Image preview - the first page of the document



>> Download HFP0475 documenatation <<

Text preview - extract from the document

                                   Hi-Fi Products                                              CSA-13
                                   Service Bulletin
                                    Sony Service Company - Technical Services
                                    A Division of Sony Electronics Inc.
                                    Sony Drive, Park Ridge, New Jersey 07656

Model:      MDS-302                                                             No.    475
Subject: Note when replacing an Optical Block                                   Date: March 25, 1996


Symptom:
  (62)          After replacing an optical block, two to three minutes into playing back a 74 minute
                MO disc, "Retry Error" will be displayed and the sound will skip.



Solution:       There are two types of Optical block assemblies. In the old type a washer was added
                to limit the travel of the optics on the shaft. The new type of Optical block assembly
                has been improved and does not require the washer. Remove the white washer (see
                diagram below) from the shaft when replacing an older Optical block with the new
                type. To distinguish the difference between the old and new optical blocks see the
                diagram below.




Reference: Technical news AU-95038                                                            PRINTED IN USA
