                                Hi-Fi Products                                                 CSA-13
                                Service Bulletin
                                 Sony Service Company - Technical Services
                                 A Division of Sony Electronics Inc.
                                 Sony Drive, Park Ridge, New Jersey 07656


Model: DTC59ES; DTC690                                                   No.    443
Subject: No Play Mode                                                    Date: June 23, 1995


Symptom:
  (**)         The unit will not enter PLAY when changing from a FF or REW mode. This is
               due to tape slack when the mechanism stops.




Solution:      Remove the Slider Reel Lock (ref.#359 p/n 3-368-411-01) and the screw (ref.
               #397). See diagram below.




Reference: Sony Europe ef # AU01295                                                            PRINTED IN USA
