Image preview - the first page of the document
![Sharp_LC-32SD1E_LC-26SD1E_Parts_Guide_[SM]](/pics/5c26fb63463dc.gif)
>> Download Sharp_LC-32SD1E_LC-26SD1E_Parts_Guide_[SM] documenatation <<
Text preview - extract from the document
PartsGuide
LC-26SD1E/RU, LC-32SD1E/RU
PARTS GUIDE
No. S76V6LC26SD1E
LCD COLOUR TELEVISION
LC-26SD1E/RU
MODELS LC-32SD1E/RU
CONTENTS
[1] PRINTED WIRING BOARD [7] DUNTKD609FM06/FM07
ASSEMBLIES (D-TUNER UNIT)
(NOT REPLACEMENT ITEM) (LC-26SD1E/RU, LC-32SD1E/RU)
[2] LCD PANEL AND TUNER [8] DUNTKD628FM07/FM08
(NOTE: THE PARTS HERE (DIGITAL Unit)
SHOWN ARE SUPPLIED AS AN (LC-26SD1E/RU, LC-32SD1E/RU)
ASSEMBLY BUT NOT
INDEPENDENTLY.) [9] DUNTKD890FM14/FM16
(MAIN UNIT)
[3] DUNTKD604FM14/FM16 (AV UNIT) (LC-26SD1E/RU, LC-32SD1E/RU)
(LC-26SD1E/RU, LC-32SD1E/RU)
[10] CABINET PARTS (LC-26SD1E/RU)
[4] DUNTKD605FM12/FM13
(POWER UNIT) [11] CABINET PARTS (LC-32SD1E/RU)
(LC-26SD1E/RU, LC-32SD1E/RU)
[12] SUPPLIED ACCESSORIES
[5] DUNTKD606FMV0
(OPERATION Unit) [13] PACKING PARTS
[6] DUNTKD607FMV0 (R/C,LED UNIT) [14] SERVICE JIGS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-26SD1E/RU, LC-32SD1E/RU
NO. PARTS CODE PRICE NEW PART DESCRIPTION
RANK MARK DELIVERY
[1] PRINTED WIRING BOARD ASSEMBLIES (NOT REPLACEMENT ITEM)
N DUNTKD604FM14 BL N R AV Unit (26SD1E/RU)
N DUNTKD604FM16 BL N R AV Unit (32SD1E/RU)
N DUNTKD605FM12 BU N R POWER Unit (26SD1E/RU)
N DUNTKD605FM13 BU N R POWER Unit (32SD1E/RU)
N DUNTKD606FMV0 AK N R OPERATION Unit
N DUNTKD607FMV0 AQ N R R/C,LED Unit
N DUNTKD609FM06 BN N R D-TUNER Unit (26SD1E/RU)
N DUNTKD609FM07 BN N R D-TUNER Unit (32SD1E/RU)
N DUNTKD628FM07 BZ N R DIGITAL Unit (26SD1E/RU)
N DUNTKD628FM08 BZ N R DIGITAL Unit (32SD1E/RU)
N DUNTKD890FM14 CE N R MAIN Unit (26SD1E/RU)
N DUNTKD890FM16 CE N R MAIN Unit (32SD1E/RU)
[2] LCD PANEL AND TUNER (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT
NOT INDEPENDENTLY.)
! TU201 RTUNQA033WJZZ S Digital Tuner
N R1LK260T3LF14 DL N R 26V LCD Panel Module Unit (26SD1E/RU)
N R1LK315T3LF14 DV N R 32V LCD Panel Module Unit (32SD1E/RU)
[3] DUNTKD604FM14/FM16 (AV UNIT) (LC-26SD1E/RU, LC-32SD1E/RU)
C301 VCKYCY1CB273KY AB R Capacitor, 0.027 16V Ceramic
C302 VCKYCY1CB273KY AB R Capacitor, 0.027 16V Ceramic
C303 VCKYCY1HF224ZY AA R Capacitor, 0.22 50V Ceramic
C304 VCKYCY1HF224ZY AA R Capacitor, 0.22 50V Ceramic
C305 VCKYCY1HB104KY AA R Capacitor, 0.1 50V Ceramic
C306 VCEASX1HN225MY AB R Capacitor, 2.2 50V Electrolytic
C307 VCEASX1HN225MY AB R Capacitor, 2.2 50V Electrolytic
C308 VCKYCY1HB104KY AA R Capacitor, 0.1 50V Ceramic
C309 VCKYCY1HB222KY AA R Capacitor, 2200p 50V Ceramic
C310 VCKYCY1HB222KY AA R Capacitor, 2200p 50V Ceramic
C311 VCEASX1CN226MY AC R Capacitor, 22 16V Electrolytic
C312 VCKYCY1HB222KY AA R Capacitor, 2200p 50V Ceramic
C313 VCKYCY1HB222KY AA R Capacitor, 2200p 50V Ceramic
C314 VCKYCY1HB153KY AA R Capacitor, 0.015 50V Ceramic
C315 VCKYCY1HB153KY AA R Capacitor, 0.015 50V Ceramic
C316 VCCCCY1HH330JY AA R Capacitor, 33p 50V Ceramic
C317 VCCCCY1HH330JY AA R Capacitor, 33p 50V Ceramic
C318 VCCCCY1HH470JY AA R Capacitor, 47p 50V Ceramic
C319 VCCCCY1HH470JY AA R Capacitor, 47p 50V Ceramic
C320 VCEASX1HN225MY AB R Capacitor, 2.2 50V Electrolytic
C321 VCEASX1HN225MY AB R Capacitor, 2.2 50V Electrolytic
C322 VCKYCY1HF224ZY AA R Capacitor, 0.22 50V Ceramic
C323 VCKYCY1HF224ZY AA R Capacitor, 0.22 50V Ceramic
C324 VCEASX1HN106MY AC R Capacitor, 10 50V Electrolytic
C325 VCEASX1HN106MY AC R Capacitor, 10 50V Electrolytic
