Image preview - the first page of the document



>> Download Sanyo_DP19640_P19640-00_N8JE_[SM] documenatation <<

Text preview - extract from the document

                                                                                                                FILE NO.

 SERVICE MANUAL Remote Control Digital                                                                         DP19640 (U.S.A.)
                                                                         Color Television
                                                                                                                                     (CANADA)
                                                                                                               ORIGINAL VERSION
                                                                                                                     Chassis NO. P19640-00

                                                                                                                NOTE: Match the chassis NO.
                                                                                                                      on the unit's back cover
                                                                                                                      with the chassis NO. in
                                                                                                                      the Service Manual.
                                                                                                                          If the Original Version
                                                                                                                          Service Manual Chassis
                                                                                                                          NO. does not match the
                                                                                                                          unit's, additional Service
                                                                                                                          Literature is required.
                                                                                                                          You must refer to "Notices"
                                                                                                                          to the Original Service
                                                                                                                          Manual prior to servicing
                                                                                                                          the unit.

                                          Servicing should be performed by only trained and qualified service personnel.
                                         Contents                                                 Specifications
                                         SAFETY INSTRUCTIONS............................. 2       POWER RATING................................. 120VAC
                                         SERVICE ADJUSTMENTS........................... 3                                                        34 W(AVG.)
                                         POWER FAILURE CIRCUIT.......................... 7        ANTENNA INPUT IMPEDANCE............... 75
