Image preview - the first page of the document
![Sony_KDL-23S2010_KDL-23S2010_KDL-26S2010_KDL-26S2010_KDL-32S2010_KDL-32S2010_KDL-40S2010_KDL-40S2010_KDL-46S2010_KDL-46S2010_[SM]](/pics/5c26fed05fe09.gif)
>> Download Sony_KDL-23S2010_KDL-23S2010_KDL-26S2010_KDL-26S2010_KDL-32S2010_KDL-32S2010_KDL-40S2010_KDL-40S2010_KDL-46S2010_KDL-46S2010_[SM] documenatation <<
Text preview - extract from the document
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER
WAX2
DESTINATION
CHASSIS
KDL-23S2010 RM-YD005 CANADA
KDL-23S2010 RM-YD005 US
KDL-26S2010 RM-YD005 CANADA
KDL-26S2010 RM-YD005 US
KDL-32S2010 RM-YD005 CANADA
KDL-32S2010 RM-YD005 US
KDL-40S2010 RM-YD005 CANADA
KDL-40S2010 RM-YD005 US
KDL-46S2010 RM-YD005 CANADA
KDL-46S2010 RM-YD005 US
ORIGINAL MANUAL ISSUE DATE: 7/2006
:UPDATED ITEM
REVISION DATE SUBJECT
7/2006 No revisions or updates are applicable at this time.
1/2007 Updated TOC to include Appendix A. Replaced Pg 3.
Added Encryption Key notes. Replaced Pgs 21, 27-34, 55-58, 59, & 66.
Identified Encryption Key boards. Replaced Pg 56 & 66.
Added new PNs LCD panels for 26" and 32" models (new Serial Number ranges) and
PNs for Inverter Boards. Replaced Pg. 58.
Added Support Belt description to Lock Assy, Rudder. Replaced Pg. 82.
Added APPENDIX A: ENCRYPTION KEY COMPONENTS to service manual. Added Pg A-1.
Self Diagnosis
Supported model
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER
WAX2
DESTINATION
CHASSIS
KDL-23S2010 RM-YD005 CANADA
KDL-23S2010 RM-YD005 US
KDL-26S2010 RM-YD005 CANADA
KDL-26S2010 RM-YD005 US
KDL-32S2010 RM-YD005 CANADA
KDL-32S2010 RM-YD005 US
KDL-40S2010 RM-YD005 CANADA
KDL-40S2010 RM-YD005 US
KDL-46S2010 RM-YD005 CANADA
KDL-46S2010 RM-YD005 US
KDL-26S2010 RM-YD005
KDL-23S2010/26S2010/32S2010/40S2010/46S2010
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 4 3-4. Schematics and Supporting Information .............................. 24
Warnings and Cautions .................................................................. 6 AU Board Schematic Diagram (1 of 2) ................................. 24
Safety-Related Component Warning .............................................. 7 AU Board Schematic Diagram (2 of 2) ................................. 25
BU Board Schematic Diagram (1 of 8) ................................. 27
Safety Check-Out ........................................................................... 9
BU Board Schematic Diagram (2 of 8) ................................. 28
Self-Diagnostic Function............................................................... 10
BU Board Schematic Diagram (3 of 8) ................................. 29
SECTION 1: DISASSEMBLY ............................................................... 12 BU Board Schematic Diagram (4 of 8) ................................. 30
1-1. Rear Cover Removal ............................................... 12 BU Board Schematic Diagram (5 of 8) ................................. 31
1-2. Vesa Bracket Assembly Removal ............................ 12 BU Board Schematic Diagram (6 of 8) ................................. 32
1-3. H1U Board Removal ................................................ 13 BU Board Schematic Diagram (7 of 8) ................................. 33
1-4. G1 Board (Power Supply) or G2 Board and BU Board Schematic Diagram (8 of 8) ................................. 34
H2U Board Removal ................................................ 13 G1 Board, Power Unit
1-5. AU Board Removal .................................................. 14 (KDL-23S2010/26S2010/32S2010 Only) ................ 36
1-6. QT Board Removal .................................................. 14 G2 Board Schematic Diagram
1-7. QS board and BU Board Removal........................... 15 (KDL-40S2010/46S2010 Only) ................................ 38
1-8. H3U Board and Speaker Removal .......................... 15 H1U Board Schematic Diagram ........................................... 40
1-9. LCD Panel Removal ................................................ 15 H2U Board Schematic Diagram ........................................... 41
H3U Board Schematic Diagram ........................................... 43
SECTION 2: SERVICE ADJUSTMENTS ............................................. 17
