                                  Car Stereo                                                        CSA-14
                                 Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656


Model:      XR-C210, XR-C410                                                        No.    383
Subject: Intermittent Audio Muting                                                  Date: November 15, 1995


Symptom:
  (57)         The audio may intermittently mute at high volume levels.



Solution:      If the customer complains of this problem, change the value of C904 on the
               AMPLIFIER board as shown below.

                   REF                   FORMER                                            NEW
                            DESCRIPTION          PART NUMBER                   DESCRIPTION     PART NUMBER

                   C904      CAPACITOR,             1-124-584-00               CAPACITOR,        1-126-157-11
                            ELECT., 100UF,                                     ELECT., 10UF,
                                10V                                                16V



               Serial number range in which this problem might be found:
                     XR-C210:       59501 - 67000           69501 - 77000
                                    108201 - 111144         120201 - 122200
                                    133801 - 137800

                    XR-C410          31401 - 42400                        45401 - 48400
                                     59101 - 66576




Reference: Technical News ME-95022                                                                  PRINTED IN USA
