Image preview - the first page of the document



>> Download HFP0485 documenatation <<

Text preview - extract from the document

                                            CONFIDENTIAL                                                  CSA-13
Sony Service Company
National Technical Services                 Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656                Hi-Fi Products

Model:           D-335                                                                    No.       485
Subject: Does Not Operate                                                                 Date: April 29, 1996


Symptom:
  (12)                  Does not operate.

                        Will not accept any key command and LED is distorted.

Solution:               If this symptom occurs:

                        Make continuity between the upper lid and the PCB ground.
                        1. File the pattern of power PCB (Fig-1) lightly and clean with alcohol.
                        2. Add a rubber cushion on the DC Jack. (Fig-2)
                        3. Put the upper lid and confirm the continuity between the mount screw of upper lid
                        and the negative battery terminal.

                             REF                 DESCRIPTION                        PART NUMBER

                                -            RUBBER CUSHION                          3-355-463-01

                        Applicable Serial Nos:         100,001 to 251,510




Reference: Tokyo Fax No. GA-95001                                                                         PRINTED IN USA

                                                        PRINTED ON RECYCLED PAPER
