                                   Hi-Fi Products                                               CSA-13
                                   Service Bulletin
                                    Sony Service Company - Technical Services
                                    A Division of Sony Electronics Inc.
                                    Sony Drive, Park Ridge, New Jersey 07656


Model:      CDP-C265                                                            No.       455
Subject: Disc Table will not stop Rotating                                      Date: November 10, 1995


Symptom:
  (62)         The disc table (B) rotation speed is too fast and will not stop rotating.



Solution:      If this problem is seen, note the serial number of the unit and add the proper resistor
               in parallel to R459 (1.2K ohm). The additional resistor (listed below) should be
               added to the foil pattern side of the PCB.

                  SERIAL             8000101 - 8000682                           8000001 - 8000100
                   NO.
                                                                                 8000683 - 8018074
                  RANGE
                              DESCRIPTION            PART NUMBER            DESCRIPTION     PART NUMBER

                                7.5K OHM              1-247-852-11           12K OHM        1-247-857-11




Reference: Technical News AU-95024                                                              PRINTED IN USA

                                                PRINTED ON RECYCLED PAPER