C326 VCKYCY1HB153KY AA R Capacitor, 0.015 50V Ceramic
C327 VCKYCY1HB153KY AA R Capacitor, 0.015 50V Ceramic
C328 VCEASX1HN225MY AB R Capacitor, 2.2 50V Electrolytic
C329 VCEASX1HN225MY AB R Capacitor, 2.2 50V Electrolytic
C330 VCESYA1VM477M+ AF R Capacitor, 470 35V Electrolytic
C331 VCESYA1VM477M+ AF R Capacitor, 470 35V Electrolytic
C332 VCKYCY1HB221KY AA R Capacitor, 220p 50V Ceramic
C333 VCKYCY1HB221KY AA R Capacitor, 220p 50V Ceramic
C334 VCKYCY1HB221KY AA R Capacitor, 220p 50V Ceramic
C335 VCKYCY1HB221KY AA R Capacitor, 220p 50V Ceramic
C336 VCEASX1HN105MY AB R Capacitor, 1 50V Electrolytic
C337 VCEASX1HN105MY AB R Capacitor, 1 50V Electrolytic
C338 RC-EZA513WJZZ AH R Capacitor, 470 50V Electrolytic
C339 RC-EZA513WJZZ AH R Capacitor, 470 50V Electrolytic
C340 VCKYTV1EB224KY AA R Capacitor, 0.22 25V Ceramic
C341 VCKYTV1EB224KY AA R Capacitor, 0.22 25V Ceramic
C342 VCFYFA1HA334J+ AB R Capacitor, 0.33 50V
C343 VCFYFA1HA334J+ AB R Capacitor, 0.33 50V
C344 VCEASX1HN105MY AB R Capacitor, 1 50V Electrolytic
C345 VCEASX1HN105MY AB R Capacitor, 1 50V Electrolytic
C346 VCEASX1HN105MY AB R Capacitor, 1 50V Electrolytic
C347 VCEASX1HN105MY AB R Capacitor, 1 50V Electrolytic
C348 VCEASX1VN226MY AC R Capacitor, 22 35V Electrolytic
C349 VCEASX1VN226MY AC R Capacitor, 22 35V Electrolytic
C350 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C351 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C352 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C353 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C354 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C355 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C356 VCEASY1HN476MY AD R Capacitor, 47 50V Electrolytic
C357 VCEASY1HN476MY AD R Capacitor, 47 50V Electrolytic
C358 VCEASX1HN106MY AC R Capacitor, 10 50V Electrolytic
C359 VCEASX1HN106MY AC R Capacitor, 10 50V Electrolytic
C360 VCEASY1CN476MY AC R Capacitor, 47 16V Electrolytic
C361 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C362 VCKYTV1EB224KY AA R Capacitor, 0.22 25V Ceramic
C363 VCKYTV1EB224KY AA R Capacitor, 0.22 25V Ceramic
C364 VCEASY1CN477MY AD R Capacitor, 470 16V Electrolytic
2
LC-26SD1E/RU, LC-32SD1E/RU
NO. PARTS CODE PRICE NEW PART DESCRIPTION
RANK MARK DELIVERY
[3] DUNTKD604FM14/FM16 (AV UNIT) (LC-26SD1E/RU, LC-32SD1E/RU)
C365 VCKYCY1HB222KY AA R Capacitor, 2200p 50V Ceramic
C366 VCKYCY1HB222KY AA R Capacitor, 2200p 50V Ceramic
C1101 VCKYTV1EB104KY AB R Capacitor, 0.1 25V Ceramic
C1102 VCKYTV1EB104KY AB R Capacitor, 0.1 25V Ceramic
C1103 VCKYTV1EB104KY AB R Capacitor, 0.1 25V Ceramic
C1104 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1105 VCKYTV1EB104KY AB R Capacitor, 0.1 25V Ceramic
C1106 VCKYTV1EB104KY AB R Capacitor, 0.1 25V Ceramic
C1107 VCKYTV1EB104KY AB R Capacitor, 0.1 25V Ceramic
C1108 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1109 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1110 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1114 VCKYCY1HB221KY AA R Capacitor, 220p 50V Ceramic
C1116 VCKYCY1HB221KY AA R Capacitor, 220p 50V Ceramic
C1117 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1118 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1119 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C1120 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C1121 VCKYTV1CB105KY AC R Capacitor, 1 16V Ceramic
C1122 VCKYCY1HB331KY AA R Capacitor, 330p 50V Ceramic
C1123 VCKYCY1HB331KY AA R Capacitor, 330p 50V Ceramic
C1124 VCKYTV1CB105KY AC R Capacitor, 1 16V Ceramic
