Image preview - the first page of the document
ASC20100920001


>> Download ASC20100920001 documenatation <<

Text preview - extract from the document
                                                                               SERVICE BULLETIN
                                                                               PRODUCT:                             Refrigerator

                                    ELECTRONICS                                BULLETIN NUMBER:                     ASC20100920001
                                                                               BULLETIN DATE:                        Sept. 20, 2010
                                                                               MODELS:                               RS261MDPN/XAA
SUBJECT: Door Handle Parts change
                                                                                                                    RS261MDRS/XAA
Stainless Steel and Platinum colored models listed above                                                            RS263TDPN/XAA
employ a new handle. Since the old and new handles look
                                                                                                                    RS263TDRS/XAA
different, please verify which type you need before
ordering.
                                                                                                                    RS265TDPN/XAA
                                                                                                                    RS265TDRS/XAA
When changing from one construction type to another, it is
                                                                                                                    RS267TDPN/XAA
best to order the both freezer and fridge handles instead
of one to ensure the handles match.
                                                                                                                    RS267TDRS/XAA

Part Description             Old part number:DA97-06634A                       New Part: DA97-08278C
                             All steel construction                             Plastic construction
Assembly Handle




Note: Consult the Samsung Service Website at (http://.service.samsungportal.com) for the Service Manual
and other information on this product.
   This information is published for experienced repair technicians only and is not intended for use by the public. It does not contain
  warnings to advise non-technical individuals of possible dangers in attempting to service a product. Only experienced professional
  technicians should repair products powered by electricity. Any attempt to service or repair the product or products dealt with in this
 information by anyone else could result in serious injury or death. Information provided in this bulletin is subject to change or update
                                                             without notice.
