 DC 5V IC This is to supply DC5V with main PCB by voltage regulator.
5-1 PCB Diagrams (Main)
5. PCB Diagrams
63
No. Parts Number Part Name Function and Rule
1 CN01 Door plunger switch, cooktop warming center, This is connector which is connected with Door plunger switch and Door lock switch. (COM-NO, COM-NC)
oven lamp and relay of convection fan connector
(This Document can not be used without Samsung's authorization)
2 CN04, CN05 Relay connector Connector(CN04,CN05) on sub PCB take a role of getting all of the operation of relay on sub PCB to connect with main PCB(CN04,CN05).
3 Circuit is designed to have broil relay or convection relay worked after DLB relay is being worked by Double line break. (It will not be problem
DLB relay(Ry02) DLB Relay
with reversing the order in insering Orange and Red)
4 Broil relay(Ry03) Broil relay Broil relay(Ry03), Bake relay(Ry04), convection relay(Ry05) will be on-off working by micom signal after DLB relay is worked.
5 Bake relay(Ry04) Bake relay (Broil relay : It will not be problem with reversing the order in insering Black and Brown)
6 Convection relay(Ry05) Convection relay (Bake relay : It will not be problem with reversing the order in insering Yellow and Gray)
7 RY-source relay(Ry01) Source relay This is consisted of 15 pin and take a role of getting a cable on keypad to connect with touch PCB.
8 W/Drawer Relay(Ry06)
Warmer drawer terminal & Warmer drawer relay This is terminal to connect harness with relay to get heater on warming drawer work.
and T03 terminal
9 T02 terminal Convection terminal This is the terminal to connect convection heater with convection relay.
5-2 PCB Diagrams (Sub)
10 T01 terminal Live 1 Terminal This is the terminal to supply L1 voltage(120V) with warming drawer relay(Ry06),convection relay(Ry05).
5. PCB Diagrams
