Image preview - the first page of the document
![Sony_KDL-46V4100_[SM]](/pics/5c26fea3e3b68.gif)
>> Download Sony_KDL-46V4100_[SM] documenatation <<
Text preview - extract from the document
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER DESTINATION
EX1 CHASSIS
KDL-46V4100 RM-YD023 US
KDL-46V4100 RM-YD023 CANADA
KDL-46V4100 RM-YD023 MEXICO
KDL-46V4100 RM-YD023 LATIN AMERICA
ORIGINAL MANUAL ISSUE DATE: 5/2008
REVISION DATE SUBJECT
5/2008 No revisions or updates are applicable at this time.
LCD DIGITAL COLOR TELEVISION
9-883-784-01
Self Diagnosis
Supported model
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER DESTINATION
EX1 CHASSIS
KDL-46V4100 RM-YD023 US
KDL-46V4100 RM-YD023 CANADA
KDL-46V4100 RM-YD023 MEXICO
KDL-46V4100 RM-YD023 LATIN AMERICA
KDL-46V4100 RM-YD023
LCD DIGITAL COLOR TELEVISION
9-883-784-01
KDL-46V4100
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 4 SECTION 3: DIAGRAMS ..................................................................... 41
Warnings and Cautions - English ................................................... 6 3-1. Circuit Boards Location ........................................................ 41
Warnings and Cautions - French .................................................... 7 3-2. Printed Wiring Boards and
Safety-Related Component Warning .............................................. 8 Schematic Diagrams Information ......................................... 41
Safety Check-Out ......................................................................... 10 3-3. Block Diagram ...................................................................... 43
Self-Diagnostic Function................................................................11 3-4. Schematics and Supporting Information .............................. 44
BU Board Schematic Diagram (1 of 12) ............................... 44
SECTION 1: DISASSEMBLY ............................................................... 13 BU Board Schematic Diagram (2 of 12) ............................... 45
1-1. Rear Cover Removal............................................................ 13 BU Board Schematic Diagram (3 of 12) ............................... 46
1-2. Switch Unit Removal (Contains H1 Board) .......................... 13 BU Board Schematic Diagram (4 of 12) ............................... 47
BU Board Schematic Diagram (5 of 12) ............................... 48
1-3. Side Jack Bracket, BU Shield, and BU Board Removal....... 14
BU Board Schematic Diagram (6 of 12) ............................... 49
1-4. IP5Z Board (Power Unit) Removal ....................................... 14
BU Board Schematic Diagram (7 of 12) ............................... 50
1-5. Stand and Under Cover Removal ........................................ 15 BU Board Schematic Diagram (8 of 12) ............................... 51
1-6. AC Inlet Removal ................................................................. 15 BU Board Schematic Diagram (9 of 12) ............................... 52
1-7. Structural Frames and Brackets Removal ........................... 16 BU Board Schematic Diagram (10 of 12) ............................. 53
BU Board Schematic Diagram (11 of 12) ............................. 54
1-8 Speakers, Under Bar, H4 Board and Light Guide Removal 17
BU Board Schematic Diagram (12 of 12) ............................. 55
1-9. LCD Panel Removal............................................................. 17
H3E Board Schematic Diagram ........................................... 57
1-10. Balancer (ETC-Inverter MT) Board Removal ....................... 18 H4 Board Schematic Diagram.............................................. 59
WIRE DRESSING ........................................................................ 19 IP5Z Board Schematic Diagram (1 of 2) .............................. 61
IP5Z Board Schematic Diagram (2 of 2) .............................. 62
SECTION 2: SERVICE ADJUSTMENTS ............................................. 39
3-5. Semiconductors ................................................................... 65
2-1. Viewing Service Adjustment Data ........................................ 39
2-2. Accessing Service Adjustment Mode ................................... 39 SECTION 4: EXPLODED VIEWS ........................................................ 66
2-3. Viewing the Service Menus .................................................. 39 4-1. Rear Cover Assembly and Stand Assembly ........................ 66
2-4. Using the Remote Commander to View Service Data ......... 40 4-2. Chassis ................................................................................ 67
2-5. Resetting to Factory Defaults ............................................... 40 4-3. Connectors ........................................................................... 68
4-4. Bezel Assembly and LCD Panel .......................................... 69
