>> Download Repairing-GD-ROM-1589 documenatation <<Text preview - extract from the documentRepairing Sega Dreamcast GD-ROM
Repairing Sega Dreamcast GD-ROM
Tools used in this guide
Phillips #1 Screwdriver
Step 1 - Expansion bay
Verify that the console is disconnected from
the AC outlet before you begin.
Flip the console over on its back.
Take note of your model number, in case
replacement parts are needed.
