Image preview - the first page of the document



>> Download HFP0491 documenatation <<

Text preview - extract from the document

                                          CONFIDENTIAL                                                CSA-13
Sony Service Company
National Technical Services               Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656              Hi-Fi Products
Model:           MDS-S35, MDS-302, MDS-JA3ES                                         No.        491
Subject: Note when replacing Optical Block                                           Date: June 14, 1996


Symptom:
 (****)                 There are several types of optical block assemblies and it is sometimes necessary to
                        remove a mounted component when installing a new optical block assembly. In
                        instances where component removal is required, a notice is packed with the
                        replacement part outlining the specific component to remove. In addition to the
                        component outlined in the notice remove the capacitor listed below.



Solution:               Remove the following capacitor when replacing the Optical Block assembly.
                        Removing C168 produces no side effect.

                              REF                 FORMER                                        NEW
                                       DESCRIPTION         PART NUMBER            DESCRIPTION     PART NUMBER

                            C168      0.1UF CERAMIC         1-163-038-91           REMOVE              N/A
                                           CHIP




Reference: Technical News AU-96008                                                                    PRINTED IN USA
