                                  Car Stereo                                                   CSA-14
                                  Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656

Model:      MDX-100                                                           No.     395
Subject: Skipping And/Or Drop-outs.                                           Date: April 4, 1996


Symptom:
  (57)         The unit may skip, or audio drop-outs may be heard. This problem may be caused
               by dust on the objective lens. The dust may be the result of the fan producing
               excessive air circulation.



Solution:      If skipping and/or drop-outs occur, and dust is found on the lens, change D501 on the
               Main board to a different type, and add a fan sheet as shown below.

                   REF                   FORMER                                       NEW
                            DESCRIPTION          PART NUMBER              DESCRIPTION    PART NUMBER

                  D501          DIODE,              8-719-423-23            DIODE,          8-719-422-97
                               MA8110-M                                    MA8091-M
                     -              -                           -         SHEET (FAN)       3-928-751-01




Reference: Tech News ME95033; SEC ME00496                                                      PRINTED IN USA
