Image preview - the first page of the document
![Sony_KDL-40VL130_KDL-52W3000_KDL-52WL130_KDL-52WL135_[SM]](/pics/5c26fe6d2603f.gif)
>> Download Sony_KDL-40VL130_KDL-52W3000_KDL-52WL130_KDL-52WL135_[SM] documenatation <<
Text preview - extract from the document
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER DESTINATION
FIX2 CHASSIS
KDL-40VL130 RM-YD014 US
KDL-52W3000 RM-YD017 US/CND
KDL-52WL130 RM-YD017 US
KDL-52WL135 RM-YD014 US
ORIGINAL MANUAL ISSUE DATE: 8/2007
:UPDATED ITEM
REVISION DATE SUBJECT
8/2007 No revisions or updates are applicable at this time.
9/2007 Updated Self Check illustration. Replaced page 12.
Added PNs for LCD Panels and FB1 Boards for S/N 8,100,001 to 8,499,999 and
8,600,001 on up. Replaced page 100 & 103.
10/2007 Updated schematic diagrams to correct connector pins #s that were up side down.
Replaced pages 29, 36, 39, 42, 45, 47, 62, 64, 78, 81, 89, & 94.
12/2007 Updated entire manual to include KDL-52WL135 model.
LCD DIGITAL COLOR TELEVISION
9-883-764-04
Self Diagnosis
Supported model
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER
FIX2
DESTINATION
CHASSIS
KDL-40VL130 RM-YD014 US
KDL-52W3000 RM-YD017 US/CND
KDL-52WL130 RM-YD017 US
KDL-52WL135 RM-YD014 US
KDL-40VL130 RM-YD014
LCD DIGITAL COLOR TELEVISION
9-883-764-04
KDL-40VL130/52W3000/52WL130/52WL135
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 5 3-4. Schematics and Supporting Information .............................. 31
Warnings and Cautions .................................................................. 7 AU Board Schematic Diagram (1 of 6) ................................. 31
AU Board Schematic Diagram (2 of 6) ................................. 32
Safety-Related Component Warning .............................................. 8
AU Board Schematic Diagram (3 of 6) ................................. 33
Safety Check-Out ......................................................................... 10 AU Board Schematic Diagram (4 of 6) ................................. 34
Self-Diagnostic Function................................................................11 AU Board Schematic Diagram (5 of 6) ................................. 35
SECTION 1: DISASSEMBLY ............................................................... 13 AU Board Schematic Diagram (6 of 6) ................................. 36
DF1 Board Schematic Diagram
1-1. Rear Cover Removal............................................................ 13
(KDL-40VL130 Only) ............................................... 38
1-2. Arm (Bracket) and Stand Removal ..................................... 13 DF4 Board Schematic Diagram
1-3. Speakers, HW3 Board, and AC Inlet Removal .................... 14 (ALL EXCEPT KDL-40VL130) ................................. 41
1-4. HW1 Board Removal ........................................................... 14 DF5 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) ................................. 44
1-5. UB2 Board Removal (KDL-52WL135 Only) ........................ 14
FB1 Board Schematic Diagram
1-6. HV2 Board Removal (KDL-40VL130 Only) (ALL EXCEPT KDL-40VL130) (1 of 16) ................... 47
or HW2 Board Removal (ALL EXCEPT KDL-40VL130)....... 15 FB1 Board Schematic Diagram
1-7. AU Board and FB1 Board (ALL EXCEPT KDL-40VL130) (ALL EXCEPT KDL-40VL130) (2 of 16) ................... 48
or FB3 Board (KDL-40VL130 Only) Removal ...................... 15 FB1 Board Schematic Diagram
1-8. TUU2 Board Removal .......................................................... 16 (ALL EXCEPT KDL-40VL130) (3 of 16) ................... 49
FB1 Board Schematic Diagram
1-9. DF1 Board and GF1 Board Removal
(ALL EXCEPT KDL-40VL130) (4 of 16) ................... 50
(KDL-40VL130 Only) ............................................................ 16
FB1 Board Schematic Diagram
1-10. DF4 Board, DF5 Board, and GF2 Board Removal (ALL EXCEPT KDL-40VL130) (5 of 16) ................... 51
(All Except KDL-40VL130) ................................................... 17 FB1 Board Schematic Diagram
1-11. Stay Removal ....................................................................... 17 (ALL EXCEPT KDL-40VL130) (6 of 16) ................... 52
1-12. LCD Panel Removal ............................................................ 18 FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (7 of 16) ................... 53
1-13. (Balancer Boards) ETC-Inverter MT Board Removal ........... 19
FB1 Board Schematic Diagram
SECTION 2: SERVICE ADJUSTMENTS ............................................. 20 (ALL EXCEPT KDL-40VL130) (8 of 16) ................... 54
2-1. Remote Adjustment Buttons and Indicators ......................... 20 FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (9 of 16) ................... 55
2-2. Accessing Service Adjustments ........................................... 20
FB1 Board Schematic Diagram
2-3. Updating Model Information after (ALL EXCEPT KDL-40VL130) (10 of 16) ................. 56
Replacing the FB1 Board or FB3 Board............................... 22 FB1 Board Schematic Diagram
SECTION 3: DIAGRAMS ..................................................................... 23 (ALL EXCEPT KDL-40VL130) (11 of 16) ................. 57
FB1 Board Schematic Diagram
3-1. Circuit Boards Location ........................................................ 23
(ALL EXCEPT KDL-40VL130) (12 of 16) ................. 58
3-2. Printed Wiring Boards and FB1 Board Schematic Diagram
Schematic Diagrams Information ......................................... 24 (ALL EXCEPT KDL-40VL130) (13 of 16) ................. 59
