Image preview - the first page of the document
KV-HW212M60_THAILAN


>> Download KV-HW212M60_THAILAN documenatation <<

Text preview - extract from the document
SERVICE MANUAL                                                    BX1S           CHASSIS
MODEL             COMMANDER DEST.      CHASSIS NO.    MODEL                COMMANDER DEST.   CHASSIS NO.


KV-HW212M60       RM-W101   Thailand    SCC-U94W-A

KV-HW212M80       RM-W101   ME          SCC-U90W-A

KV-HW212M80       RM-W101   Saudi Arabia SCC-V10P-A

KV-HW212M80/H     RM-W101   Saudi Arabia SCC-V10Q-A
(DOLPHIN GREY)
KV-HW212M81       RM-W100   ME          SCC-U90X-A

KV-HW212M83       RM-W101   ME          SCC-U90Y-A

KV-HW212M83/H     RM-W101   Saudi Arabia SCC-V10R-A
(DOLPHIN GREY)
KV-HW212P52       RM-W101   Thailand    SCC-V94V-A




                 (KV-HW212M83/M83/H)                          (EXCEPT KV-HW212M83/M83/H)




                                       RM-W101            RM-W100




                                                         TRINITRON
