Image preview - the first page of the document



>> Download Car0343 documenatation <<

Text preview - extract from the document

                                  Car Stereo                                                    CSA-14
                                  Service Bulletin
                                   Sony Service Company - Technical Services
                                   A Division of Sony Electronics Inc.
                                   Sony Drive, Park Ridge, New Jersey 07656


Model:      XR-U500/U700/U800                                              No.    343
Subject: Switching Noise Heard From Speakers While                         Date: November 18, 1994
            Volume Is Being Increased Or Decreased.


Symptom:
  (54)          Switching noise may be heard from the speakers while the volume level is being
                increased or decreased. The noise is particularly noticeable when high power
                amplifiers or high efficiency speakers are connected to the unit.



Solution:       If the customer complains of this problem, remove R126, R128, R226, and R228
                from the Main board. On XR-U800, also remove R151 and R251.
