Image preview - the first page of the document



>> Download Sanyo_DP37649_P37649-01_N4PLE_[SM] documenatation <<

Text preview - extract from the document

                                         Notice
                                             CORRECTION                            PRODUCTION CHANGE
                                             SERVICE FLASH                         ADD INFORMATION                                                                FILE NO.

                                         Please add this notice to the Service Manual listed below.                                                               REVISION 0

                                          Category:       COLOR TELEVISION                                                                       Date:         OCTOBER / 06 / 2009


                                          Model:          DP37649                                                         Effective from : Chassis No. P37649-01


                                         Destination: U.S.A. / CANADA                             REF : No. SM780162-01



                                         NOTE: Match the Chassis No. on the unit's back cover with the Chassis No. in the Service
                                               Manual. If the Service Manual Chassis No. does not match the unit's, additional Service
                                               Literature is required. This chassis is similar to Chassis No. P37649-00. Only the
                                               difference Service Information is given in this manual. For detailed Service Information,
                                               refer to the Original Service Manual and Notices for Chassis No. P37649-00 used in
                                               Model DP37649 (SM7800162).


                                         SERVICING SHOULD BE PERFORMED BY ONLY TRAINED AND QUALIFIED SERVICE PERSONNEL.

                                         1. IN THE SERVICE ADJUSTMENTS
                                           PAGE 4      ON-SCREEN SERVICE MENU
                                                Item No. 088 OP2 Data should match 21h in the table and in Note 2.


                                         2. IN THE CHASSIS ELECTRICAL PARTS LIST MISCELLANEOUS
                                            The reason for change.
                                             A : Misprint     B : Quality Reliability                                    C : Standardization
                                             D : Design       E : Add as a possible sub                                  F : Schematic location change
                                             G : Purchasing Request

                                          Page &                                                                                                                       Interchange-
                                                       Schematic                      Part No.
                                          Section       Location
                                                                                                                          Description                      Q'ty        ability                      Reason

                                          Page 25,              Old         1AV4T40C11900                   LCD(T370XW02 VC02)                               1                NO
                                          Chassis       EL901 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -     D
                                          Electrical
                                          Parts List
                                                                New 1AV4T40C00300                          LCD(T370XW02 VC00)                                1                NO
