Image preview - the first page of the document



>> Download KV-21FA310 documenatation <<

Text preview - extract from the document

                     HISTORY INFORMATION FOR THE FOLLOWING MANUAL:




   SERVICE MANUAL                                                                              BA-6              CHASSIS

               MODEL NAME               REMOTE COMMANDER               DESTINATION            CHASSIS NO.


          KV-20FS120                       RM-Y194                         US                 SCC- S61K-A

          KV-20FS120                       RM-Y194                        CND                 SCC- S59H-A

          KV-21FM120                       RM-W151                  LATIN NORTH               SCC- S60X-A

          KV-21FS120                       RM-Y194                  LATIN NORTH               SCC- S60Y-A

          KV-21FS120                       RM-Y194                  LATIN SOUTH               SCC- S73A-A

          KV-21FA310                       RM-Y180                  LATIN NORTH               SCC- S60T-A

          KV-21FA310                       RM-Y180                  LATIN SOUTH               SCC- S60U-A

          KV-24FS120                       RM-Y194                         US                 SCC- S61L-A

          KV-24FS120                       RM-Y194                        CND                 SCC- S59J-A

          KV-25FS120                       RM-Y194                  LATIN NORTH               SCC- S73B-A

          KV-25FS120                       RM-Y194                  LATIN SOUTH               SCC- S73C-A




 ORIGINAL MANUAL ISSUE DATE: 3/2004

          :UPDATED ITEM



 REVISION DATE              SUBJECT

 3/2004                     No revisions or updates are applicable at this time.
 4/2004                     Corrected HV Hold-Down PN Replaced Page 17 with Page 17, Replaced Page 37 with Page 37
                            Removed critical mark on SPACER, DY Replaced Page 52 with Page 52, Page 54 with Page 54,
                            and Page 56 with Page 56
                            Corrected screw placement for Speaker Assy Replaced Page 56 with Page 56
                            Added Remote Control Battery Cover PNs for RM-Y194 and RM-W151 Replaced Page 80 with Page 80.
 3/2005                     Corrected Remote Control Battery Cover PN for RM-Y194 Replaced Page 80 with Page 80.


                                                                  TRINITRON