H46 Board Schematic Diagram............................................ 44
2-1. Remote Adjustment Buttons and Indicators ......................... 17
QS Board Schematic Diagram (1 of 5)................................. 46
2-2. Accessing Service Adjustments ........................................... 17 QS Board Schematic Diagram (2 of 5)................................. 47
2-2-1. Accessing the Digital Service Adjustment Menus .... 17 QS Board Schematic Diagram (3 of 5)................................. 48
2-2-2. Viewing the Digital Module Box QS Board Schematic Diagram (4 of 5)................................. 49
(Q-Box) Service Items ............................................. 18
QS Board Schematic Diagram (5 of 5)................................. 50
2-2-3. Accessing the Analog Service Adjustment Menus ... 18
QT Board Schematic Diagram ............................................. 52
2-3. Resetting the User Menu - Factory Reset ............................ 19
3-5. Semiconductors ................................................................... 54
2-4. Aging Mode .......................................................................... 19
SECTION 4: EXPLODED VIEWS ........................................................ 55
2-5. White Balance Adjustment. .................................................. 20
4-1. Rear Cabinet and Stand Assembly ..................................... 55
SECTION 3: DIAGRAMS ..................................................................... 21
4-2. Chassis ............................................................................... 56
3-1. Circuit Boards Location ........................................................ 21
4-3. Speakers .............................................................................. 57
3-2. Printed Wiring Boards and
4-4. LCD Panel ............................................................................ 58
Schematic Diagrams Information ......................................... 21
3-3. Block Diagram ...................................................................... 23 SECTION 5: ELECTRICAL PARTS LIST ............................................ 59
APPENDIX A: ENCRYPTION KEY COMPONENTS ..........................A-1
KDL-23S2010/26S2010/32S2010/40S2010/46S2010 3
KDL-23S2010/26S2010/32S2010/40S2010/46S2010
.'/6 .'/6 .'/6
6SHDNHU 2XWSXW : : : : :
'LPHQVLRQV : [ + [ '
ZLWK VWDQG
PP [ [ PP [ [ PP [ [ PP
LQ [ [ LQ [ [ LQ [ [ LQ
'LPHQVLRQV : [ + [ '
ZLWKRXW VWDQG
PP [ [ PP [ [ PP [ [ PP
LQ [ [ LQ [ [ LQ [ [ LQ
0DVV
ZLWK VWDQG
NJ NJ NJ NJ
OEV OEV R] OEV R] OEV R]
ZLWKRXW VWDQG
NJ NJ NJ NJ
OEV OEV R] OEV R] OEV
.'/6 .'/6
6SHDNHU 2XWSXW : : :
'LPHQVLRQV : [ + [ '
ZLWK VWDQG
PP [ [ PP [ [ PP
LQ [ [ LQ [ [ LQ
'LPHQVLRQV : [ + [ '
ZLWKRXW VWDQG
PP [ [ PP [ [ PP
LQ [ [ LQ [ [ LQ
0DVV
ZLWK VWDQG
NJ NJ NJ
OEV OEV R] OEV R]
ZLWKRXW VWDQG
NJ NJ NJ
OEV OEV R] OEV R]
Television system Supplied Accessories
American TV Standard Remote Commander RM-YD005
Two Size AA (R6) Batteries
Channel coverage 75-ohm coaxial cable
VHF: 2-13/UHF: 14-69/ Cable TV: 1-125 AC Power Cord
HD15-HD15 Cable
Antenna Suport Belt, Securing Screw, and Wood Screw
75-ohm external terminal for VHF/UHF Cable Holder
Operating Instructions
Panel System Quick Setup Guide
LCD (Liquid Crystal Display) Panel Warranty Card
Display Resolution (horizontal x vertical): Optional Accessories
1,366 dots x 768 lines Headphones Plug Adaptor
Connecting Cables
Screen Size (measured diagonally) Wall-Mount Bracket
26 inches (KDL-26S2010 Only) SU-WL31 (KDL-23S2010//26S2010/32S2010 Only)
32 inches (KDL-32S2010 Only) SU-WL51 (KDL-40S2010/46S2010 Only)
40 inches (KDL-40S2010 Only)
KDL-23S2010/26S2010/32S2010/40S2010/46S2010 5
KDL-23S2010/26S2010/32S2010/40S2010/46S2010
WARNINGS AND CAUTIONS
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless you are qualified to do so.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of
this receiver is directly connected to the ac power line.
!
SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for
safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements
published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual. Follow these procedures
whenever critical components are replaced or improper operation is suspected.
