Image preview - the first page of the document



>> Download SANYO_VPC-S6 documenatation <<

Text preview - extract from the document

                                                                                              FILE NO.




SERVICE MANUAL




Digital Camera                                                                                VPC-S6U
                                                                                              (Product Code : 168 028 01)
                                                                                              (U.S.A.)
                                                                                              (Canada)



                                                                                              VPC-S6
                                                                                              (Product Code : 168 028 02)
                                                                                              (Europe)
                                                                                              (South America)
                                                                                              (China)
                                                                                              (Australia)
                                                                                              (Korea)
                                                                                              (Taiwan)
                                                                                              (General)
Contents
1. OUTLINE OF CIRCUIT DESCRIPTION .................... 3
2. DISASSEMBLY ........................................................ 11
3. ELECTRICAL ADJUSTMENT .................................. 16                                VPC-S6GX
                                                                                              (Product Code : 168 028 03)
4. USB STORAGE INFORMATION
   REGISTRATION ...................................................... 21                     (Southeast Asia)
5. TROUBLESHOOTING GUIDE ................................. 22                                 (Middle East)
                                                                                              (Hong Kong)
6. PARTS LIST ............................................................. 24
   ELECTRICAL PARTS .............................................. 24
   ACCESSORIES & PACKING MATERIALS ............. 27
   CABINET & CHASSIS PARTS 1 ............................. 28
   CABINET & CHASSIS PARTS 2 ............................. 30
CIRCUIT DIAGRAMS &
PRINTED WIRING BOARDS ...................................... C1

WARNING
This product has been manufactured using lead-free solder. Be sure to follow the warning given on page 2 when carrrying out
repair work.

                                                           PRODUCT SAFETY NOTICE
   The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
   special significance to product safety. Should any component designated by a symbol need to be replaced, use only the part
   designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.


CAUTION : Danger of explosion if battery is incorrectly replaced.

                Replace only with the same or equivalent type recommended by the manufacturer.
                Discard used batteries according to the manufacturer's instructions.

NOTE : 1. Parts order must contain model number, part number, and description.
       2. Substitute parts may be supplied as the service parts.
       3. N. S. P. : Not available as service parts.

Design and specification are subject to change without notice.
SX813/U, EX, GX                                                                                       REFERENCE No. SM5310630
