Image preview - the first page of the document



>> Download CAR0389 documenatation <<

Text preview - extract from the document

                                  Car Stereo                                                     CSA-14
                                  Service Bulletin
                                   Sony Service Company - Technical Services
                                   A Division of Sony Electronics Inc.
                                   Sony Drive, Park Ridge, New Jersey 07656


Model:      XR-6450                                                              No.       389
Subject: Display Button Does Not Work.                                           Date: December 14, 1995


Symptom:
  (13)         Pressing the DISPLAY button may have no effect when in FM mode and the field
               strength of the signal is greater than 60dB.



Solution:      If the customer complains of this problem add a 22K ohm resistor between JW25
               and JW43 on the main board as shown below.

                   REF                DESCRIPTION                          PART NUMBER
                      -     RESISTOR, CARBON 22K, 1/4W                      1-247-863-91
               Applicable serial numbers:     156,111 ~ 165,500
                                              165,201 ~ 170,200
                                              172,301 ~ 174,700
                                              174,801 ~ 175,400



               Preparing the resistor:
               1- Cut the leads so that the overall length is 26mm.
               2- Insulate the leads as shown.
               3- Form the ends of the leads as shown.




Reference: Technical News ME-95026                                                               PRINTED IN USA
