Image preview - the first page of the document



>> Download HFP0419 documenatation <<

Text preview - extract from the document

                                   Hi-Fi Products                                                CSA-13
                                   Service Bulletin
                                   Sony Service Company - Technical Services
                                   A Division of Sony Electronics Inc.
                                   Sony Drive, Park Ridge, New Jersey 07656


Model:      D-335, TCD-D7                                                  No.    419
Subject: No Digital Recording                                              Date: December 27, 1994


Symptom:
  (55)         Digital recording is impossible when connecting D-335 to TCD-D7 using an optical
               connection cable.



Solution:      Apply the following changes on the Main Board of D-335.

               1. Replace the Ceramic Oscillator X301 with a Crystal oscillator.

               2. Add 2 capacitors.

                   REF                    FORMER                                        NEW
                             DESCRIPTION          PART NUMBER               DESCRIPTION    PART NUMBER

                   X301       CERAMIC                1-760-404-11             CRYSTAL         1-567-908-11
                             OSCILLATOR                                      OSCILLATOR


                                      -                                       15PF/50V
                   C391/                                        -                             1-162-917-11
                                                                            CERAMIC CHIP
                   C392
                                                                             CAPACITORS




Reference: Tokyo fax No. GA00994                                                                 PRINTED IN USA
