Image preview - the first page of the document
![Sharp_LC-39LE650E_50LE650E_LC-39LE651E_50LE651E_LC-39LE652E_50LE652E_[SM]](/pics/5c26fbfa8d0af.gif)
>> Download Sharp_LC-39LE650E_50LE650E_LC-39LE651E_50LE651E_LC-39LE652E_50LE652E_[SM] documenatation <<
Text preview - extract from the document
LC-39/50LE650
LC-39/50LE651
LC-39/50LE652
50mm
SERVICE MANUAL
S1stLC39LE650
40mm
Issued: 14th June 2013
1st Edition LED LCD COLOUR TELEVISION
Wi-Fi & 3D Ready / DVB-T / T2 / C / S / S2 PAL B/G / SECAM B/G, D/K, L/L' SYSTEM COLOUR TELEVISION
31.5mm
25mm MODELS
LC-39LE650E/RU/V
LC-39LE651E/K/RU/V
LC-39LE652E/RU/V
20mm
LC-50LE650E/RU/V
LC-50LE651E/K/RU/V
LC-50LE652E/RU/V
In the interests of user safety (required by safety
regulations in some countries) the set should be re-
stored to its original condition and only parts identical
to those specified should be used.
CONTENTS
ELECTRICAL SPECIFICATIONS ........................................................................................ 2
IMPORTANT SERVICE SAFETY PRECAUTIONS ......................................................................... 3
OPERATION MANUAL .................................................................................................................... 6
DIMENSIONS .................................................................................................................... 22
REMOVING OF MAJOR PARTS ..................................................................................................... 23
SERVICE ADJUSTMENTS ............................................................................................................. 33
PUBLIC MODE .................................................................................................................................... 44
SOFTWARE UPGRADING ............................................................................................................. 47
MAJOR ICs INFORMATION ..................................................................................................... 48
BLOCK DIAGRAMS ..................................................................................................................... 63
SCHEMATIC DIAGRAMS ....................................................................................................... 66
PRINTED WIRING BOARDS ......................................................................................................... 114
REPLACEMENT PARTS LIST ....................................................................................................... 121
CABINET AND MECHANICAL PARTS ............................................................................................ 141
PACKING OF THE SET ....................................................................................................................... 145
SHARP CORPORATION This document has been published to
be used for after sales service only.
The contents are subject to chage without notice.
1
LC-39/50LE650
LC-39/50LE651
LC-39/50LE652
Appendix ELECTRICAL SPECIFICATIONS
Specifications
Item 39" LCD COLOUR TV, 50" LCD COLOUR TV, 60" LCD COLOUR TV,
Models: Models: Models:
LC-39LE650E/RU/V LC-50LE650E/RU/V LC-60LE650E/RU
LC-39LE651E/K/RU/V LC-50LE651E/K/RU/V LC-60LE651E/K/RU
LC-39LE652E/RU/V LC-50LE652E/RU/V LC-60LE652E/RU
LC-39LE654E/RU/V LC-50LE654E/RU/V LC-60LE654E/RU
LC-39LU651E LC-50LU651E LC-60LU651E
LC-39LM652E/V LC-50LM652E/V LC-60LM652E
LC-39LK652E LC-50LK652E LC-60LK652E
LC-39LX652E LC-50LX652E LC-60LX652E
LCD Panel (LED TV) 39" BLACK TFT 50" BLACK TFT 60" BLACK TFT
Resolution 6.220.800 dots (1.920 x 1.080 pixels)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV Standard Analogue CCIR (B/G, I, D/K, L/L')
Digital DVB-T (2K/8K OFDM)(H.264), DVB-C, DVB-C2 (L*654 only), DVB-T2(L*651/654
TV only), DVB-S/S2 (L*652/654 only)
Func- Receiving VHF/UHF E2◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