C1125 VCKYCY1HB471KY AA R Capacitor, 470p 50V Ceramic
C1126 VCKYCY1HB471KY AA R Capacitor, 470p 50V Ceramic
C1127 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1128 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1130 VCEASY1CN477MY AD R Capacitor, 470 16V Electrolytic
C1131 VCKYCY1HF103ZY AA R Capacitor, 0.01 50V Ceramic
C1132 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1133 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1134 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C1135 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C1136 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1137 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1138 VCKYTV1CB105KY AC R Capacitor, 1 16V Ceramic
C1139 VCKYCY1HB331KY AA R Capacitor, 330p 50V Ceramic
C1140 VCKYCY1HB331KY AA R Capacitor, 330p 50V Ceramic
C1142 VCKYTV1CB105KY AC R Capacitor, 1 16V Ceramic
C1143 VCKYCY1HB471KY AA R Capacitor, 470p 50V Ceramic
C1144 VCKYCY1HB471KY AA R Capacitor, 470p 50V Ceramic
C1145 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1146 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1147 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1148 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1157 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1158 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1159 VCKYCY1HF103ZY AA R Capacitor, 0.01 50V Ceramic
C1160 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1161 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1162 VCEASY1CN477MY AD R Capacitor, 470 16V Electrolytic
C1201 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C1202 VCKYCY1HF103ZY AA R Capacitor, 0.01 50V Ceramic
C1203 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1204 VCCCCY1HH100DY AA R Capacitor, 10p 50V Ceramic
C1205 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1206 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1207 VCCCCY1HH100DY AA R Capacitor, 10p 50V Ceramic
C1208 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1210 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1211 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C1212 VCKYTV1CB105KY AC R Capacitor, 1 16V Ceramic
C1216 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1217 VCKYCY1HB102KY AA R Capacitor, 1000p 50V Ceramic
C1218 VCKYTV1CB105KY AC R Capacitor, 1 16V Ceramic
C1219 VCEASY1CN476MY AC R Capacitor, 47 16V Electrolytic
C1220 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1221 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1222 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1223 RC-KZA073WJZZY AD R Capacitor, 10 16V Ceramic
C1224 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1225 VCCCCY1HH101JY AA R Capacitor, 100p 50V Ceramic
C1251 VCEASX1CN107MY AC R Capacitor, 100 16V Electrolytic
C1252 VCKYTV1CB105KY AC R Capacitor, 1 16V Ceramic
C1253 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
D301 RH-EXA092WJZZY AB R Zener Diode, UDZSTE-1712B
D302 RH-EXA092WJZZY AB R Zener Diode, UDZSTE-1712B
D303 RH-EXA092WJZZY AB R Zener Diode, UDZSTE-1712B
D304 RH-EXA092WJZZY AB R Zener Diode, UDZSTE-1712B
D305 RH-EXA089WJZZY AB R Zener Diode, UDZSTE-174.3B
D306 VHD1SS390++-1Y AB R Diode, 1SS390TE61
D307 VHD1SS390++-1Y AB R Diode, 1SS390TE61
D308 VHD1SS390++-1Y AB R Diode, 1SS390TE61
D309 VHD1SS390++-1Y AB R Diode, 1SS390TE61
D310 VHD1SS390++-1Y AB R Diode, 1SS390TE61
D311 RH-EXA103WJZZY AB R Zener Diode, UDZSTE-1736B
3
LC-26SD1E/RU, LC-32SD1E/RU
