Image preview - the first page of the document



>> Download CAR0380 documenatation <<

Text preview - extract from the document

                                  Car Stereo                                                  CSA-14
                                 Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656


Model:      CDX-4090                                                          No.    380
Subject: No Audio.                                                            Date: November 10, 1995


Symptom:
  (51)         The unit has no audio regardless of the source. In some instances the STEREO
               indicator on the display may always be illuminated. This problem may be caused by
               Q593 being defective.



Solution:      Check Q-593, and if found to be defective replace it. Also, change TH503 to a
               different type which offers greater protection against damage to Q593.

                   REF                   FORMER                                      NEW
                            DESCRIPTION          PART NUMBER              DESCRIPTION   PART NUMBER
                  Q593      TRANSISTOR,             8-729-822-84              SAME            SAME
                            2SB1202FAST

                  TH503     THERMISTOR,             1-809-148-21          THERMISTOR,      1-809-842-21
                              2.2 OHM                                       2.0 OHM




Reference: M.E.-Q.A. Ref. QM-MIWA210-04                                                       PRINTED IN USA