3-3. Block Diagram ...................................................................... 25 FB1 Board Schematic Diagram
3-3-1. Block Diagram (KDL-40VL130 Only) ....................... 25 (ALL EXCEPT KDL-40VL130) (14 of 16) ................. 60
3-3-2. Block Diagram (KDL-52W3000/52WL130 Only)...... 26 FB1 Board Schematic Diagram
3-3-3. Block Diagram (KDL-52WL135 Only) ...................... 27 (ALL EXCEPT KDL-40VL130) (15 of 16) ................. 61
3-3-4. Connector Diagram (KDL-40VL130 Only) ............... 28 FB1 Board Schematic Diagram
3-3-5. Connector Diagram (ALL EXCEPT KDL-40VL130) (16 of 16) ................. 62
(KDL-52W3000/52WL130 Only) .............................. 29
3-3-6. Connector Diagram (KDL-52WL135 Only) .............. 30
KDL-40VL130/52W3000/52WL130/52WL135 3
KDL-40VL130/52W3000/52WL130/52WL135
SECTION TITLE PAGE SECTION TITLE PAGE
FB3 Board Schematic Diagram SECTION 4: EXPLODED VIEWS ...................................................... 101
(KDL-40VL130 Only) (1 of 15) ................................. 64 4-1. Rear Cover Assembly and Stand Assembly ...................... 101
FB3 Board Schematic Diagram
4-2. Chassis .............................................................................. 102
(KDL-40VL130 Only) (2 of 15) ................................. 65
FB3 Board Schematic Diagram 4-3. Connectors ......................................................................... 103
(KDL-40VL130 Only) (3 of 15) ................................. 66 4-4. Speakers ............................................................................ 104
FB3 Board Schematic Diagram 4-5. Bezel Assembly and LCD Panel
(KDL-40VL130 Only) (4 of 15) ................................. 67 (KDL-40VL130 Only) .......................................................... 105
FB3 Board Schematic Diagram
4-6. Bezel Assembly and LCD Panel
(KDL-40VL130 Only) (5 of 15) ................................. 68
(KDL-52W3000/52WL130 Only) ........................................ 106
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (6 of 15) ................................. 69 4-7. Bezel Assembly and LCD Panel
FB3 Board Schematic Diagram (KDL-52WL135 Only) ......................................................... 107
(KDL-40VL130 Only) (7 of 15) ................................. 70 SECTION 5: ELECTRICAL PARTS LIST .......................................... 108
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (8 of 15) ................................. 71 APPENDIX A: ENCRYPTION KEY COMPONENTS ..........................A-1
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (9 of 15) ................................. 72
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (10 of 15) ............................... 73
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (11 of 15) ............................... 74
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (12 of 15) ............................... 75
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (13 of 15) ............................... 76
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (14 of 15) ............................... 77
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (15 of 15) ............................... 78
GF1 Board Schematic Diagram
(KDL-40VL130 Only) ............................................... 80
GF2 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) ................................. 83
HV2 Board Schematic Diagram
(KDL-40VL130 Only) ............................................... 85
HW1 Board Schematic Diagram .......................................... 88
HW2 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (1 of 2) ..................... 90
HW2 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (2 of 2) ..................... 91
HW3 Board Schematic Diagram .......................................... 94
TUU2 Board Schematic Diagram (1 of 2) ............................ 96
TUU2 Board Schematic Diagram (2 of 2) ............................ 97
3-5. Semiconductors ................................................................. 100
KDL-40VL130/52W3000/52WL130/52WL135 4
KDL-40VL130/52W3000/52WL130/52WL135
SPECIFICATIONS
Power Requirements 120V-240V AC, 50/60Hz HDMI IN 1/2/3:
HDMI: Video:480i, 480p, 720p, 1080i,1080p, 1080/24p
Power Consumption (W) Audio: Two channel linear PCM 32, 44.1 and
In Use (Max) 220W (KDL-40VL130 Only) 48 kHz, 16, 20 and 24 bits, Dolby Digital
295W (All except KDL-40VL130) AUDIO (for HDMI IN 1):
In Standby Less than 0.4W 500 mVrms (100% modulation) (Fixed)
Impedance: 47 kilohms
VIDEO (IN) 1/2/3:
S Video (4-Pin Mini DIN (VIDEO 1 Only) AUDIO OUT:
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative 500 mVrms (100% modulation) (Fixed)
C: 0.286 Vp-p (Burst signal), 75 ohms 1 Vrms at the maximum volume setting (Variable)
Video
1.0 Vp-p, 75ohms unbalanced, sync negative DIGITAL OUT (OPTICAL):
Audio Optical Digital Audio Ouput (PCM/Dolby digital)
500 mVrms (100% modulation)
Impedance:47 kilohms PC IN:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
COMPONENT IN 1/2:
YPBPR (Component Video) PC AUDIO INPUT:
Y:1.0 Vp-p, 75 ohms unbalanced, sync negative Stereo mini jack, 500 mVrms 1(100% modulation)
PB:0.7 Vp-p, 75 ohms Impedance: 47 kilohoms
PR:0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i, 1080p HEADPHONES:
AUDIO Stereo mini jack
500 mVrms (100% modulation) Impedance: 16 ohms
Impedance: 47 kilohms
Trademark Information
As an ENERGY STAR◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