NO. PARTS CODE PRICE NEW PART DESCRIPTION
RANK MARK DELIVERY
[3] DUNTKD604FM14/FM16 (AV UNIT) (LC-26SD1E/RU, LC-32SD1E/RU)
D312 RH-EXA103WJZZY AB R Zener Diode, UDZSTE-1736B
D313 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D314 RH-EXA101WJZZY AB R Zener Diode, UDZSTE-1730B
D315 RH-EXA101WJZZY AB R Zener Diode, UDZSTE-1730B
D316 RH-EXA101WJZZY AB R Zener Diode, UDZSTE-1730B
D317 RH-EXA101WJZZY AB R Zener Diode, UDZSTE-1730B
D318 VHD1SS390++-1Y AB R Diode, 1SS390TE61
D1101 RH-EX1068CEZZY AB R Zener Diode, EX1068CE
D1102 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1103 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1104 RH-EX1068CEZZY AB R Zener Diode, EX1068CE
D1105 RH-EX1064CEZZY AB R Zener Diode, EX1064CE
D1106 RH-EX1034CEZZY AB R Zener Diode, EX1034CE
D1107 RH-EX1034CEZZY AB R Zener Diode, EX1034CE
D1108 RH-EX1064CEZZY AB R Zener Diode, EX1064CE
D1109 RH-EX1049CEZZY AB R Zener Diode, EX1049CE
D1110 RH-EX1049CEZZY AB R Zener Diode, EX1049CE
D1111 RH-EX1049CEZZY AB R Zener Diode, EX1049CE
D1112 RH-EX1049CEZZY AB R Zener Diode, EX1049CE
D1113 RH-EX1034CEZZY AB R Zener Diode, EX1034CE
D1114 RH-EX1034CEZZY AB R Zener Diode, EX1034CE
D1115 RH-EX1034CEZZY AB R Zener Diode, EX1034CE
D1116 RH-EX1034CEZZY AB R Zener Diode, EX1034CE
D1117 RH-EX1034CEZZY AB R Zener Diode, EX1034CE
D1118 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1119 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1120 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1121 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1122 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1123 RH-EX1026CEZZY AB R Zener Diode, 3.9V
D1201 RH-EX1239CEZZY AB R Zener Diode, EX1239CE
FB1101 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1102 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1103 RBLN-A074WJZZY AA R Balun, BLN-A074WJ
FB1104 RBLN-A074WJZZY AA R Balun, BLN-A074WJ
FB1105 RBLN-A073WJZZY AA R Balun, BLN-A073WJ
FB1106 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1107 RBLN-A073WJZZY AA R Balun, BLN-A073WJ
FB1108 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1109 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1110 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1111 RBLN-A073WJZZY AA R Balun, BLN-A073WJ
FB1112 RBLN-A073WJZZY AA R Balun, BLN-A073WJ
FB1201 RBLN-A073WJZZY AA R Balun, BLN-A073WJ
FB1202 RBLN-A073WJZZY AA R Balun, BLN-A073WJ
FB1203 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1204 RBLN-A345WJZZY AB R Balun, BLN-A345WJ
FB1213 RBLN-A215WJZZY AB R Balun, BLN-A215WJ
FB1218 RBLN-A192WJZZY AA R Balun, BLN-A192WJ
FL1101 RFILN0017TAZZY AC R Filter
FL1102 RFILN0017TAZZY AC R Filter
FL1103 RFILN0017TAZZY AC R Filter
FL1104 RFILN0017TAZZY AC R Filter
FL1105 RFILN0017TAZZY AC R Filter
FL1106 RFILN0017TAZZY AC R Filter
FL1107 RFILN0017TAZZY AC R Filter
FL1108 RFILN0017TAZZY AC R Filter
FL1109 RFILN0017TAZZY AC R Filter
FL1110 RFILN0017TAZZY AC R Filter
FL1211 RFILN0017TAZZY AC R Filter
FL1212 RFILN0017TAZZY AC R Filter
IC301 VHITDA8931T-1Y AS R IC, TDA8931T/N1,118
IC302 VHITDA8931T-1Y AS R IC, TDA8931T/N1,118
IC303 VHINJM4558M-1Y AD R IC, NJM4558M-TE1
IC1101 VHIMM1506XN-1Y AD R IC, MM1506XNRE
IC1102 VHIMM1506XN-1Y AD R IC, MM1506XNRE
IC1201 VHIMM1507XN-1Y AD R IC, MM1507XNRE
J1101 QSOCZA116WJZZ AK R Socket
J1201 QJAKZA033WJZZ AK R Jack, 16Pin
J1301 QJAKJA007WJZZ AD R Jack, Headphone Out
L301 RCILPA386WJZZ AF R Coil, Peaking 47◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
