HiFi - Sony Service Bulletin 332R1


>> Download HiFi - Sony Service Bulletin 332R1 documenatation <<

Text preview - extract from the document
                                   Audio Products                                                    CSA-11
                                   Service Sbletin
                                    Sony Service Company - Technical Services
                                    A Division of Sony Electronics Inc.
                                    Sony Drive, Park Ridge, New Jersey 07656


Model:      CFD-250/260/580/757/758/767/768                                 No.    332R1
Subject: Precautions When Replacing Optical Pick Up Block                   Date: October 26, 1995
            KSS-360A


Symptom:
  (**)          The new optical pick up block has a plug in type flex connector which does not fit
                onto the old solder in type translation board.



Solution:       When replacing the optical pick up block with the solder in type flex, order a new
                translation board, p/n A-4910-578-A to plug into the new optical pick up block.




Reference: FPR-P2354                                                                             PRINTED IN USA
