Image preview - the first page of the document



>> Download HFP0468 documenatation <<

Text preview - extract from the document

                                     Hi-Fi Products                                             CSA-13
                                    Service Bulletin
                                     Sony Service Company - Technical Services
                                     A Division of Sony Electronics Inc.
                                     Sony Drive, Park Ridge, New Jersey 07656


Model:      STR-GX700ES                                                          No.    468
Subject: Unit goes into Protection when Powered On                               Date: February 15, 1996


Symptom:
  (**)           The unit will go into protection when it is powered on.



Solution:        Add missing jumper wire, JW623 on the Amp Board. The See diagram below




Reference: Investigation Result                                                                 PRINTED IN USA

                                                 PRINTED ON RECYCLED PAPER
