Image preview - the first page of the document



>> Download CAR0377 documenatation <<

Text preview - extract from the document

                                   Car Stereo                                                    CSA-14
                                   Service Bulletin
                                   Sony Service Company - Technical Services
                                   A Division of Sony Electronics Inc.
                                   Sony Drive, Park Ridge, New Jersey 07656


Model: XDP-U50D                                                            No.    377
Subject: No Audio Or Distorted Audio When Connected                        Date: September 13, 1995
            To CDX-91 or MDX-40.


Symptom:
  (51)          When the CDX-91 or MDX-40 is connected to the XDP-U50D "ANALOG IN 2"
                the audio might not be heard, or might sound distorted.




Solution:       If the customer complains of this problem, replace R213 on the XDP-U50D
                Main board with a jumper wire as shown below.

                    REF                    FORMER                                          NEW
                             DESCRIPTION            PART NUMBER              DESCRIPTION     PART NUMBER

                   R213     RESISTOR, MTL            1-202-999-11            JUMPER WIRE            -
                             GLAZE, 470
                                OHM




                Applicable Serial Numbers: up to 40,510


Reference: Technical News ME-95016                                                               PRINTED IN USA