4-5. Screw Legend ...................................................................... 70
SECTION 5: ELECTRICAL PARTS LIST ............................................ 71
APPENDIX A: ENCRYPTION KEY COMPONENTS ..........................A-1
KDL-46V4100 3
KDL-46V4100
SPECIFICATIONS
Power Requirements 120V AC, 60Hz HDMI IN 1/2/3/4:
HDMI: Video: 480i, 480p, 720p, 1080i,1080p, 1080/24p
Power Consumption (W) Audio: Two channel linear PCM 32, 44.1 and
In Use (Max) 260W 48 kHz, 16, 20 and 24 bits, Dolby Digital
In Standby Less than 0.1W AUDIO (for HDMI IN 4):
500 mVrms (Typical)
VIDEO (IN) 1/2/3: Impedance: 47 kilohms
S Video (4-Pin Mini DIN (VIDEO 1 Only)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative AUDIO OUT:
C: 0.286 Vp-p (Burst signal), 75 ohms 500 mVrms (Typical)
Video
1.0 Vp-p, 75 ohms unbalanced, sync negative DIGITAL OUT (OPTICAL):
Audio Optical Digital Audio Output (PCM/Dolby digital)
500 mVrms (Typical)
Impedance:47 kilohms PC IN:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
COMPONENT IN 1/2:
YPBPR (Component Video) PC AUDIO INPUT:
Y:1.0 Vp-p, 75 ohms unbalanced, sync negative Stereo mini jack, 500 mVrms (Typical)
PB:0.7 Vp-p, 75 ohms Impedance: 47 kilohms
PR:0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i, 1080p
AUDIO
500 mVrms (Typical)
Impedance: 47 kilohms
Trademark Information
Blu-ray Disc is a trademark. In the United States, TV Guide and other
related marks are registered marks of
"BRAVIA" and , S-Force, Gemstar-TV Guide International, Inc. and/or
BRAVIA Sync, , DMex and "x.v. Color" are one of its affiliates. In Canada, TV Guide is a
trademarks or registered marks of Sony registered mark of Transcontinental Inc., and is
Corporation. used under license by Gemstar-TV Guide
"XMB" and "XrossMediaBar" are the International, Inc.
trademarks of Sony Corporation and Sony
Computer Entertainment Inc. The TV Guide On Screen system is
manufactured under license from Gemstar-TV
"PLAYSTATION" is a registered trademark Guide International, Inc. and/or one of its
and "PS3" is a trademark of Sony Computer affiliates.
Entertainment Inc.
The TV Guide On Screen system is protected
Adobe is a registered trademark or a trademark by one or more of the following United States
of Adobe Systems Incorporated in United patents 4,908,713; 6,498,895; 6,850,693;
States and/or other countries. 6,396,546; 5,940,073; 6,239,794 to
Gemstar-TV Guide International, Inc. and/or
Macintosh is a trademark of Apple Inc., its subsidiaries.
registered in the U.S. and other countries.
Gemstar-TV Guide International Inc. and/or its
HDMI, the HDMI logo and High-Definition related affiliates are not in any way liable for
Multimedia Interface are trademarks or the accuracy or availability of the program
registered trademarks of HDMI Licensing, schedule information or other data in the TV
LLC. Guide On Screen system and cannot guarantee
Fergason Patent Properties, LLC: service availability in your area. In no event
U.S. Patent No. 5,717,422 shall Gemstar-TV Guide International, Inc.
and/or its related affiliates be liable for any
U.S. Patent No. 6,816,141 damages in connection with the accuracy or
Manufactured under license from Dolby availability of the program schedule
Laboratories. "Dolby" and double-D symbol information or other data in the TV Guide On
are trademarks of Dolby Laboratories. Screen system.
Design and specifications are subject to change without notice.
KDL-46V4100 4
KDL-46V4100
KDL-46V4100
Speaker Output 10W+10W
mm 65 X 150 mm
in 21/2 x 57/8 in
Dimensions (W x H x D)
with stand
mm 1,120 x 782 x 307 mm
in 441/8 x 307/8 x 121/8 in
without stand
mm 1,120 x 742 x 115 mm
in 441/8 x 291/4 x 45/8 in
wall-mount hole pattern 300 x 300 mm
Mass
with stand
kg 30 kg
lbs 67 lbs
without stand
kg 26 kg
lbs 58 lbs
All measurements are approximations.
Television system Supplied Accessories
NTSC American TV Standard Remote Commander RM-YD023
ATSC (8VSB terrestrial) ATSC compliant 8VSB Two Size AA (R6) Batteries
QAM on cable ANSI/SCTE 07 2000 AC Power Cord
Cable Holder (1 attached to the TV)
Channel coverage Operating Instructions
Analog Quick Setup Guide
2-69 Terrestrial Warranty Card
1-135 Cable Online Registration Card
Digital Safety and Regulatory Booklet
2-69 Terrestrial Attaching the Table-Top Stand
1-135 Cable Installing the Wall-Mount Bracket
Antenna Optional Accessories
75-ohm external terminal for RF inputs Connecting Cables
Suport Belt Kit
Panel System Wall-Mount Bracket
LCD (Liquid Crystal Display) Panel SU-WL500
TV-Stand
Display Resolution (horizontal x vertical) WS-S10LS
1,920 dots x 1,080 lines SU-FL300M
SU-FL300L
Screen Size (measured diagonally)
~ 46 inches
KDL-46V4100 5
KDL-46V4100
WARNINGS AND CAUTIONS - ENGLISH
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualified to do so.
CARRYING THE TV
Be sure to follow these guidelines to protect your ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
