Image preview - the first page of the document



>> Download HFP0457 documenatation <<

Text preview - extract from the document

                                  Hi-Fi Products                                                 CSA-13
                                  Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656


Model:      TC-WR445                                                          No.       457
Subject: Erratic Deck Operation                                               Date: November 10, 1995


Symptom:
  (62)         Deck A operates erratically due to incomplete meshing of Gear (A/B) and trigger
               lever.



Solution:      Replace Gear (A/B) in the DC motor assy. See part numbers listed below.


                   REF                    FORMER                                        NEW
                             DESCRIPTION           PART NUMBER            DESCRIPTION     PART NUMBER

                   M2         GEAR (A/B)            3-918-330-01          GEAR (A/B)          3-918-330-02


               Applicable Serial number range:- from 826023 and up.




Reference: Technical News AU-95017                                                               PRINTED IN USA

                                              PRINTED ON RECYCLED PAPER
Filename:             HFP0457.SB
