Image preview - the first page of the document
Sanyo_DP50749_P50749-00_J4FE_[SM]


>> Download Sanyo_DP50749_P50749-00_J4FE_[SM] documenatation <<

Text preview - extract from the document
Sanyo Service Tip                                     USIK / YX6E CHASSIS
                                                                                                    07/27/12

SYMPTOM:      If the power LED on front of the TV is turning ON for 10-20 seconds, OFF for
1-2 second and keeps repeating, the problem is most likely IC5750A. Affected models are
the 2009 & 2010 TVs (LCD and Plasma) listed.


IC5750A is located under the large shield. IC 5750A is a 48 pin NAND FLASH IC with
easy access for replacement. This will fix +80% of the boards with the symptom below.

                                                                       You must use the 3
Sanyo Part Number: QXXAVD058- - -M                                     dashes when ordering
                                                                       this IC.
  Chassis       IC 5700      IC 5700
  Version      Samsung      Quimonda

 P37819-00       SW84         SW82
                                          SYMPTOM:       If the power LED on front of the TV is turning ON
 P42849-00       SW84         SW82
                                          for 10-20 seconds, OFF for 1-2 second and keeps repeating, the
 P42849-01       SW84         SW82
                                          problem is most likely IC5750A. Affected models are the 2009 &
 P42849-02       SW84         SW82
                                          2010 TVs (LCD and Plasma) listed.
 P42849-04       SW84         SW82
 P42849-05       SW84         SW82

 P46849-00       SW84         SW82
 P46849-01       SW84         SW82
 P46849-02       SW84         SW82
 P46849-03       SW84         SW82
 P46819-00       SW84         SW82

 P50749-00       SW84         SW82
 P50749-01       SW84         SW82
 P50749-02       SW84         SW82
 P50749-03       SW84         SW82
 P50719-00       SW84         SW82        IC5750 to be replaced

 P52449-01       SW85         SW83                   Check IC manufacture for either Samsung or Quimonda

 P42840-02       SW84         SW82        The IC 5750A you receive will have software 84 installed in it. If
 P42840-03       SW84         SW82        IC 5700's manufacture is Quimonda or TV is a 52" then the
 P42840-04       SW84         SW82        software will need to be changed with the use of a USB drive.

 P46840-01       SW84         SW82
 P46840-02       SW84         SW82        Note : Only use this software in the Sanyo TVs listed.
                                          If used in wrong chassis, it could cause TV not to come
 P50740-01       SW84         SW82        on and IC 5750 will need to be changed again.
                                                      This self test is only for the
                                                      DP50749-00, with the Samsung
                                                      panel.
                DP50749-00                            The self test will not work with the
                                                      Panasonic panel.


               Panel: Self Test
Panel is capable of generating internal patterns without the Main
Signal Board attached. (rotating: white / red / green / blue / and
various other patterns)
This test eliminates Main Signal Board from circuit and confirms if
panel itself is operating properly.

1) Unplug these connectors on Main Signal Board.
  K8P
  K8B

2) Short pins 1-4 together on Logic Bd. at under connector
  CN2000.      (a small screw works good to short all together)

3) K8P Connector
  These pins must be shorted together.
  p#1 & #3
  p#2 & #7

 Shorting these pins together will automatically energize the panel,
 after AC power has been applied in step #4 below.

4) AC power must be applied to panel. Power cord can still be
  attached to AC Filter, or power can be applied directly to
  CN800s on SMPS.
  (recommend that AC Filter still be used for ease of connection,
  but can be bypassed if needed)

5) Please remember to remove the screw on the Logic Board under
  CN2000, when finished.

 note: no audio is available with panel self test
#1




#2
#4
                                                                                                                                                     FILE NO.


     SERVICE MANUAL                                                              Remote Control Digital                                    DP50749                       (U.S.A.)
                                                                                 Color Television                                                                        (CANADA)
                                                                                                                                           ORIGINAL VERSION


                                                                                                                                               Chassis No. P50749-00


                                                                                                                                         NOTE: Match the Chassis No. on
                                                                                                                                               the unit's back cover with
                                                                                                                                               the Chassis No. in the
                                                                                                                                               Service Manual.
                                                                                                                                                      If the Original Version
                                                                                                                                                      Service Manual Chassis
                                                                                                                                                      No. does not match the
                                                                                                                                                      unit's, additional Service
                                                                                                                                                      Literature is required. You
                                                                                                                                                      must refer to "Notices" to the
                                                                                                                                                      Original Service Manual
                                                                                                                                                      prior to servicing the unit.


                                              Servicing should be performed by only trained and qualified service personnel.

                                         Contents                                                                   Specifications
                                         SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . 2     POWER RATING . . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
                                         SERVICE ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . 3                                                                    464 W (AVG.)
                                         ON-SCREEN SERVICE MENU . . . . . . . . . . . . . . . . . . . . . 4         ANTENNA INPUT IMPEDANCE. . . . . . . . . . . . . . . . . 75
                                         POWER FAILURE CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . 5                                                                 UHF/VHF/CATV
                                         MECHANICAL DISASSEMBLY . . . . . . . . . . . . . . . . . . . . 6                                                                                 DIGITAL
                                         CHASSIS ELECTRICAL PARTS LIST . . . . . . . . . . . . . . . . 8
