Image preview - the first page of the document



>> Download CAR0361 documenatation <<

Text preview - extract from the document

                                  Car Stereo                                                      CSA-14
                                  Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656


Model:      XR-1400                                                       No.    361
Subject: Tape Audio Level Lower Than Tuner Audio Level.                   Date: May 1, 1995


Symptom:
  (52)         The tape audio level may be lower than the tuner audio level.



Solution:      If the customer complains about this problem, implement the component changes
               shown below.

                   REF                   FORMER                                          NEW
                             DESCRIPTION         PART NUMBER               DESCRIPTION     PART NUMBER

                   R54        RESISTOR,             1-247-815-11             RESISTOR,         1-247-807-11
                   R55         220 OHM                                        100 OHM

                   R11        RESISTOR,             1-247-863-11             RESISTOR,         1-247-839-11
                   R12          22 K                                           2.2 K




Reference: Technical News ME-95002                                                                PRINTED IN USA
